Suzuki UG110 2021 Bedienungsanleitung

UG110

99500-11180-01E

FOREWORD

This manual contains an introductory description on

the SUZUKI UG110 and procedures for its inspec-

tion, service, and overhaul of its main components.

Other information considered as generally known is

not included.

Read the GENERAL INFORMATION section to fa-

miliarize yourself with the motorcycle and its main-

tenance. Use this section as well as other sections

as a guide for proper inspection and service.

This manual will help you know the motorcycle bet-

ter so that you can assure your customers of fast

and reliable service.

* This manual has been prepared on the ba-

sis of the latest specifications at the time of

publication. If modifications have been made

since then, differences may exist between

the content of this manual and the actual

motorcycle.

* Illustrations in this manual are used to show

the basic principles of operation and work

procedures. They may not represent the

actual motorcycle exactly in detail.

* This manual is written for persons who have

enough knowledge, skills and tools, includ-

ing special tools, for servicing SUZUKI mo-

torcycles. If you do not have the proper

knowledge and tools, ask your authorized

SUZUKI motorcycle dealer to help you.

Inexperienced mechanics or mechanics with-

out the proper tools and equipment may not

be able to properly perform the services de-

scribed in this manual. Improper repair may

result in injury to the mechanic and may ren-

der the motorcycle unsafe for the rider and

passenger.

Motorcycle Service Department

GROUP INDEX

GENERAL INFORMATION 1

PERIODIC MAINTENANCE 2

ENGINE 3

FUEL AND LUBRICATION 4

SYSTEM

CHASSIS 5

ELECTRICAL SYSTEM 6

SERVICING INFORMATION 7

HOWTO USETHIS MANUAL

TO LOCATEWHATYOU ARE

LOOKING FOR:

1. The text of this manual is divided into sections.

2. The section titles are listed in the GROUP INDEX.

3. Holding the manual as shown at the right will al-

low you to find the first page of the section easily.

4. The contents are listed on the first page of each

section to help you find the item and page you

need.

COMPONENT PARTS AND WORKTO BE DONE

Under the name of each system or unit, is its exploded view.Work instructions and other service information

such as the tightening torque, lubricating points and locking agent points, are provided.

Example: Front wheel

1Front axle

2Spacer

3Dust seal

4Bearing

5Spacer

6Front wheel

7Speedometer gearbox

8Brake disc

AFront axle nut

BBrake disc bolt

ITEM N.m kgf.m

A42 4.2

B23 2.3

SYMBOL

Listed in the table below are the symbols indicating instructions and other information necessary for servic-

ing. The meaning of each symbol is also included in the table.

SYMBOL DEFINITION

"Torque control required.

Data beside it indicates specified

torque.

#Apply oil. Use engine oil unless

otherwise specified.

$Apply SUZUKI SUPER GREASE

“A”.

99000-25010

%Apply SUZUKI SILICONE

GREASE.

99000-25100

&Apply SUZUKI MOLY PASTE.

99000-25140

'Apply THERMO GREASE.

99000-25300

(Apply SUZUKI BOND “1215”.

99000-31110

)Apply THREAD LOCK “1322”.

99000-32110

*Apply THREAD LOCK “1342”.

99000-32050

+Apply THREAD LOCK SUPER

“1360”.

99000-32130

SYMBOL DEFINITION

,Apply or use brake fluid.

-Measure in voltage range.

.Measure in resistance range.

/Measure in current range.

0Measure in diode test range.

1Measure in continuity test range.

2Use special tool.

3Use fork oil.

99000-99044-10G

4Indication of service data.

GENERAL INFORMATION

CONTENTS

WARNING/CAUTION/NOTE...................................................................1- 2

GENERAL PRECAUTIONS ...................................................................1- 2

SUZUKI UG110Y (2000-MODEL) ..........................................................1- 4

SERIAL NUMBER LOCATION...............................................................1- 4

FUEL AND OIL RECOMMENDATIONS .................................................1- 4

FUEL................................................................................................1- 4

ENGINE OIL ....................................................................................1- 5

FINAL GEAR OIL ............................................................................1- 5

BRAKE FLUID.................................................................................1- 5

FRONT FORK OIL...........................................................................1- 5

BREAK-IN PROCEDURES ....................................................................1- 5

INFORMATION LABELS........................................................................1- 6

SPECIFICATIONS ..................................................................................1- 7

COUNTRY AND AREA CODES.............................................................1- 9

GENERAL INFORMATION 1-1

1-2 GENERAL INFORMATION

WARNING/CAUTION/NOTE

Please read this manual and follow its instructions carefully. To emphasize special information, the symbol

and the words WARNING, CAUTION and NOTE have special meanings. Pay special attention to the mes-

sages highlighted by these signal words.

