Swann AMU Rescon Bedienungsanleitung
AMU Rescon
Version 6.20 and higher
A-96.250.351 / 230320
Operator’s Manual
© 2019, SWAN ANALYTISCHE INSTRUMENTE AG, Switzerland, all rights reserved
subject to change without notice
.
Customer Support
SWAN and its representatives maintain a fully trained staff of technical specialists
around the world. For any technical question, contact your nearest
SWAN representative, or the manufacturer:
SWAN ANALYTISCHE INSTRUMENTE AG
Studbachstrasse 13
8340 Hinwil
Switzerland
Internet: www.swan.ch
E-mail: [email protected]
Document Status
Title: AMU Rescon Operator’s Manual
ID: A-96.250.351
Revision Issue
00 March 2007 First Edition
01 June 2019 Update to firmware V6.20
AMU Rescon
A-96.250.351 / 230320 1
Table of Contents
1. Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1. Warning Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2. General Safety Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3. Restrictions for use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1. Description of the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2. Single Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2.1 AMU Rescon Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2.2 Flow Cell QV-Flow and QV-HFlow SS316L 130 . . . . . . . . . . . . 11
2.2.3 Flow Cell B-Flow SS316L 130 . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.4 Swansensor RC U . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3. Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1. Installation Checklist Monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2. Dimensions of the AMU Transmitter. . . . . . . . . . . . . . . . . . . . . . . 15
3.3. Connecting Sample Inlet and Outlet . . . . . . . . . . . . . . . . . . . . . . . 16
3.3.1 Sample Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3.2 Sample Outlet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.4. Install Sensor RCU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.5. Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.6. Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.7. Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.8. Flow Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.9. Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.10. Relay Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.10.1 Alarm Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.10.2 Relay 1 and 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.11. Signal Output 1 and 2 (current outputs) . . . . . . . . . . . . . . . . . . . . 22
3.12. Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.12.1 RS232 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.12.2 Profibus (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.12.3 Modbus (optional). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4. Instrument Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.1. Establish Sample Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.2. Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2A-96.250.351 / 230320
AMU Rescon
5. Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.1. Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.2. Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.3. Software Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.4. Changing Parameters and values. . . . . . . . . . . . . . . . . . . . . . . . . 30
6. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.1. Maintenance Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.2. Stop of Operation for Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 31
6.3. Maintenance of Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.3.1 Clean Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.4. Conductivity-Resistivity QC-Kit Test Plug . . . . . . . . . . . . . . . . . . . 35
6.4.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.4.2 Carry out a transmitter check . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.5. Fine Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.6. Longer Stop of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7. Error List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8. Program Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8.1. Messages (Main Menu 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8.2. Diagnostics (Main Menu 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.3. Maintenance (Main Menu 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.4. Operation (Main Menu 4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.5. Installation (Main Menu 5). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
9. Program List and Explanations . . . . . . . . . . . . . . . . . . . . . . . . . 47
1 Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
2 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
10. Default Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
11. Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
12. Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
AMU Rescon
Safety Instructions
A-96.250.351 / 230320 3
AMU Rescon–Operator’s Manual
This document describes the main steps for instrument setup, oper-
ation and maintenance.
1. Safety Instructions
General The instructions included in this section explain the potential risks
associated with instrument operation and provide important safety
practices designed to minimize these risks.
If you carefully follow the information contained in this section, you
can protect yourself from hazards and create a safer work environ-
ment.
More safety instructions are given throughout this manual, at the
respective locations where observation is most important.
Strictly follow all safety instructions in this publication.
Target
audience
Operator: Qualified person who uses the equipment for its intended
purpose.
Instrument operation requires thorough knowledge of applications,
instrument functions and software program as well as all applicable
safety rules and regulations.
OM Location The Operator’s Manual shall be kept in proximity of the instrument.
Qualification,
Training
To be qualified for instrument installation and operation, you must:
read and understand the instructions in this manual as well as
the Material Safety Data Sheets.
know the relevant safety rules and regulations.
4A-96.250.351 / 230320
AMU Rescon
Safety Instructions
1.1. Warning Notices
The symbols used for safety-related notices have the following sig-
nificance:
DANGER
Your life or physical wellbeing are in serious danger if such
warnings are ignored.
Follow the prevention instructions carefully.
WARNING
Severe injuries or damage to the equipment can occur if such
warnings are ignored.
Follow the prevention instructions carefully.
CAUTION
Damage to the equipment, minor injury, malfunctions or incor-
rect process can be the consequence if such warnings are ig-
nored.
Follow the prevention instructions carefully.
Mandatory
Signs
The importance of the mandatory signs in this manual.
Safety goggles
Safety gloves
AMU Rescon
Safety Instructions
A-96.250.351 / 230320 5
Warning Signs The importance of the warning signs in this manual.
1.2. General Safety Regulations
Legal
Requirements
The user is responsible for proper system operation.
All precautions must be followed to ensure safe operation of the in-
strument.
