GUIDE TO THE

PTC-710

Guide to the

PTC-710

Part Number: 13977-000-03-004

Release Date: Nov. 2000

Symbol is a registered trademark of Symbol Technologies,

Inc.

The information contained in this manual is subject to

change without notice.

Symbol shall not be liable for technical or editorial omis-

sions or mistakes in this manual nor shall it be liable for inci-

dental or consequential damages resulting from your use of

the information contained in this manual.

This manual contains confidential and proprietary informa-

tion and is copyrighted. All rights are reserved. No part of

this manual may be photocopied or reproduced in any form

without the prior written consent of Symbol.

Contents

Unpacking the PTC-710.............1

Before You Use the PTC-710..........2

Charge the Nickel-Cadmium Batteries.......2

Turn on the Backup Battery............3

Overview of the PTC-710............5

Parts.......................6

Display.......................6

Keyboard......................6

Internal Modem (Optional).............6

RJ-11 Socket (Optional)..............8

Bar-Code Reader and Holder (Optional)......8

Bar-Code Reader Socket..............8

25-Pin Connector..................8

Acoustic Coupler..................8

Elastic Strap....................9

Batteries......................9

Application ROM Cartridge (ARC)........10

Features....................11

Power Backup System..............11

Clock and Calendar................11

Automatic Off...................11

Automatic Return At On.............11

Handling and Maintaining

the PTC-710.....................12

Use and Storage..................12

Cables and Accessories..............12

Cleaning......................13

Service.......................13

...........................13

Replacing Alkaline Batteries.........14

The PTC-710 / i

To Remove the Batteries:.............14

To Replace the Batteries:.............15

Charging Nickel-Cadmium Batteries.....16

Connecting and Removing

Accessories.....................17

To Connect an Accessory:............17

To Remove an Accessory:............18

Scanning Bar-Code Labels..........19

Attaching the Acoustic Coupler

to a Telephone Receiver ..............20

Connecting the Internal Modem

to a Telephone Line................21

Troubleshooting................22

If the PTC Does Not Start:............22

If the PTC Shows the Message “BACKUP BAT-

TERY FAULT”:....................22

If the Bar-Code Reader Does Not Read a Label: 22

Regulations..................23

FCC (United States)................23

Department of Communications (Canada)....23

ii/ The PTC-710

Unpacking the PTC-710

When you receive the PTC-710, the package should contain

the following:

•PTC-710

•battery charger (if the PTC-710 was ordered with

nickel-cadmium batteries)

•bar-code reader (if ordered)

The PTC-710 / 1

Before You Use the PTC-710

Charge the Nickel-Cadmium Batteries

Follow these steps only if your PTC-710 contains

nickel-cadmium batteries.

CAUTION! Do not connect a battery charger to a

PTC-710 that contains alkaline batteries. Attempting to

charge alkaline batteries can cause them to burst, which

can result in equipment damage.

1. Connect the battery charger to the PTC-710’s 25-pin

connector (see Figure 1).

2. Plug the battery charger into a standard 110-volt electri-

cal outlet. The charger’s red indicator light shows that

the batteries are charging.

Note: 220-volt outlets, used outside North America,

require a different battery charger than that shown in

2/ The PTC-710

Figure 1. Connecting the Battery Charger

Figure 1; see your Symbol sales representative for order-

ing information.

3. Allow the batteries to charge for 12 to 14 hours. After-

ward, unplug the battery charger from the electrical out-

let, then disconnect it from the PTC.

Turn on the Backup Battery

1. Remove the battery compartment cover by inserting a

coin in the slot at the bottom of the battery compartment

cover and applying light pressure to the coin (see Figure

2). The cover will pop up.

2. Using the tip of a pen or pencil, depress the backup battery

switch (see Figure 3).

3. Replace the battery compartment cover. Line up the bat-

tery compartment cover so the recessed edge on the top

of the cover is under the flange of the PTC’s case. Press

down lightly on the cover until it snaps into place.

The PTC-710 / 3

Figure 2. Removing the Battery Compartment

Cover

4/ The PTC-710

Figure 3. Turning on the Backup Battery

PRESS

DOWN

BACKUP BATTERY

SWITCH
