Synway TEJ100P Bedienungsanleitung
Synway AST Series
TEJ100P/TEJ200P
TEJ100E/TEJ200E
TEJ101P/TEJ201P
TEJ101E/TEJ201E
Digital Trunk Interface Board
Version 1.0
Synway Information Engineering Co., Ltd
www.synway.net
Synway Information Engineering Co., Ltd
Contents
Contents.........................................................................................................................................i
Copyright Declaration..................................................................................................................ii
Revision History..........................................................................................................................iii
Chapter 1 Overview......................................................................................................................1
1.1 Features .............................................................................................................................2
1.2 Operation Principle.............................................................................................................3
Chapter 2 Installation ...................................................................................................................4
2.1 Hardware Structure ............................................................................................................4
2.2 Interface Identification ........................................................................................................9
2.3 Slot Compatibility................................................................................................................9
2.4 System Requirements ......................................................................................................10
2.5 Hardware Installation........................................................................................................10
Appendix A Technical Specifications .......................................................................................13
Appendix B Technical/Sales Support .......................................................................................14
Synway TEJ100/200/101/201P, TEJ100/200/101/201E Hardware Manual (Version 1.0) Page i
Synway Information Engineering Co., Ltd
Copyright Declaration
This manual is provided by Synway Information Engineering Co., Ltd (hereinafter referred to as
‘Synway’) as the support file for ‘Synway TEJ Series board driver software’. Both the software and
this manual are copyrighted and protected by the laws of the People's Republic of China.
All rights reserved; no part of this manual may be extracted, modified, copied, reproduced or
transmitted in any form or by any means, electronic or mechanical, without prior written permission
from Synway. By using this manual, you agree to the following Software License Agreement.
Synway reserves the right to revise this manual without prior note. Please contact Synway for the
latest version of this manual before placing an order.
Synway has made every effort to ensure the accuracy of this manual but does not guarantee the
absence of errors. Moreover, Synway assumes no responsibility in obtaining permission and
authorization of any third party patent, copyright or product involved in relation to the use of this
manual.
Note: Asterisk and Digium mentioned in this book are registered trademarks of Digium Inc.
Synway TEJ100/200/101/201P, TEJ100/200/101/201E Hardware Manual (Version 1.0) Page ii
Synway Information Engineering Co., Ltd
Revision History
Version Date Comments
Version 1.0 2009-12 Initial publication.
Note: Only major revisions to this manual itself recorded herein.
Synway TEJ100/200/101/201P, TEJ100/200/101/201E Hardware Manual (Version 1.0) Page iii
Synway Information Engineering Co., Ltd
Chapter 1 Overview
The Synway TEJ100P, TEJ200P, TEJ100E, TEJ200E, TEJ101P, TEJ201P, TEJ101E and
TEJ201E are digital trunk interface boards which support E1, T1 and J1 environments. They are in
2U size, 120mm in length, compact in structure and high in integration. TEJ100P, TEJ200P,
TEJ101P, TEJ201P include PCI bus while TEJ100E, TEJ200E, TEJ101E and TEJ201E include
PCIe bus, designed especially for various application systems that require high performance.
They all perform echo cancellation by on-board DSPs. The enhanced capability of TEJ101P,
TEJ101E, TEJ201P, TEJ201E in echo cancellation reaches 128ms for time delay estimation,
which ensures high-quality voice talk without extra modules or devices to support echo
cancellation. They are cost-effective. The design of on-board EMC and lightning-proof circuits
further guarantee the security in use.
These boards are completely compatible with Asterisk at the hardware/driver level and support
smooth connection to Asterisk platform. Therefore they have a lot of advanced call features.
Supported Data Modes: Cisco HDLC, HDLC, PPP, Multi-link PPP, Frame Relay.
Supported Voice Modes:
PRI CPE and PRI NET
—NI1
—NI2
—EuroISDN
—4ESS(AT&T)
—5ESS(Lucent)
—DMS100
E&M
—Wink
—Feature Group B
—Feature Group D
FXO and FXS
—Ground Start
—Loop Start
—Loop Start with Disconnect Detect
These boards connect Asterisk Server with PSTN, Channel Bank or PBX via T1, E1 or J1 interface
to build a specialized telephony network environment. Figure 1-1 and Figure 1-2 below are typical
application models with these boards.
Synway TEJ100/200/101/201P, TEJ100/200/101/201E Hardware Manual (Version 1.0) Page 1
Synway Information Engineering Co., Ltd
Figure 1-1 Application Model I: Traditional Telephony System
Note: TEJXXX in Figure 1-1 and Figure 1-2 represent available TEJ series boards
Figure 1-2 Application Model II: VoIP Telephony System
1.1 Features
zPCI/PCIe Bus Support
TEJ100P/TEJ200P/TEJ101P/TEJ201P includes PCI 2.2 bus; in the universal PCI design, it
supports 3.3V/5V PCI slot and PCI-X slot.