Spare Parts
and
Disposables
Use only official SWAN spare parts and disposables. If other parts
are used during the normal warranty period, the manufacturer’s
warranty is voided.
Electrical shock hazard
Corrosive
Harmful to health
Flammable
Warning general
Attention general
6A-96.250.351 / 230320
AMU Rescon
Safety Instructions
Modifications Modifications and instrument upgrades shall only be carried out by
an authorized Service Technician. SWAN will not accept responsi-
bility for any claim resulting from unauthorized modification or alter-
ation.
WARNING
Electrical Shock Hazard
If proper operation is no longer possible, the instrument must be
disconnected from all power lines, and measures must be taken
to prevent inadvertent operation.
To prevent from electrical shock, always make sure that the
ground wire is connected.
Service shall be performed by authorized personnel only.
Whenever electronic service is required, disconnect instru-
ment power and power of devices connected to.
– relay 1,
– relay 2,
– alarm relay
WARNING
For safe instrument installation and operation you must read
and understand the instructions in this manual.
WARNING
Only SWAN trained and authorized personnel shall perform the
tasks described in this document.
1.3. Restrictions for use
The AMU Rescon is designed for determination of specific conduc-
tivity or resistivity in high purity water.
To avoid clogging the flow cell, prevent sand, oil or solids, from en-
tering into the flow cell.
Sufficient sample flow is coercive for the correct function of the in-
strument. To determine values near 18.18 MOhm-cm exactly, a
sample flow of 70–100 l/h is needed.
AMU Rescon
Product Description
A-96.250.351 / 230320 7
2. Product Description
2.1. Description of the System
This instrument is applicable for the determination of specific resis-
tivity or specific conductivity in high purity water.
Measuring
Principle
The resistivity of high purity water is determined with a sensor con-
sisting of two metal electrodes. The characteristics of each sensor
is expressed as cell constant. An alternating voltage (to minimize
polarization effects) is applied to two electrodes. Depending on the
concentration of ions in the sample, a signal results between the
electrodes which is proportional to the resistivity of the water.
The measuring result is indicated as resistivity or conductivity. The
conductivity measurement depends on temperature, as the mobility
of ions increase with rising temperature. To eliminate these effects,
the temperature is determined simultaneously with an incorporated
NT5K temperature sensor. Several temperature compensation
curves for different applications are available.
Signal
Outputs
Two signal outputs programmable for measured values (freely scal-
able, linear, bilinear, log) or as continuous control output (control
parameters programmable).
Current loop: 0/4–20 mA
Maximal burden: 510 Ω
Relays Two potential-free contacts programmable as limit switches for
measuring values, controllers or timer for system cleaning with au-
tomatic hold function.
Maximum load: 100 mA/50 V
Alarm Relay One potential free contact. Summary alarm indication for program-
mable alarm values and Instrument faults.
Available in two configurations:
Normally open*: Closed during normal operation, open in case of
error or power loss.
Normally closed: Open during normal operation, closed in case
of error or power loss
*Standard configuration. To order the version with normally closed
alarm relay, contact your dealer in advance.
Maximum load: 100 mA / 50 V
8A-96.250.351 / 230320
AMU Rescon
Product Description
Input One input for potential-free contact to freeze the measuring value
or to interrupt control in automated installations (hold function or re-
mote-off).
Communica-
tion interface
(optional)
RS232 for logger download with HyperTerminal
RS485 with Fieldbus protocol Modbus or Profibus DP (optional)
Safety
Features
No data loss after power failure. All data is saved in non-volatile
memory.
Over voltage protection of in- and outputs.
Galvanic separation of measuring inputs and signal outputs.
USP
Operating
Mode
The USP Operating Mode implemented in the firmware of the AMU
Rescon transmitter allows the measurement of pharmaceutical wa-
ter according to the USP <645>.
If the USP Operating Mode is set to <off>, conductivity or resistivity
standard measurement with automatic temperature compensation
is performed.
If the USP Operating Mode ils set to <on>, the temperature com-
pensation function is disabled. The uncompensated measuring val-
ues are compared with the values of an implemented table defined
by USP (see table below). If the deviation of the measured values
is too high, the Error 15 (USP Error) is issued.
Conductivity
QC-Kit Test
Plug
The implemented Transmitter Test together with Conductivity QC-
Kit Test Plug containing a traceable high precision resistor allows to
perform a verification of the measuring electronics at any time.
Fluidics The flow cell QV-Hflow consists of the flow cell block [D], the flow
sensor [B] and the flow regulating valve [E].
Temperature [°C] Conductivity [S/cm] Temperature [°C] Conductivity [S/cm]
0 0.6 55 2.1
5 0.8 60 2.2
10 0.9 65 2.4
15 1.0 70 2.5
20 1.1 75 2.7
25 1.3 80 2.7
30 1.4 85 2.7
35 1.5 90 2.7
40 1.7 95 2.9
45 1.8 100 3.1
50 1.9
Inhaltsverzeichnis
Andere Swann Controller Handbücher
