SUUNTO X9 QUICK GUIDE
Navigation method Activity status
START/DATA
Mode indicator
STOP/BACK
Battery level
UP
DOWN
ENTER
Altitude alarm
Weather alarm Time alarm
GPS signal
EN
4
1. INTRODUCTION
This is the Quick Guide for Suunto X9 wristop computer. It contains brief introductions
to all the modes and guidelines on where and when to use their functions. It also
contains more detailed instructions on how to use the most important functions.
However, it does not include all the information on Suunto X9, and the information
it contains is not always given in full detail. In other words, the Quick Guide should
be used alongside the instruction manual. Therefore you should first read the
instruction manual carefully before using the Quick Guide. You can find the instruction
manual on the CD-ROM supplied with your Suunto X9.
Checklist
Make sure the package contains the following items:
• Suunto X9
• Docking Station
• Charger
• PC-interface cable
• CD containing the Suunto Trek Manager software and the user guide
• Suunto X9 Quick Guide
• Suunto X9 Pocket Guide
• Should any of these be missing from the package, contact the resale agent who
sold you the package.
5
EN
ALARM
TIME/DATE
UNITS
GENERAL
REFERENCE
USE
BARO MEM
ALARM
DECLINATION
CALIBRATE
NAVIGATE
ROUTE
NAVIDATA
TRACK BACK
XTE ALARM
REFERENCE
GPS fix
ACTIVITY
GPS fix
REFERENCE
MEMORY
TIME/DATE
DUAL TIME
SYNC
UTC
LIGHT
BRIGHT
CONTRAST
TONES
INFO
TIME
DATE
TEMP
PRESS
ALTITUDE
VERT
DISTANCE
SPEED
POSITION
DATUM
GRID
ALARM LIST
ALTITUDE
SEA LEVEL
PRESSURE - TEMPERATURE GRAPH
ALTITUDE
BARO AL
CREATE
My Poin s
ROUTE LIST
ALTITUDE
SEA LEVEL
NAVIDATA LIST
ALTITUDE
SEA LEVEL
MEMORY LIST
GPS
MARK Memp
MARK HOME
FIND HOME
POSITION
ROUTE INFO
CREATE WP
SELECT
WP LIST
ERASE
VIEW
EDIT
LINK WP
UPDATE
ERASE
SHORTCUTS
SUMMARY
SHORTCUTS
SHORTCUTS
DAY LIGHT
SHORTCUTS
SHORTCUTS
rou e wp
GPS refresh
GPS refresh
VIEW
ERASE
TRACK BACK
TIME
ALTI/BARO
COMPASS
NAVIGATION
ACTIVITY
ALL MODES
ENTER Shor press
ENTER Long press
START/DATA Shor press
UP/DOWN
STOP/BACK Shor press
BUTTONS
STOP/BACK Long press
2. BASIC MENU STRUCTURE
6
Main display
Adjust the
settings and accept
with ENTE
3. GENERAL SETTINGS
Before starting to use your Suunto X9, you need to set the correct time and date.
You can also customize all the necessary units and settings.
These instructions show you how to set the time and date. The adjustments of the
other settings is fairly similar. You can find all the settings in the basic menu
structure.
Setting the time and date:
7
EN
4. TIME MODE
The Time mode includes normal watch functions such as time, date, alarm and
stopwatch. In the Time menu you can select the measuring units for the data
displayed in other modes, adjust the general settings such as display contrast and
button tones and define the GPS position format to match the maps you normally
use.
4.1. Using the Time mode-specific functions
General settings
• Set the time and date (TIME/DATE)
• Customize the desired units and settings, select the coordinate system (UNITS
and GENERAL)
Date
Time
Shortcuts
(Seconds,
Dual time,
Stopwatch)
8
Planning your journey
• Set the UTC offset (UNITS)
• Set the Position format (UNITS)
• If the position format is Grid, set the grid that matches your map (UNITS)
Before starting the hike
• Adjust the time and dual time if you are in a new time zone (TIME/DATE)
During hiking
• Use the stopwatch to record your runs, hikes etc.
• Adjust the light settings to suit different conditions (LIGHT)
9
EN
5. ALTI/BARO MODE
The Alti/Baro mode is used for measuring altitude, barometric pressure and
temperature. Suunto X9 calculates the altitude from the current barometric pressure,
which is more sensitive and accurate than the altitude measurement with the GPS,
and is also available when the GPS is off.
Because both altitude and weather data are measured with the same barometric
sensor, you have to select whether you want to use this mode as an altimeter or
as a weather station. The Use selection defines the set of information shown on
the main display. The Alti/Baro menu also contains weather and altitude alarms, the
reference setting needed to relate the current weather state with your current
altitude, and the weather memory.
5.1. Alti use
Vertical speed
Altitude
Shortcuts
(Temperature,
Absolute barometric
pressure (abs), Time)
10
5.2. Baro use
Sea le el barometric
pressure
6h-barometric
pressure graph
Shortcuts
(Absolute barometric
pressure (abs), Time,
Temperature)
Before starting the hike
• Set the reference altitude and/or sea level pressure (REFERENCE)
• Set the altitude or barometric alarms (ALARM)
During hiking
• View either altitude or barometric information (USE)
After the journey
• View the 7-day barometric memory (BARO MEM)