TEJ100E/TEJ200E/TEJ101E/TEJ201E includes PCIe bus; supports PCI Express X1, X4,
X8, X16 slots and PNP (plug and play) feature.
zDMA Read and Write
The use of DMA technique for data reading and writing helps minimize the cost of the host
CPU.
zCompatible with Asterisk
Entirely compatible with Asterisk at the hardware/driver level, with all source codes open.
zRJ48C Jack
The TEJ100P/TEJ100E/TEJ101P/TEJ101E and TEJ200P/TEJ200E/TEJ201P/TEJ201E
boards respectively have 1 and 2 RJ48C jacks which can either connect directly with digital
trunks or convert to BNC connectors via a proper adapter, making connection easy and
malfunctions rare.
Legacy Phones
Legacy
PBX
A
ster
i
s
k
S
erve
r
TEJXXX T1
Internet
R
emote o
ffi
ces
CLEC
A
ster
i
s
k
S
erve
r
TEJXXX T1
IP Phones
LAN
Switch
Synway TEJ100/200/101/201P, TEJ100/200/101/201E Hardware Manual (Version 1.0) Page 2
Synway Information Engineering Co., Ltd
zEcho Cancellation
The echo cancellers developed by Synway for these boards use on-board DSPs to work.
TEJ101P/TEJ101E/TEJ201P/TEJ201E supports up to 128ms for time delay estimation per
channel, and TEJ100P/TEJ100E/TEJ200P/TEJ200E supports 32ms, really cost-effective.
It not only cancels out the effect of voice playback on DTMF and busy tones detection, but
also avoids self-excited oscillation and howling, and minimizes the possibility of registering
wrong DTMF and busy tones in a conference call, designed especially for VoIP application
environments.
zVoice CODEC Support
Supports A-law, μ-law codecs.
zClock Sync Support
Supports input and output of CT clock, allowing clock synchronization with multiple boards.
zEMC & Lightning-proof Circuits Available
1.2 Operation Principle
Mother Board
Figure 1-3 Operation Principle
Inbound PCM Data
Echo
Outbound PCM Data
PCM Interface
Recording Playback
Host Computer Interface (PCI/PCIe)
Synway TEJ100/200/101/201P, TEJ100/200/101/201E Hardware Manual (Version 1.0) Page 3
Synway Information Engineering Co., Ltd
Chapter 2 Installation
2.1 Hardware Structure
zTEJ100P, TEJ200P, TEJ101P and TEJ201P Boards
PCM0
RJ48C
LED1
Figure 2-1 TEJ100P (Left and Front Views)
Figure 2-2 TEJ200P (Left and Front Views)
OUT1 IN1 OUT2 IN2 JP3
PCI Interface
JP3
Clock Sync Interface
Connect to grounding
j
umpers at transmit
end of PCM0
Connect to grounding
j
umpers at receive end
of PCM0
Connect to grounding
j
umpers at transmit
end of PCM1
Connect to grounding
j
umpers at receive
end of PCM1
PCM0
PCM1
RJ48C
LED1
LED2
OUT1 IN1
JP3
PCI Interface
Connect to grounding
j
umpers at receive end
Connect to grounding
j
umpers at transmit end
Clock Sync Interface
Synway TEJ100/200/101/201P, TEJ100/200/101/201E Hardware Manual (Version 1.0) Page 4
Synway Information Engineering Co., Ltd
PCM0
RJ48C
LED1
Figure 2-3 TEJ101P (Left and Front Views)
Figure 2-4 TEJ201P (Left and Front Views)
OUT1 IN1
JP3
PCI Interface
Connect to grounding
j
umpers at receive end
Connect to grounding
j
umpers at transmit end
Clock Sync Interface
OUT1 IN1 OUT2 IN2 JP3
PCI Interface
JP3
Clock Sync Interface
Connect to grounding
j
umpers at transmit
end of PCM0
Connect to grounding
j
umpers at receive
end of PCM0
Connect to grounding
j
umpers at transmit
end of PCM1
Connect to grounding
j
umpers at receive
end of PCM1
PCM0
PCM1
LED1
LED2
RJ48C
Synway TEJ100/200/101/201P, TEJ100/200/101/201E Hardware Manual (Version 1.0) Page 5
Synway Information Engineering Co., Ltd
Board Model
& Serial
TEJXXXP XXXXXX
Figure 2-5 TEJ100P/TEJ200P/TEJ101P/TEJ201P (Rear View)
zTEJ100E, TEJ200E, TEJ101E and TEJ 201E Boards
Figure 2-6 TEJ100E (Left and Front Views)
OUT1 IN1
Connect to grounding
j
umpers at transmit end
PCM0
JP3
Connect to grounding
j
umpers at receive end Clock Sync Interface
RJ48C
LED1
PCIe Interface
Synway TEJ100/200/101/201P, TEJ100/200/101/201E Hardware Manual (Version 1.0) Page 6
