PN 53-0082 Rev C 02/22

• The lightning ash with arrowhead

symbol within an equilateral triangle is

intended to alert the user of the presence

of uninsulated “dangerous voltage”

within the product’s enclosure that may

be of su󰀩cient magnitude to constitute

a risk of electric shock to persons. The

exclamation point within an equilateral

triangle is intended to alert the user of

the presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the product (i.e.

this Quick Start Guide).

• CAUTION: To prevent electric shock,

do not use the polarized plug supplied

with the device with any extension cord,

receptacle, or other outlet unless the

prongs can be fully inserted.

• Power Source: This Symetrix hardware

uses a universal input supply that

automatically adjusts to the applied

voltage. Ensure that your AC mains

voltage is somewhere between 100-240

VAC, 50-60 Hz. Use only the power

cord and connector specied for the

product and your operating locale. A

protective ground connection, by way of

the grounding conductor in the power

cord, is essential for safe operation. The

appliance inlet and coupler shall remain

readily operable once the apparatus has

been installed.

• User Serviceable Parts: There are no

user serviceable parts inside this Symetrix

product. In case of failure, customers

inside the U.S. should refer all servicing to

the Symetrix factory. Customers outside

the U.S. should refer all servicing to an

authorized Symetrix distributor. Distributor

contact information is available online at:

http://www.symetrix.co.

AVIS:

NE PAS OUVRIR

Il ne se trouve a l’interieur aucune piece pourvant entre reparée l’usager.

SEE OWNERS MANUAL. VOIR CAHIER D’INSTRUCTIONS.

S’adresser a un reparateur compétent.

RISQUE DE CHOC ELECTRIQUE

No user serviceable parts inside. Refer servicing to qualified service personnel.

CAUTION

WARNING:

TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK DO NOT EXPOSE

THIS EQUIPMENT TO RAIN OR MOISTURE

DO NOT OPEN

RISK OF ELECTRIC SHOCK

Important Safety Instructions

1Read these instructions.

2Keep these instructions.

3Heed all warnings.

4Follow all instructions.

5Do not use this apparatus near water.

This apparatus shall not be exposed

to dripping or splashing and no objects

lled with liquids, such as vases, shall be

placed on the apparatus.

6Clean only with dry cloth.

7Do not block any ventilation openings.

Install only in accordance with the

manufacturer’s instructions.

8Do not install near any heat sources such

as radiators, heat registers, stoves, or

other apparatus (including ampliers) that

produce heat.

9This apparatus shall be connected to

a mains socket outlet with a protective

earthing connection. Do not defeat

the safety purpose of the polarized or

grounding-type plug. A polarized plug has

two blades with one wider than the other.

A grounding type plug has two blades and

a third grounding prong. The wide blade

or the third prong are provided for your

safety. If the provided plug does not t

into your outlet, consult an electrician for

replacement of the obsolete outlet.

10 Ensure proper ESD control and grounding

when handling exposed module terminals.

11 Protect the power cord from being walked

on or pinched particularly at plugs,

convenience receptacles, and the point

where they exit from the apparatus.

12 Only use attachments/accessories

specied by the manufacturer.

13 Use only with the cart, stand, tripod,

bracket, or table specied

by the manufacturer,

or sold with the

apparatus. When a cart is

used, use caution when

moving the cart/apparatus

combination to avoid injury from tip-over.

14 Unplug this apparatus during lightning

storms or when unused for long periods of

time.

15 Refer all servicing to qualied service

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as power-supply cord or plug

cord is damaged, liquid has been spilled

or objects have fallen into the apparatus,

the apparatus has been exposed to rain

or moisture, does not operate normally, or

has been dropped.

Note: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Modifications not expressly approved by the manufacturer could void

the user’s authority to operate the equipment under FCC rules.

Cet appariel numerique de la classe B respecte toutes les Exigences du

Reglement sur le materiel brouilleur du Canada.

The 2-line analog telephone interface card device is in compliance

with the Federal Communications Commission’s (FCC) Rules and

Regulations 47 CFR Part 68, and the Administrative Council on

Terminal Attachments (ACTA) – adopted technical criteria, TIA-

968-B – Telephone Terminal Equipment, Technical Requirements For

Connection of Terminal Equipment To The Telephone Network, August

2009 and TIA-1096.

The 2-line analog telephone interface card device meets the Industry

Canada technical specifications CS-03 Part I for terminal equipment

and related access arrangements intended for direct connection

to analogue wireline facilities and DC-01(E) for the declaration

of conformity and registration of terminal equipment. The Ringer

Equivalence Number (REN) is an indication of the maximum number of

devices allowed to be connected to a telephone interface. The REN for

the Analog Telephone Interface (ATI) card is two. The termination of

an interface may consist of any combination of devices subject only to

the requirement that the sum of the REN’s not exceed two per ATI card.

