USER’S MANUAL
Web Camera with Headset
ICH-3500
1
User’s Manual
ENG
2
2
2
2
3
3
4
Congratulations on your purchase of the Sven web camera!
Please read this Operation Manual before using the unit and retain this
Operation Manual in a safe place for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information of this Manual is given on “as is”
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. SAFETY PRECAUTIONS ..............................................
2. PACKAGE CONTENTS ................................................
3. SPECIAL FEATURES ...................................................
4. SYSTEM REQUIREMENTS ...........................................
5. CONNECTION AND INSTALLATION ................................
6. DESCRIPTION ..........................................................
7. TECHNICAL SPECIFICATIONS ......................................
Technical support: www.sven.fi
ICH-3500
1. SAFETY PRECAUTIONS
•Protect your web camera from high humidity, dust or high temperatures.
•Do not use gasoline, spirit or other dissolvents for cleaning. This may
cause damage to the surface. Clean the outside of the camera with dry soft
cloth.
•Avoid causing mechanical damage to the device.
•Do not attempt to disassemble or repair your device yourself.
2. PACKAGE CONTENTS
•Web camera – 1 pc
•Headset – 1 pc
•User’s Manual – 1 pc
•Warranty card – 1 pc
3. SPECIAL FEATURES
•Adjustable focal distance
•Comfortable mounting clip for camera fixation on a desktop, laptop, LCD
monitor
•Ball-type hinge for camera rotation
•Plug&Play
•Adjustable headband
•Flexible microphone holder
•Comfortable embouchures
4. SYSTEM REQUIREMENTS
•Windows XP/Vista/7/8
•Pentium P4 1.4GHz or AMD Athlon 1GHz
•128 MB RAM
•Video adapter 24-bit color
•Available USB port
2
ENG
Web Camera with Headset
f
j
k
l
i
g
h
5. CONNECTION AND INSTALLATION
•Connect the web camera to an avail-
able USB port.
•This web camera supports Plug and
Play technology. Installation of the de-
vice is automatic after its connection to
the USB port.
•Connect stereo headset to PC as
follows: plug headphones cable mini-
jack (k, green) into PC headphones
socket, and microphone cable mini-
jack (l, orange) connect to PC micro-
phone input.
6. WEB CAMERA WITH HEADSET
DESCRIPTION
aFocus
bLenses
cBall-type hinge
dHinge
eMounting clip
fAdjustable headband
gМicrophone
hFlexible microphone holder
iEmbouchures
jVolume control knob
kHeadphones cable mini-jack
lMicrophone cable mini-jack
d
c
e
b
a
Fig. 1. Web Camera
Fig. 2. Headset
3
ENG
User’s Manual ICH-3500
Notes:
• Technical specifications given in this table are supplemental information
and can not give occasion to claims.
• Technical specifications are subject to change without notice due to imp-
rovement of SVEN production.
7. TECHNICAL SPECIFICATIONS
Parameter, unit
Sensor type
Resolution, pix
Frame rate, frames/sec
Focus distance, mm
Weight, g
Impedance, Ω
Sensitivity, dB/1 kHz
Frequency response, Hz
Max. output power, mW
Jack type, mm
Module dimensions, mm
Directional selectivity
Response level of microphone, dB
Frequency response of mic-phone, Hz
Cable length, m
Weight, g
Value
CMOS
640 × 480
up to 30 fps for 640 × 480
8 to infinity
77
32
105
20 – 20,000
100
Ø 3.5 mini-jack
9 × 7
omnidirectional (360°)
–58 ± 3
30 – 16,000
2
72
Web Camera
Headset
4
ENG
Web Camera with Headset
Модель: ICH-3500
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