Indicates a potential hazard that could result in death or injury.

Indicates a potential hazard that could result in motorcycle damage.

NOTE:

Indicates special information to make maintenance easier or instructions clearer.

Please note, however, that the warnings and cautions contained in this manual cannot possibly cover all

potential hazards relating to the servicing, or lack of servicing, of the motorcycle. In addition to the WARN-

INGS and CAUTIONS stated, you must use good judgement and basic mechanical safety principles. If you

are unsure about how to perform a particular service operation, ask a more experienced mechanic for

advice.

GENERAL PRECAUTIONS

* Proper service and repair procedures are important for the safety of the service mechanic and

the safety and reliability of the motorcycle.

* When two or more persons work together, pay attention to the safety of each other.

* When it is necessary to run the engine indoors,make sure that exhaust gas is forced outdoors.

* When working with toxic or flammable materials, make sure that the area you work in is well

ventilated and that you follow all of the manufacturer’s instructions.

* Never use gasoline as a cleaning solvent.

* To avoid getting burned, do not touch the engine, engine oil and exhaust system until they

have cooled.

* After servicing fuel, oil, exhaust or brake systems, check all of the lines and fittings related to

the system for leaks.

GENERAL INFORMATION 1-3

* If parts replacement is necessary, replace the parts with Suzuki Genuine Parts or their equiva-

lent.

* When removing parts that are to be reused, keep them arranged in an orderly manner so that

they may be reinstalled in the proper order.

* Be sure to use special tools when instructed.

* Make sure that all parts used in reassembly are clean. Lubricate them when specified.

* Use the specified lubricant, bond, or sealant.

* When removing the battery, disconnect the --

-battery lead wire first, and then the ++

+battery

lead wire.

* When reconnecting the battery, connect the ++

+battery lead wire first, then the --

-battery lead

wire. Finally, cover the ++

+battery terminal with the terminal cover.

* When performing service to electrical parts, disconnect the --

-battery lead wire, unless the

service procedure requires the battery power.

* When tightening cylinder head and crankcase bolts and nuts, tighten the larger sizes first.

Always tighten the bolts and nuts from the inside working out, diagonally and to the specified

tightening torque.

* Whenever you remove oil seals, gaskets, packing, O-rings, self-locking nuts, locking washers,

cotter pins, circlips, and certain other parts as specified, be sure to replace them with new

ones. Also, before installing these new parts, be sure to remove any left over material from the

mating surfaces.

* Never reuse a circlip.When installing a new circlip, take care not to expand the end gap larger

than required to slip the circlip over the shaft. After installing a circlip, always ensure that it is

completely seated in its groove and securely fitted.

* Use a torque wrench to tighten fasteners to the specified torque.Wipe off grease and oil if a

thread is smeared with them.

* After reassembling, check parts for tightness and proper operation.

* To protect the environment, do not unlawfully dispose of used motor oil, batteries, and tires.

* To protect the earth’s natural resouces, properly dispose of used motorcycles and parts.

1-4 GENERAL INFORMATION

SUZUKI UG110Y (2000-MODEL)

SERIAL NUMBER LOCATION

The frame serial number or V.I.N. (Vehicle Identification Number) 1is stamped on the right side of the

frame. The engine serial number 2 is located on the end of the crankcase. These numbers are required

especially for registering the machine and ordering spare parts.

FUEL AND OIL RECOMMENDATIONS

Be sure to use the specified fuel and oils. Fuel and oil specifica-

tions are listed below.

FUEL

Use unleaded gasoline that is graded 91 octane or higher rated

by the Reserch Method.

RIGHT SIDE LEFT SIDE

* Difference between photographs and the actual motorcycles depends on the markets.

1Fuel tank cap

GENERAL INFORMATION 1-5

FINAL GEAR OIL

Use a good quality SAE 10W/40 multi-grade motor oil.

BRAKE FLUID

,Specification and classification: DOT 4

* This motorcycle uses a glycol-based brake fluid. Do not use or mix different types of brake

fluid such as silicone-based and petroleum-based fluids for refilling the system, otherwise

serious damage will result to the brake system.

* Never use any brake fluid taken from old, used, or unsealed containers.