Multiple ATI Cards may be installed to increase the REN for a system.

1 of 3

QUICK START GUIDE: AEC Coprocessor Module

What Ships in the Box

• AEC Coprocessor Module.

• Two 4-40 Phillips head screws.

• This Quick Start Guide.

What You Need to Provide

• Radius NX 4x4 or Radius NX 12x8

• Anti-static work station.

Getting Help

Composer, the Windows software that

configures Symetrix Dante Network Audio

hardware, includes a help file which acts as

a complete User’s Guide for both hardware

and software. If you have questions beyond

the scope of this Quick Start Guide, contact

our Customer Support Group in the following

ways:

Tel: +1.425.778.7728 ext. 5

6:00 am to 5:00 pm PST

Monday through Friday

Web: https://www.symetrix.co

Email:

[email protected]

Forum: https://forum.symetrix.co

www.symetrix.co | +1.425.778.7728

PN 53-0082 Rev C 02/22

2 of 3

QUICK START GUIDE: AEC Coprocessor Module

ESD Warning

This product can be damaged by electrostatic discharge

(ESD). When handling, care must be taken so that the

devices are not damaged. Damage due to inappropriate

handling is not covered by the warranty.

The following precautions must be taken:

• Do not open the protective conductive packaging until

you have read the following, and are at an approved

anti-static work station.

• Use a conductive wrist strap attached to a good earth

ground.

• Always discharge yourself by touching a grounded bare

metal surface or approved anti-static mat before picking

up an ESD-sensitive electronic component.

• Use an approved anti-static mat to cover your work

surface.

Card Removal and Installation

Once you are properly grounded, follow this sequence of

steps to properly set-up and congure the Symetrix AEC

Coprocessor Module in your Radius NX 4x4 or Radius NX

12x8 hardware.

First, make sure the unit is powered down. Next, you must

remove the two rack ears and the lid. To do this, remove the

6 Phillips head screws from the rack ears and the 3 Phillips

head screws from the rear of the frame. Lift the lid up using

the two tabs in the rear of the lid.

If your Radius NX 4x4 or Radius NX 12x8 unit has an AEC

Coprocessor Module installed, unscrew and remove it

by removing the two stainless steel Phillips head screws

located on the top of the card. Gently pull the card up to

disconnect the two 50-pin connectors. The card is no longer

attached to the frame. Carefully remove the card from the

chassis.

To install a new module, align and feed the connectors on

the AEC Coprocessor Module and align the screw holes

in the card with the stando󰀨s on the motherboard. Look

through this hole and align with the stando󰀨 and then,

carefully, apply an even downward pressure until you feel

the card seat into the 50-pin sockets. Use the two stainless

steel screws provided and mount the board to the stando󰀨.

Do not over tighten these screws. The 50-pin connectors on

the Symetrix AEC Coprocessor Module should not be under

any tension when properly installed.

Finally, replace the lid and rack ears.

Step 1:

Step 2:

To watch a video showing

AEC Coprocessor Module

installation, scan QR code.

www.symetrix.co | +1.425.778.7728

PN 53-0082 Rev C 02/22

3 of 3

QUICK START GUIDE: AEC Coprocessor Module

The Symetrix Limited Warranty

By using Symetrix products, the Buyer agrees to be bound by the terms of

this Symetrix Limited Warranty. Buyers should not use Symetrix products

until the terms of this warranty have been read.

What is Covered by this Warranty:

Symetrix, Inc. expressly warrants that the product will be free from defects

in material and workmanship for ve (5) years from the date the product

is shipped from the Symetrix factory. Symetrix’s obligations under this

warranty will be limited to repairing, replacing, or partially crediting original

purchase price at Symetrix’s option, the part or parts of the product which

prove defective in material or workmanship within the warranty period,

provided that the Buyer gives Symetrix prompt notice of any defect or failure

and satisfactory proof thereof. Symetrix may, at its option, require proof of

the original date of purchase (copy of original authorized Symetrix Dealer’s

or Distributor’s invoice). Final determination of warranty coverage lies

solely with Symetrix. This Symetrix product is designed and manufactured

for use in professional audio systems and is not intended for other usage.

With respect to products purchased by consumers for personal, family, or

household use, Symetrix expressly disclaims all implied warranties,

including, but not limited to, warranties of merchantability and tness

for a particular purpose. This limited warranty, with all terms, conditions

and disclaimers set forth herein, shall extend to the original purchaser and

anyone who purchases the product within the specied warranty period

from an authorized Symetrix Dealer or Distributor. This limited warranty

gives the Buyer certain rights. The Buyer may have additional rights

provided by applicable law.

What is not Covered by this Warranty:

This warranty does not apply to any non-Symetrix branded hardware

products or any software even if packaged or sold with Symetrix Products.

