Sysmik Scalibur SCA-340 Bedienungsanleitung

Rev.22

Scalibur – Modular Controllers

SCA-340 / SCA-340-L

Manual

Disclaimer / Impressum

2 sysmik.de Manual SCA-340 / SCA-340-L

This manual is intended to provide support for installation and usage of the device. The

information is believed to be accurate and reliable. However, SysMik GmbH Dresden

assumes no responsibility for possible mistakes and deviations in the technical

specifications. SysMik GmbH Dresden reserves the right to make modifications in the

interest of technical progress to improve our modules and software or to correct mistakes.

We are grateful to you for criticism and suggestions. Further information (device description,

available software) can be found on our homepage www.sysmik.de. Please ask for latest

information.

SysMik disclaims all warranties in case of improper use or disassembly and software

modifications not described in this document or when using improper or faulty tools.

Commissioning and operation of the device by qualified personnel only. All applicable

regulations have to be observed.

SysMik®and the SysMik logo are registered trademarks of SysMik GmbH Dresden.

All other trademarks mentioned in this document are registered properties of their owners.

These and further trademarks are used in this document but not marked for better

readability.

No part of this document may be reproduced or modified in any form without prior written

agreement with SysMik GmbH Dresden.

SysMik GmbH Dresden Tel + 49 (0) 351 – 4 33 58 – _0

Bertolt-Brecht-Allee 24 Fax + 49 (0) 351 – 4 33 58 – 29

01309 Dresden E-Mail (Sale) [email protected]

E-Mail (Support) [email protected]