* Never reuse brake fluid left over from a last servicing or which has been stored for a long

period of time.

FRONT FORK OIL

Use SUZUKI FORK OIL G10 (#10) or an equivalent fork oil.

BREAK-IN PROCEDURES

During manufacturing only the best possible materials are used and all machined parts are finished to a

very high standard. It is still necessary to allow the moving parts to “BREAK-IN”before subjecting the engine

to maximum stresses.The future performance and reliability of the engine depends on the care and restraint

exercised during its early life. Refer to the following throttle position recommendations.

•Keep to these break-in throttle positions.

Initial 800 km (500 miles) : Less than 1/2 throttle

Up to 1 600 km (1 000 miles): Less than 3/4 throttle

•Upon reaching an odometer reading of 1 600 km you can subject the motorcycle to full throttle operation

for short periods of time.

ENGINE OIL

Use only SUZUKI CCI SUPER OIL or an equivalent premium

quality 2-stroke synthetic engine oil. Use only oils which are rated

FC under the JASO classification.

1Engine oil tank cap

1-6 GENERAL INFORMATION

INFORMATION LABELS

1Warning safety label

2Engine starting label

3Warning screen label

4Tire pressure label

5Fuel caution plate (For E-02)

6Loading capacity label

7Anti-tampering label

8ID plate

10 mm

10 mm 1mm

Inhaltsverzeichnis

Andere Suzuki Motorrad Handbücher

Suzuki

Suzuki FA50 Bedienungsanleitung

Suzuki

Suzuki GSX 400F Bedienungsanleitung

Suzuki

Suzuki GSXR-1100 1990 Bedienungsanleitung

Suzuki

Suzuki PE250 Bedienungsanleitung

Suzuki

Suzuki GZ250 Marauder Bedienungsanleitung

Suzuki

Suzuki GSX650FA Bedienungsanleitung

Suzuki

Suzuki RGV250 1989 Bedienungsanleitung

Suzuki

Suzuki GSX1250FA Bedienungsanleitung

Suzuki

Suzuki V-Storm DL650A Bedienungsanleitung

Suzuki

Suzuki DR650S Bedienungsanleitung

Suzuki

Suzuki SV 650 2016 Bedienungsanleitung

Suzuki

Suzuki V-Storm DL650A Bedienungsanleitung

Suzuki

Suzuki GSF 400 BANDIT Bedienungsanleitung

Suzuki

Suzuki 2005 GSF1200 Bedienungsanleitung

Suzuki

Suzuki DL1000AL4 Bedienungsanleitung

Suzuki

Suzuki VL125 Bedienungsanleitung

Suzuki

Suzuki GSX1400 Bedienungsanleitung

Suzuki

Suzuki T250 Bedienungsanleitung

Suzuki

Suzuki PE175 Bedienungsanleitung

Suzuki

Suzuki RM250 Anwendungshandbuch

Suzuki

Suzuki GSX1200 1999 Bedienungsanleitung

Suzuki

Suzuki DF25A 2014 Bedienungsanleitung

Suzuki

Suzuki GS550 Bedienungsanleitung

Suzuki

Suzuki shogun sports 125 Bedienungsanleitung

Beliebte Motorrad Handbücher anderer Marken

OHVALE

OHVALE GP-0 Stücklistenhandbuch

Yamaha

Yamaha Star XV19CTSZ 2009 Bedienungsanleitung

KTM

KTM 350 XCF-W USA Bedienungsanleitung

HYOSUNG

HYOSUNG ST7 Bedienungsanleitung

Husqvarna

Husqvarna FC 250 2016 Bedienungsanleitung

Ducati

Ducati SCRAMBLER 800 Gebrauchsanweisung

MOTO GUZZI

MOTO GUZZI QUOTA 1100 ES Bedienungsanleitung

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Bedienungsanleitung

Yamaha

Yamaha 2006 YZF-R1V Bedienungsanleitung

KTM

KTM Freeride E-XC 2021 Bedienungsanleitung

Fantic

Fantic Enduro 125 Bedienungsanleitung

Ducati

Ducati Supersport 750 desmodue Bedienungsanleitung

MV Agusta

MV Agusta 2008 F4 312RR 1078 Gebrauchsanweisung

Yamaha

Yamaha XVS650A Bedienungsanleitung

Yamaha

Yamaha YZF-R6T(C) Handbuch

Ducati

Ducati 748 monoposto strada Bedienungsanleitung

ATK

ATK 1988 250 Bedienungsanleitung

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Bedienungsanleitung