Symetrix does not authorize any third party, including any dealer or sales

representative, to assume any liability or make any additional warranties

or representation regarding this product information on behalf of Symetrix.

This warranty also does not apply to the following:

1. Damage caused by improper use, care, or maintenance or failure to

follow the instructions contained in the Quick Start Guide or Help File.

2. Symetrix product that has been modied. Symetrix will not perform

repairs on modied units.

3. Symetrix software. Some Symetrix products contain embedded

software or apps and may also be accompanied by control software

intended to be run on a personal computer.

4. Damage caused by accident, abuse, misuse, exposure to liquids, re,

earthquake, acts of God, or other external causes.

5. Damage caused by improper or unauthorized repair of a unit. Only

Symetrix technicians and Symetrix international distributors are

authorized to repair Symetrix products.

6. Cosmetic damage, including but not limited to, scratches and dents,

unless failure has occurred due to a defect in materials or

workmanship within the warranty period.

7. Conditions caused by normal wear and tear or otherwise due to the

normal aging of Symetrix products.

8. Damage caused by use with another product.

9. Product on which any serial number has been removed, altered or defaced.

10. Product that isn’t sold by an authorized Symetrix Dealer or Distributor.

Buyer Responsibilities:

Symetrix recommends the Buyer make backup copies of site les before

having a unit serviced. During service it is possible that the site le will be

erased. In such an event, Symetrix is not responsible for the loss or the

time it takes to reprogram the site le.

Legal Disclaimers and Exclusion of other

Warranties:

The foregoing warranties are in lieu of all other warranties, whether oral,

written, express, implied or statutory. Symetrix, Inc. expressly disclaims

any IMPLIED warranties, including tness for a particular purpose or

merchantability. Symetrix’s warranty obligation and Buyer’s remedies

hereunder are SOLELY and exclusively as stated herein.

Limitation of Liability:

The total liability of Symetrix on any claim, whether in contract, tort

(including negligence) or otherwise arising out of, connected with,

or resulting from the manufacture, sale, delivery, resale, repair,

replacement or use of any product will not exceed the retail price of the

product or any part thereof which gives rise to the claim. In no event

will Symetrix be liable for any incidental or consequential damages,

including but not limited to, damage for loss of revenue, cost of

capital, claims of Buyers for service interruptions or failure to supply,

and costs and expenses incurred in connection with labor, overhead,

transportation, installation or removal of products, substitute facilities or

supply houses.

Servicing a Symetrix Product:

The remedies set forth herein shall be the Buyer’s sole and exclusive

remedies with respect to any defective product. No repair or

replacement of any product or part thereof will extend the applicable

warranty period for the entire product. The specic warranty for any

repair will extend for a period of 90 days following the repair or the

remainder of the warranty period for the product, whichever is longer.

Residents of the United States may contact the Symetrix Technical

Support Department for a Return Authorization (RA) number and

additional in-warranty or out-of-warranty repair information.

If a Symetrix product requires repair services outside of the United

States please contact the local Symetrix dealer or distributor for

instructions on how to obtain service.

Products may be returned by Buyer only after a Return

Authorization number (RA) has been obtained from Symetrix. Buyer

will prepay all freight charges to return the product to the Symetrix factory.

Symetrix reserves the right to inspect any products which may be the

subject of any warranty claim before repair or replacement is carried

out. Products repaired under warranty will be returned freight prepaid

via commercial carrier by Symetrix, to any location within the continental

United States. Outside the continental United States, products will be

returned freight collect.

Andere Symetrix Stereoanlage Handbücher

Symetrix

Symetrix Edge Bedienungsanleitung

Beliebte Stereoanlage Handbücher anderer Marken

LG CM3330B Bedienungsanleitung

Sony

Sony SS-CEP50 Bedienungsanleitung

Cetacea Sound

Cetacea Sound CVS-II Bedienungsanleitung

Aiwa

Aiwa XR-H66MD Bedienungsanleitung

Denon

Denon UCD-250 Bedienungsanleitung

Sanyo

Sanyo DC-MX41i Bedienungsanleitung

Sharp

Sharp CD-ES600V Bedienungsanleitung

Exibel

Exibel BDX600-UK Bedienungsanleitung

Sanyo

Sanyo DC-F320 Bedienungsanleitung

Philips

Philips FWM583X Bedienungsanleitung

Sharp

Sharp CD-C462 Bedienungsanleitung

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Bedienungsanleitung

Aiwa

Aiwa XR-EM70 Bedienungsanleitung

Cyrus

Cyrus Lyric Bedienungsanleitung

Philips

Philips MCM159/98 Bedienungsanleitung

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Bedienungsanleitung

RCA

RCA RS3965SB Bedienungsanleitung

Sharp

Sharp XL-UH240 Bedienungsanleitung