Germany Homepage https://www.sysmik.de

Contents

Manual SCA-340 / SCA-340-L sysmik.de 3

Contents

1. Introduction 6

2. Device and System Overview 7

2.1 Hardware 7

2.1.1 Functional Overview 7

2.1.2 Processor Core 7

2.1.3 Ethernet 7

2.1.4 Serial Ports 8

2.1.5 USB 8

2.1.6 LON 8

2.1.7 Inline Local Bus Interface / Modular IO Terminals 8

2.2 Software Overview 9

2.2.1 Scalibur System Shell 9

2.2.2 IO Server 9

2.2.3 Commissioning Web Server 9

2.2.4 Sedona Virtual Machine 9

2.2.5 Niagara Framework 10

3. Installation and Commissioning 11

3.1 Assembly 11

3.1.1 Dimensions 11

3.1.2 Mounting 12

3.1.3 Adding Inline Terminals 13

3.2 Connections 14

3.2.1 Connectors 14

3.2.2 Power Supply 15

3.2.2.1 How to Connect Power 15

3.2.2.2 Power Dissipation Calculations for a Scalibur Controller 17

3.2.2.3 Current Consumption Calculation for a Scalibur Station (with Terminals) 18

3.2.2.4 Derating of Terminal and USB Supply 18

3.2.2.5 Protective Devices of 24 V Main and Segment Supply UMand US20

3.2.3 RS-485 and LON 20

3.2.4 Ethernet 21

3.2.5 USB-OTG for local Access 22

Contents

4 sysmik.de Manual SCA-340 / SCA-340-L

3.2.6 USB 23

3.3 Operating Elements 24

3.3.1 Overview 24

3.3.2 Inline Supply LEDs “US”, “UM”, “UL” 24

3.3.3 Process Status LEDs “PL”, “ST”, “SE” 24

3.3.4 IO Status LED “IO” 25

3.3.5 Communication LEDs “COM1”, “COM2”, “LON” 25

3.3.6 Service Button and LED “SV” 26

3.3.7 Ethernet Status LEDs 26

3.3.8 RS-485 Termination 27

4. Software 28

4.1 Configuration Tools 28

4.1.1 SCA System Shell 29

4.1.2 Commissioning Website 29

4.1.3 File Access via FTP 30

4.2 Commissioning Scalibur 30

4.2.1 IP Addressing 31

4.2.2 Time and Time Zone 31

4.2.3 Hardware Data Point Test 31

4.3 Ethernet Switch for Flexible Network Topologies 33

4.3.1 Assignment of IP Interfaces to External Ethernet Ports 33

4.3.2 Ethernet Ring Monitoring 35

4.3.3 Rapid-Spanning-Tree-Protocol (RSTP) 35

4.3.4 Port Status Informations 36

4.3.5 Broadcast Storm Protection 36

4.4 Real-Time Control with Scalibur and Sedona 37

4.4.1 IO Access 37

4.4.2 Modbus 37

4.4.3 Platform Service 38

4.5 Integration with Scalibur and Niagara Framework 39

4.5.1 Local IO Access 39

4.5.2 Serial Interfaces 41

4.5.3 IO Remote Control 43

4.5.4 Sedona Integration 43

Contents

Manual SCA-340 / SCA-340-L sysmik.de 5

4.6 Concurrent Access to the IO Terminals 44

5. Best Practices and Troubleshooting 46

5.1 Performance and Resource Management 46

5.2 Reliability of Nonvolatile Memory 47

5.3 Diagnosis and Troubleshooting 47

5.3.1 SCA System Shell / Commissioning Website is not accessible 48

5.3.2 IP Address unknown 48

5.3.3 No IP Communication 48

5.3.4 Unknown Niagara Platform Access Credentials 48

5.3.5 No Platform Connection to Device - Platform Daemon is not starting 49

5.3.6 Sedona Virtual Machine is not Starting 49

5.3.7 IO Errors 49

6. Technical Data 50

7. Order Information 53

7.1 Scalibur and Accessories 53

7.2 Supported Inline Automation Terminals 54

8. Glossary 56

9. Third-Party Software 57

10. Bibliography 58

Introduction

6 sysmik.de Manual SCA-340 / SCA-340-L

1. Introduction

Scalibur is a powerful modular controller for Niagara and Sedona. Scalibur stands

for scalability, a major characteristic of this controller. Scalability comprises several

aspects:

1) Scalable IO

A Scalibur station consists of the Scalibur controller and up to 63 terminals of the

modular Inline system. The terminals are available in a wide variety of types:

digital and analog inputs and outputs with different numbers of channels as well

as functional terminals for DALI light control, pulse metering, MBUS or serial

interfaces.

2) Scalable software

Scalibur has been developed primarily for the Niagara framework. Niagara

applications are built with the software tool Niagara Workbench. While Niagara

is very powerful, it is not very well suited for specific real-time applications. In

order to realize such applications with Scalibur too, the controller has the

Sedona framework in parallel to Niagara. Sedona applications run with fixed

cycle times in the millisecond range and are created with the

Niagara Workbench. Beside the separate exclusive use of either framework, the

parallel use of Niagara and Sedona is supported. The Niagara and Sedona

application can communicate to each other with a Sedona driver for Niagara.

3) Scalable licensing

The license model for Scalibur is very flexible: a license comprises a certain

number of data points which can be integrated with Scalibur. These license

packs are available as first-time license (250/500/1250/5000/10000 data points)

or as upgrade license (500/1250/2500 data points). Sedona, as open source

project, doesn’t have any license fees.

4) Scalable IP network

Scalibur contains two logically separated IP interfaces and an integrated

Ethernet switch with four external ports. The configurable assignment of the

Ethernet ports to the separate IP interfaces and the usage of the spanning-tree-

protocol allow flexible topologies like daisy-chain and redundant ring-structures

for both the backbone and the local control network.

Device and System Overview

Manual SCA-340 / SCA-340-L sysmik.de 7

2. Device and System Overview

2.1 Hardware

2.1.1 Functional Overview

Fig. 2.1.1.1: SCA-340-L basic circuit diagram

2.1.2 Processor Core

Processor: ARM®Cortex®A8 / 1 GHz

DDR3 SDRAM: 1 GB RAM (512 MiB for hardware version < 06 – see serial label)

eMMC Flash: 1,8 GB

NVRAM: 512 KiB / (buffered for a power failure of 5 days)

RTC: buffered for a power failure of 5 days

The internal Flash memory can be extended with a microSD card.

2.1.3 Ethernet

The integrated Ethernet switch has 4 external ports, which can be assigned

independently to one of the two separate IP interfaces. If at least two ports belong to

an IP interface, then redundant communication paths can be established, for

example by connecting several devices in a ring. The Ethernet switch supports the

Rapid Spanning Tree Protocol (RSTP), as well as a ring monitoring function to

automatically switch off redundant paths, and a broadcast storm protection function.

Factory default: eth0 is assigned to LAN3/LAN4, eth1 is assigned to LAN1/LAN2,

and RSTP and ring monitoring are deactivated.

Device and System Overview

8 sysmik.de Manual SCA-340 / SCA-340-L

2.1.4 Serial Ports

Both RS-485 ports have switches for bias and terminating resistors, and are

galvanically isolated from each other and the rest of the circuit.

Further serial interfaces may be added using modular IO terminals (M-Bus, RS-232,

RS-485, RS-422).

