Superbrightleds STAC Series Bedienungsanleitung

120 VAC LED Strips

Important: SAVE THESE INSTRUCTIONS

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

STAC Series

4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com

Rev Date: V1 04/26/2022

5yr

User Manual

IMPORTANT SAFETY NOTES

• Do not cover this product as the covering may cause the exible light to overheat, melt, and/or ignite.

• Do not operate with the strip tightly coiled.

• Do not puncture, cut, shorten, or splice the exible lighting other than by the means instructed in this

manual and using approved accessories. Any modication that is required should only be done with

the power turned o󰀨/disconnected and by a certied electrician.

• Do not route the cord or strip through walls, doors, windows, or any like part of a building or structure.

• Do not use if there is any damage to the light or cord insulation. Inspect periodically.

• Do not submerge in liquids or use the product in the vicinity of standing water or other liquids.

• Secure this exible light using only the optional clips or adhesive foam shown on the site. Do no secure

this product or its cord with staples, nails, or like means that may damage the insulation or permanently

attach to the building structure.

• Do not subject exible lighting to continuous exing.

• This product has a polarized 1-15P plug as a feature to reduce the risk of electric shock. This plug will

t in a polarized outlet only one way. If the plug does not t fully in the outlet, reverse the plug. Do not

use with an extension cord unless it is polarity specic and the plug can be fully inserted. Do not alter

or replace the plug.

WARNING: When using outdoor, basic safety precautions should always be followed to reduce

the risk of re, electric shock, and personal injury. Ground fault circuit interrupter (GFCI) protection

must be used on the circuits or outlet when the strips are intended to be used outdoors. Receptacles

with built-in GFCI protection are the easiest way to facilitate this kind of connection.

Fuse Replacement

Mounting

The 1-15P power cord (also sold as STAC-1-15P-50) has a built in fuse. There is also a spare stored

in the fuse compartment. If replacement is necessary beyond that, use similar 8 A 125 V fuse only.

Do not attempt to access or replace fuse unless cord is unplugged.

1. Grasp plug and remove from receptacle or other outlet device. Do not unplug by pulling on cord.

2. Slide open fuse cover on plug.

3. Remove fuse carefully and replace with spare located in plug or other compatible fuse.

WARNING: Risk of re. Replace fuse with 8 amp, 125 volt fuse only.

4. Slide the fuse cover closed.

WARNING: Risk of re. Do not replace attachment plug. It contains a safety device (fuse) that should

not be removed. Do not use product if the attachment plug is damaged in any way.

Secure this exible light using only the optional clips (STAC-CLIP) or adhesive foam shown on the site.

1. Mount clips at even increments where the strip is to be mounted.

2. With power switched o󰀨 or disconnected, align strip with clips and snap fold-over clamp part

of the clip into place to secure the strip.

120 VAC LED Strips

Important: SAVE THESE INSTRUCTIONS

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

STAC Series

4400 Earth City Expy, St. Louis, MO 63045 866-590-3533 superbrightleds.com

Rev Date: V1 04/26/2022

5yr

User Manual

Part Numbers

Specications

Connection Types

Specications

Operating Temperature -4°–113° F(-20°–45° C)

IP Rating IP65

Dimming TRIAC

Power Consumption 14 W / m

Current 117 mA / m

WARNING: If a connection other than the original

is needed follow the below steps. Strips should not

be modied by anyone other than a fully certied

electrician. Strip should be unplugged or have supply

power removed before any modication or installation

procedures are performed. DO NOT CUT OR INSTALL

STRIP WHILE POWERED.

Standard 1-15P Plug (STAC-1-15P-50)

1. Measure desired length. Cut strip on designated cut line

being careful to avoid any damage to square terminal.

2. For pin connections, push two pins into square terminal.

3. For blade connections, push blade connector into

terminal slot.

4. Apply silicone glue for a water resistant seal.

5. Plug 1-15P connector into an appropriate outlet.

A GFCI outlet is recommended.

Optional Hardwire Connection (STAC-PT50)

1. Remove the attached cord if necessary.

Note: The original cord will be sealed to the strip,

so it will need the sealant to be cut/loosened.

2. Clean any remaining sealant from the strip.

3. Use accessory sealant (STAC-PVC1OZ) to seal the

hardwire connector and slide it onto the strip.

4. Make electrical connections using weatherproof

connectors.

STAC-A30K90 -C8D-14S5M-120V

STAC-A40K90-C8D-14S5M-120V

STAC-A50K90 -C8D-14S5M-120V

blade connector slides between

the bottom of PCB and the clear

plastic insulator strip

STAC-A30K90 -C8D-14S25M-120V

STAC-A40K90-C8D-14S25M-120V

STAC-A50K90 -C8D-14S25M-120V
