QUICK START GUIDE
MODEL:SLT-1900
Customer Service: (877) 246-0990
Scan here for bonus recipes and to
watch how-to videos that will help
you make the most of your air fryer.
or go to www.monchateau.us/sltappliances
M I C ROWAV E OV E N
WITH AI R F RYE R
High Baking Pan mode Low Baking Pan mode
Figure 1 Figure 2
Figure 3
INTRODUCTION TO THE USE OF
BAKING PAN & AIR FRY BASKET
The Baking Pan included in this machinehas two modes ofuse, high or
low, dependingon the size of the foodor the degree ofbrowning you
desire. To use the high position, justflip the Oven Rack over so theBaking
Pan sits higher upin the center (Figure 1). Ideal for pizza, chicken legs,
French fries, bread, etc. To use the low position, flip Oven Rack so the
Baking Pan sits lower in the center, closer to the glass plate (Figure 2).
Ideal for thawing, combined cooking and roasting a whole chicken.
1 Time Setting
It is used to set the time required for cooking.
2Temperature Setting
Used to set the cooking temperature.
3Weight Setting
Used to set the weight of cooking ingredients.
4Microwave Power Adjustment
Used to adjust the Microwave Power Level
Introduction to the Use of the Knob
1
4
2 3
Description of Microwave Power Level
MICROWAVE POWER LEVEL INDICATOR
MICROWAVE POWER LEVEL INDICATION
1P100
2P80
3P60
4P40
5P20
During the cooking process, the operator can adjust the power of the knob to
microwave as needed.
The Air Fry Basket included in this machine
should be used on Air Fry or Oven mode. To
use simply place the Air Fry Basket on the
glass plate included. Use the Bake/Drip Pan
under the Air Fry Basket to collect crumbs and
drippings from the food (Figure 3). Ideal for
chicken wings, French fries, shrimp, etc.
AUTOMATIC MICROWAVE MENU
(Weight Unit: Oz)
Reheat Meat Fish
100% Microwave Power 100% Microwave Power 100% Microwave Power
Weight Time Weight Time Weight Time
5 1:30 9 4:30 7 3:00
9 2:40 12 5:30 10 4:10
14 3:50 15 6:30 13 5:20
18 5:00 18 7:30 16 6:30
22 6:10 21 8:30 19 7:40
26 7:20
Potato Popcorn Vegetable
100% Microwave Power 100% Microwave Power 100% Microwave Power
Weight Time Weight Time Weight Time
8 6:00 3 2:30 5 2:10
16 9:00 4 3:00 12 4:30
24 12:00 5 3:30 18 5:30
AUTOMATICAIR FRYER MENU
Function Time (Min) Temp (°F)
Pizza 10 340
French Fries 18 400
Bread 3 400
Fish 12 380
Shrimp 12 360
Steak 12 400
Ribs 18 380
Wings 20 360
Snacks 5 400
PLEASE UNPACK AND WASH ALL PARTS WITH WARM SOAPY WATER BEFORE FIRST USE. ONLY THE ACCESSORIES ARE DISHWASHER SAFE.
INSTRUCTIONS FOR USE OF THE
CONTROL PANEL
See OWNERS MANUAL for informtaion on:
• Auto Mode Menu Functions
(Microwave & Air Fry)
•Manual Mode Menu Functions
(Microwave, Air Fry, Combi. Defrost)
DESCRIPTIONS OF PROCEDURES
AND FUNCTIONS
Start/+30Sec/Confirm Key Function:
1. When setting the function, press the “Start/+30Sec/Confirm” key as the
confirmation key.
2. After setting the cooking program, press the “Start/+30Sec/Confirm” key to
start cooking.
3. In the cooking pause state, press the “Start/+30Sec/Confirm” key to
continue cooking.
Child Lock Function
1. In standby mode, the “Child Lock ” icon is on, and pressing any
operation key is invalid at this time.
2. After power-on, if there is no operation within three minutes, the “Child
Lock ” icon will light up and the control panel will be automatically
locked.
3. After the work is over, if there is no operation within three minutes, the
“Child Lock ” icon will also be triggered automatically at this time.
4. Unlock: In the locked state, press and hold the “Stop/Clear ” key for two
seconds to release the “Child Lock ” icon, the “ ” icon will go out, and
the initial interface of the menu will be entered.
Buzzer
There will be 1 beep for effective key operation, 2 beeps for food prompt (end
of preheating for 6 minutes), and 5 long beeps after cooking.
Quick Microwave Function
1. In the initial interface state of the menu, every time you press the
“Start/+30Sec/Confirm” key, the time will be increased by 30 seconds, the
microwave icon on the display will light up, 100% microwave power output
will be set, and will start with a delay of 2 seconds.
2. During operation, you can press the “Start/+30Sec/Confirm” key to
increase the cooking time (30 seconds increments).
3. During operation, press the “Stop/Clear ” key once to enter the pause
state, and press the “Stop/Clear ” key again to stop the operation and
return to the initial interface of the menu.
Control Panel Functions
Initial State
Plug in the power and enter the initial interface of the function menu. The
buzzer will sound, the “Stop/Clear ” will light up, press “Stop/Clear ” and all
functions will light up and be ready for selection. After 1 second, it will enter the
standby state. In the standby state, Press the “Stop/Clear ” key to enter the
initial interface of the function menu.
(If there is no operation within 3 minutes, it will enter the lock screen sleep state,
the “ Screen Lock” icon and the “Stop/Clear ” key will light up, and all other
lights will go out). In the sleep state of the lock screen, press and hold the “Stop/
Clear ” key for two seconds to unlock and enter the initial interface of the
function menu. The initial interface of the function menu: all function lights are
on, and the digital screen displays 00:00.
Light Function
In the initial interface of the cooking and function menu, press the “Light”
button, the indicator light will turn from steady on to flashing (return to steady
on after 3 seconds). The light can be turned on and off, and the light will be
automatically turned off after 1 minute from time it was turened on.) The light
is off in the standby and lock screen state; the light will turn off automatically if
the door remains open for more than 1 minute.
NOTE: If the cooking time is less than or equal to 2 minutes, the oven light
is always on. If the cooking time is greater than 2 minutes, the oven light will
always be on 1 minute after the start and 1 minute before the end (the lamp is
off at all other times).
Stop/Clear Key Function
1. During the setting process, press the “Stop/Clear ” key to cancel the
current setting and return to the initial interface of the menu.
2. When running, press the “Stop/Clear ” key to enter the pause state (the
indicator light flashes), press the key again to cancel the running program
and return to the initial interface state of the menu. If there is no operation
within 60 minutes of the pause state, then Exit the function interface and
enter self-locking.
3. In the self-locking state, long press the “Stop/Clear ” key for two seconds
to unlock.
Stop Clear
/
