Symmons Museo 532HSB Handbuch

Museo®

Model Numbers Speciﬁcation

Modiﬁcations

Hand shower unit includes dual checks for backow

protection, 30" slide bar with cradle for hand shower

mounting, 60" exible metal hose, 2 mode hand shower

and standard 2.5 gpm (9.5 L/min) ow restrictor.

Components made from metal and nonmetallic materials,

plated in standard polished chrome nish.

Note: Append appropriate -sufx to model number.

Compliance

-ASME A112.18.1/CSA B125.1

Warranty

Limited Lifetime - to the original end purchaser in

consumer/residential installations.

5 Years - for industrial/commercial installations.

Refer to www.symmons.com/warranty for complete

warranty information.

532HSB

Hand Shower Unit

Operation & Maintenance Manual

-1.5 1.5 gpm (5.7 L/min) ﬂow restrictor

-2.0 2.0 gpm (7.6 L/min) ﬂow restrictor

-STN Satin Nickel ﬁnish

Measurements

A 3-1/8", 79 mm

Male 1/2-14 NPT tting must

be recessed 1/4" (6 mm)

from nished wall

(2x) Hole Size

Dry wall: Ø 3/16", 5 mm

Stud: Ø 1/8", 3 mm

D 28-5/16", 719 mm

C C

Note: Dimensions subject to change without notice.

Dimensions

532HSB

Hand Shower Unit

Parts Breakdown

Replacement Parts

Item Description Part Number

A Hand Shower 402W*

Slide Bar EF-02284*

E Wall Elbow EF-105*

FVacuum Breaker

(optional) EF-109*

G 60" Hose EF-02976

Note: Append modication -STN to part number

for Satin Nickel nish.

Tools Required for Installation

Adjustable

Wrench

Allen Wrench:

3 mm

Phillips Head

Screwdriver

Plumber Tape

Power Drill

Silicone

Notes:

1) Apply a bead of silicone around the perimeter of all shower trim

installed ush to the nished wall (less mounting plates and

brackets). Leave opening on bottom of escutcheons for weep hole.

2) Apply plumber tape to all threaded connections.

Installation

1a)

Dry Wall Option: R

emove upper

and lower caps (B) from slide bar

brackets. Place slide bar (D) into

desired position. Using brackets

as a guide, carefully drill 3/16"

holes into wall. Remove slide bar

and install anchors.

Notes: Make sure that slide bar holes

and bracket holes are aligned before

drilling. Before drilling bottom hole,

make sure slide bar is plumb.

1b) Stud Option: R

emove upper and

lower caps (B) from slide bar

brackets. Place slide bar (D) into

desired position. Using brackets

as a guide, carefully drill 1/8"

pilot holes into stud.

Notes: Make sure that slide bar holes

and bracket holes are aligned before

drilling. Before drilling bottom hole,

make sure slide bar is plumb.

2) With slide bar (D) in position,

secure to wall using screws (C).

Replace upper and lower caps (B)

onto slide bar brackets.

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: (800) 796-6667 ■ Fax: (800) 961-9621

Installation

3) Install wall elbow (E) to stub

out pipe. Tighten set screw

to secure.

4) Attach large end of hose (G)

to hand shower wand (A).

Attach small end of hose (G) to

wall elbow (E). Turn clockwise to

tighten.

Troubleshooting Chart

Finish is spotting. Elements in water supply may cause

water staining on nish.

Clean nished trim area with a soft

cloth using mild soap and water or a

non-abrasive cleaner and then quickly

rinse with water.

Troubleshooting Chart

WARNING: This product can expose you to chemicals including lead, which is known to the state of California to

cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