2.1.5 USB

USB 1 is a USB-OTG port with Mini-USB socket, and is used for installation and

maintenance. Connected to a PC, it allows to control the device via console and to

access the internal installation web site for device configuration and data point test.

The second USB port (USB 2) allows to connect USB end-devices.

2.1.6 LON

The SCA-340-L has a LON interface according to the CEA-709 standard, to connect

directly to LonMark TP/FT-10 networks.

2.1.7 Inline Local Bus Interface / Modular IO Terminals

The local bus interface allows to connect up to 63 modular IO terminals. This

interface comprises the communication channel to the IO terminals as well as the

power supply of these terminals and their connected sensors and actuators.

Scalibur is a controller for the Inline IO system and unlocks the rich pool of Inline IO

terminals for building automation.

Inline is a modular IO system by Phoenix Contact, to flexibly and quickly build up

space-saving automation stations. An Inline station consists of a bus controller and

a set of IO terminals, chosen freely in terms of numbers, type, and sequential

arrangement. The bus controller runs the Inline station and has interfaces to the

higher level controller. Up to 63 IO terminals can be connected to a bus controller.

There are IO terminals for almost any purpose:

digital inputs and outputs with 1, 2, 4, 8, 16, or 32 channels per terminal

Triac and relay outputs for switching signals or for higher loads

analog inputs for measuring voltage, current, resistance, or temperature

with 2, 4, or 8 channels per terminal

analog outputs for voltage or current with 2, 4, or 8 channels per terminal

function terminals for complex IO operations or gateway functions (DALI,

M-Bus, S0 pulse metering, serial interface)

supply and support terminals , e.g. to realize separated voltage domains

within an Inline station

The overall width of the Inline extension terminals is 1, 2 or 4 DU (1 DU, division

unit = 12.2 mm or approx. 0.48 in.).

Inline terminals are provided with a pluggable wiring level enabling pre-wiring and

easy module exchange.

The mechanics of the system also allows exchanging terminals without complete

dismantling of the station.

Scalibur determines type and function of all supported terminals automatically, thus

certain in- and output functions can also be created without a previous configuration

of the station, which is especially helpful for commissioning tests.

Device and System Overview

Manual SCA-340 / SCA-340-L sysmik.de 9

2.2 Software Overview

Scalibur is using a Linux operating system, which runs several applications in

parallel.

Fig. 2.1.7.1: Scalibur software structure

2.2.1 Scalibur System Shell

The Scalibur System Shell is accessible only via the local USB-OTG port, and is

used during commissioning to configure basic settings like IP address, or as

maintenance access if IP address or passwords have been lost.

2.2.2 IO Server

The IO server controls the modular Inline terminals of the Scalibur station and

manages concurrent accesses to the hardware data points. Niagara and the IO

server communicate via an TCP connection. This allows to control IOs remotely

from another Niagara station. The remote access can be limited or disabled by the

setting of the IP address of the controlling station.

2.2.3 Commissioning Web Server

The commissioning web server is exclusively accessible via the local USB-OTG

port. It presents web pages to commission the device: setting IP addresses and time

zone, reading state of inputs and setting output states of the data points of the local

IO terminals for test purposes.

2.2.4 Sedona Virtual Machine

The Sedona virtual machine (SVM) runs the Sedona application in real-time with

configurable cycle time. The Niagara Workbench connects to the SVM to modify the

application, load updates, or create backups of the application. Platform specific kits

provide access to the IO terminals, and also to system settings like IP addresses

Device and System Overview

10 sysmik.de Manual SCA-340 / SCA-340-L

and Modbus settings. A Modbus TCP server and a Modbus TCP client/Modbus RTU

master are integrated and are used to exchange data with other Sedona controllers.

Also, Niagara can be deactivated here.

2.2.5 Niagara Framework

Scalibur can be parameterized with Niagara Workbench and a platform connection

to the Niagara daemon. This includes loading of software updates and of a station

(Niagara application), which can be run automatically by the Niagara daemon.

A Workbench connection to a station is used to modify the station. All features of the

Niagara framework are available:

data point integration over a plethora of open automation protocols (LON,

BACnet, KNX, M-Bus, Modbus, and others) with data normalization

system functions (scheduler, alarming, trend log)

web visualization

enterprise interfaces (oBIX, data bases) and many more

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere sysmik Controller Handbücher

sysmik

sysmik ICS-852M Einrichtungshandbuch

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung

sysmik Scalibur SCA-340 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken
