Sylvania SMPK2077 Bedienungsanleitung

- 1 -

User Manual

Model number: SMPK2077

- 2 -

The MP3 player is a brand-new generation of digital portable device, supporting MP3/WAV music

format ,voice recorder，AMV format play ,JPEG photograph browse and E-book text reading .Its perfect

sound quality, great reliability and exquisite appearance make it a masterpiece. Devoutly hope to bring

you great enjoyment in this digital era.

Unique Features

●Exquisite Appearance

Unique appearance designed and comfortable for handling

●Multi-Codec Player

e.g.: MP1, MP2, MP3, WMA, WMV, ASF and WAV Music format

●Firmware Upgrade

Providing the latest updated features via firmware upgrade from the website (www.curtisint.com)

●Drive Free U Disk

You may manage your files directly through “Portable Disk” in “My Computer” on Winows2000

Operating System or above without driver.

●“Private Space” Disk Mode

The flash memory can be divided into two parts by using the accessory tools and one is encrypted to

hide the contents saved inaccessible by others. Keep Your Secret!

●Record/ Replay

The player supports recording through built-in microphone and saves as WAV and ACT formats.

Meanwhile it supports real digital A-B replay or comparison replay.

●7 Preset EQ

Normal, Rock, Pop, Classic, Soft, Jazz and DBB

●Multi-play Mode

Normal, Repeat One, Folder, Repeat Folder, Repeat All, Random, Intro.

●Power Off

You may set Sleep Timer or Off Time mode in your own convenience.

Declaration

Thank you for your purchase.

Please read this manual carefully before using your new player.

Contents in this manual may change possibly for better service.

We have the right to make changes to this manual without notice.

- 3 -

If the actual operations of your player are not the same as the instruction in this manual, please

visit (www.curtisint.com) for latest product information.

1. Locating the Controls

zAppearance & Keys

zLCD Window

S/N Description S/N Description

1 Menu button (Enter/ Return) 6 Power switch

2 Vol/ Hold key(Lock) 7 LCD display

3 Play/Stop 8 USB

4 Previou track/Rewind()/VOL- 9 Earphone head

5 Next track/Forward()/VOL+

- 4 -

zBattery

The player is in multilevel level battery monitoring system.

Indicates that battery is 3.6V and the power in battery will become less when using.

Indicates low battery power and battery should be charged up.

Basic Operation

zEntering Menu System

Pressing M button may enter the menu system, including main menu (long press M button

at Stop state), submenu at Play state (press M button to enter) and submenu at stop state (press M

button to enter).

zBrowsing

○Browsing music files or menu options:

Short press < / > button

○Fast forward or fast backward when playing：

Longpress< / > button

zEntering Different Modes

You may enter different modes from the main menu.

zVolume Control

At the music mode, voice mode, short press Vbuttons to enter the volume control interface

and then press the < / > button to adjust volume (follow along with number of volume value be

Main menu:

(Long press the M

button to enter )

Moviemode:

Music mode:

Record mode:

Voice mode:

E-Book: Photo System setting GAME：

Remark: Long press M button to return to the main menu at the modes. When connecting the USB cable to

PC, then will enter USB mode.

- 5 -

changed).

zPower On/Off

1．Turn on by Power switch

After push the Power switch ( OFF→ON) , the player turn on automatically and enter

power on “SYLVANIA” logo interface:

When connecting the USB plug to PC, the player turn on automatically and will be entering

USB mode：

2．Turn ON/Off by Play button,, after power switch to ON;

♦when the player is in OFF mode, long press Play button to turn on

♦when the player is in ON model ,long press Play button to turn off

Play Music

zBasic Operation

1. Connect the earphone to the player 2.Turn on “POWER SWITCH”

3. then enter the main menu:

4.press M button to enter the Music mode:

5. Short press the PLAY button to play

music

6. Choose music

>button：to choose previous music.

>button：to choose next music.

7. Volume control (Press V)

press the < / > button to adjust volume.

zEQUALIZER Mode

1.When playing music

2.Press the Mbutton to enter Play Submenu

3. select the ‘Equalizer’ and press MENU

button to conform.

4.choose the EQ that you want from 7 kinds

by press MENU button

- 6 -

zLyric Display

This player supports “*.LRC” lyric files, and lyrics may be synchronous displayed while playing

music.

yHow to use lyric files?

Save the lyric file with the same name as that of the corresponding music file.

For example.: Music file name: GiGi-Sky.mp3

Lyric file name: GiGi-Sky.mp3.

yHow to know whether the lyrics exist?

If the current song has matching lyric files, the lyric sign will be display at the top of music mode.

1. Current song has matching lyric files

2. Long press Mto enter the Lyric Interface

when playing.

3. Press Mbutton to return to Music

play mode.

4. Browse lyrics manually.

Movie mode

1. Enter the main menu and press the > button to select “MOVIE” mode.

2. Press the M to enter.

3. press the PLAY to start playing AMV files

4. Choose movie

<button：to choose previous file.

> button：to choose next music file.

5. Volume control

1) Press V

2) Press < / > to adjust volume level.

Voice Recording

Make sure that the battery is not in the status of “low battery”.

zRecording in Record Mode

- 7 -

1. At the main menu.

2. Press >button to choose recording mode.

4. Press Play button to start recording.

5. Press Play button again to pause recording.

6.Press Play button to continue recording.

7.Long press Play button to stop recording.

3. Press M button to enter Record mode

zSelect REC type

1. At the record mode stop interface：

2. Press Mbutton to enter record submenu

3. Press > button to select “REC type” option

5. Press > button to select desired recording

type

6. Press Mto confirm the type selected

7. Press PLAY button to start recording

4. Press M button enter this option

Playback Files

1.Enter the main menu

2. Press >button to choose “Voice mode”

3.Press Mbutton to enter Voice mode 4. Press PLAY button to start playing.

yREC type：

- 8 -

Besides the conversion from

ACT to WAV, the accessory

tool can also play WAV and

MP3 files.

5. Choose music

<button：to choose previous record file

>button：to choose next record file.

interface

6. Volume control

1、Press V

2、Press < / > to adjust volume level.

Convert ACT format files to WAV format files

The ACT format files can be converted to WAV format files through the accessory installation tools.

1. Run “Sound Convert Tool” program, and click “Open” button.

2. Choose the ACT format files need conversion

4. Click the “Convert” button, the conversion starts


1、Entering the main menu.

2、Push the “>” buttons to choose “Photo”

3、Long press “M” buttons to enter the “Photo”

- 9 -

System Setting

System parameters can be set here and every option varies according to firmware upgrading

At the menu, press >to select the “Setup”:

Press M button to System Setting interface is as follows:

zParameters Introduction

Clock (Date &

time) set the date and time when recorded files are saved

LCD set set the period of time (second) when Backlight stays on without any

operation

Language Set different language displayed

Power off Set a fixed time after which the player may turn power off automatically

Replay mode Set working states on Replay mode

Online device MTP and USB Disk setting

Online Mode an option specially designed for “Private Space” function

Memory info. Show memory capacity and percentage that has been used

Firmware Version show firmware version

Firmware

Upgrade special for firmware upgrading

DRM time Greenwich Mean TIME

Remove MTP

info Exit MTP mode

Exit Exit from current interface

zInstruction

○“Date & time” set

1. System Setting Interface

2. Press Mto enter Record Time Interface.

3. Press Vto set time in sequence of

“YY-MM-DD”

4. Push < / > button to adjust numbers

5. Press M to confirm and exit.

○“LCD set” setting

Operating steps is as follows:

1．At System Setting interface,

2. Press > key to select “LCD set” option,

- 10 -

3．Press Mbutton to enter “LCD set”

submenu:

4．Press M button to choose ‘Brightness

screen savers’

5. Press < / > button to adjust time（Unit：second），and press M to confirm and exit.

Black screen mode

Set fixed period of time (unit: second) when no operation on keys , the player may turn black

screen automatically. If “0” is selected, function is invalid.

○“Language” setting

1. At System setting interface, press < / >

button to select “Language” icon:

2. Press M button to enter “Language”

setting interface:

3. Press < / > button to select desired

language. 4. Press Mto confirm to exit.

Language lists as follows :( maybe add more language)

English

French

German

Italian

Spanish

Portuguese

Dutch

Turkish

○Power saving

Operating steps refer to Language setting.

Off Time mode refers that after a fixed period of time (unit: second) when no operation on keys at

Stop mode, the player may turns off automatically to save power. If “0” is selected, power saving

function is invalid.

Sleep Time refers that you may set a fixed period of time (unit: minute) for the player to turn off

automatically when no keys operation no matter which mode it is at any state. This function is

specially designed for listening to music before sleep. Note: Setting of Sleep Timer is valid only once

and the set time will be cleared after power off. The time needs to be set again next time.

○Replay Mode
