Hardware Manual of 380V 7.5kW Servo Drive II (SPD-32C1-075)
Preface–3
1 Preface
Thank you for your continued support of our products. Our servo team is forever committed to the research and
development of new products; we hope that our products and services can bring each user the best possible
experience.
The SYNTEC high-performance servo drive series consists of our company's latest servo drive models. Each
product is manufactured using high quality materials and has been through rigorous testing. In addition, our drives
adopt precise vector control, guaranteeing high accuracy, high stability and high efficiency.
This Operation Manual includes the drive's hardware specifications, installation instructions, as well as wiring
and signal descriptions, providing each user with detailed guidance. To achieve the best performance of our
products and to maintain the safety of both personnel and equipment, please read this manual carefully before use
and keep it in a safe place for future reference. If any doubts arise, please do not hesitate to contact our office-- we
will be happy to help!
伺服產品/Servo Products
–
Hardware Manual of 380V 7.5kW Servo Drive II (SPD-32C1-075)
Applicable models–4
2 Applicable models
This user manual is for Syntec 7.5kW servo drive.
伺服產品/Servo Products
–
Hardware Manual of 380V 7.5kW Servo Drive II (SPD-32C1-075)
HardwareSpecification–5
3 HardwareSpecification
3.1 Description
Each drive undergoes strict quality inspectionand anti-collision packaging before leaving the factory. Please
check for impact damage upon receiving the product. Users should also compare the serial numbers on the
outer box and on the product itself. If there is any discrepancy, please contact us immediately.
Model Description
伺服產品/Servo Products
–
Hardware Manual of 380V 7.5kW Servo Drive II (SPD-32C1-075)
HardwareSpecification–6
3.2 Appearance
3.3 Dimensions
SPD-32C1-075
伺服產品/Servo Products
–
Hardware Manual of 380V 7.5kW Servo Drive II (SPD-32C1-075)
HardwareSpecification–7
3.4 Specification
Syntec driver SPD-32C1-075
Power supply Rated supply
voltage
Three-phase 380~440V 50/60Hz
Power supply
voltage
allowable
range
-15 ~ +10%
伺服產品/Servo Products
–
Hardware Manual of 380V 7.5kW Servo Drive II (SPD-32C1-075)
HardwareSpecification–8
Power
frequency
fluctuation
range
±5%
Output Rated output
current
21A
Over current
capability
150% 60s、200% 1s
Way to control Three-phase full-wave rectification, SVPWM-VVVF control
Regenerator For external connection, please refer to the chapter on selection of
regenerator
Feedback
encoder
Support serial interface: Tamagawa, SYNNET, NIKON, FeeDAT, EnDAT,
Panasonic, Mitsubishi, Mitutoyo, HCFA
Optional expansion encoder module: support Tamagawa, SYNNET,
NIKON, ABZ, serial, SSI, BiSS (does not support UVW wiring-saving
encoder)
(To use the expansion encoder module, please refer to the servo
10PX1/10PX3 expansion module operation document)
PC
communication
interface
MINI-USB
Controller
serial
communication
interface
Mechatrolink III
I/O signal Digital input 2 ports, can be planned
Digital output 1 port, can be planned
STO Dual channel safe torque off switch (2I 1O)
Cooling
method
Fan cooling
伺服產品/Servo Products
–
Hardware Manual of 380V 7.5kW Servo Drive II (SPD-32C1-075)
HardwareSpecification–9
Environment Temperature 0°C ~ 55°C (if the ambient temperature exceeds 45°C, please force the
surrounding air to circulate),storage: -20 ~ 65°C (non-freezing)
Humidity Maximum 90% RH (non-condensing), storage: 90% RH or less (non-
condensing)
Installation
location
Indoor (avoid direct sunlight); no corrosive gas, flammable gas, oil mist or
dust
Altitude Below 1000 meters to sea level
Vibration Up to 5.9 m/s2
Weight 4.2kg
伺服產品/Servo Products
–
Hardware Manual of 380V 7.5kW Servo Drive II (SPD-32C1-075)
Transportationand Installation–10
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
4 Transportationand Installation
4.1 Transportation
The entire body of the drive must be held during transportation. To avoid the risk of falling, do NOT hold the drive
by its upper cover or by any individual part.
4.2 Installation Environment Conditions and Precautions
Installation Environment Conditions
Locations without high heat generating devices.
Locations without floating dust or metal particles.
Locations without corrosive or flammable gasses and liquids.
Locations without water, steam, dust, or oily dust.
Locations without electromagnetic noise interference.
A sturdy, vibration-free location.
Suitable ambient temperature is 0 ° C ~ 55 ° C; if the ambient temperature is above 45 ° C, please put the
drive in a well-ventilated place or in an air-conditioned room.
Installation Precautions
Install the drive in the direction specified bythe instructions; incorrect positioning may lead to servo failure.
When installing the drive, do not block its ventilation holes and do not place it upside down, otherwise the
drive may malfunction.
Do not use on or near flammable materials.
Make sure that each fastening point is tight when fixing the drive in place.
Install on a surface that can withstandthe weight.
Operation Precautions
For long-term operation, it is recommended to maintain an ambienttemperaturebelow 45 °C to ensure
product reliability.
If the product is installed inanelectrical cabinet, the size and ventilation of thecabinetmust prevent any
internal electronic devices from overheating. Also pay attention to whether the machine's vibrations will
affect other electronics in the cabinet.
To enhancecooling circulation, maintain sufficient space between all sides and surrounding objects of the
drive and the baffles (walls); also take care not to block the ventilation holes, otherwise the drive may
malfunction.
Other Precautions
The cable between the drive and the motor should not be stretched too tightly.
Do not place heavy objects on top of the drive.
Keep the drive clear from conductive objects such as metal and screws or combustibles such as oil.
If the cable connecting the motor and the drive is longer than 20 meters, please thicken the U, V, W and
encoder cables.
