1177fil HHFlex C/R/P/S

AHU Control

Operating Instructions

V8.00

Contents

1 SAFETY CONSIDERATIONS 5

1.1 General 5

1.2 Avoid Electrocution 5

1.3 Abbreviations used 5

2 CONTROLLER DESCRIPTION 6

2.1 Overview 6

2.2 Power Supply 6

2.3 Battery 6

2.4 Indications 6

2.5 Mapping of Inputs/Outputs 7

2.6 Technical data 8

2.6.1 Common Data Controller 8

2.6.2 Communication 8

2.6.3 Casing 8

2.6.4 Inputs 8

2.6.5 Outputs 8

2.6.6 External display 8

2.6.7 TCP/IP port 8

3 HUMAN MACHINE INTERFACE 9

3.1 E-DSP External display unit 9

3.2 Overview 9

3.3 Log in 9

3.4 Menu tree external display 10

3.5 Access levels external display 11

3.6 Web panel 11

3.7 Connection to the unit 11

3.8 Login Screen 12

3.9 Overview Screen 13

3.10 Dashboard screen 13

3.11 Actual/Setpoint screen 14

3.12 Alarm Status screen 14

3.13 Inputs/Output screen 14

3.14 Analog Inputs screen 15

3.15 Analog Outputs screen 15

3.16 Digital Inputs screen 16

3.17 Digital Outputs screen 16

3.18 Time Program screen 17

3.19 Settings screen 18

3.20 Factory Screen 18

4 HHFlex – BASIC CONTROL FUNCTIONS 19

4.1 Temperature Control 19

4.1.1 Temperature control in occupied mode 19

4.1.2 Supply air temperature (TT02)control 19

4.2 Economy mode based on OAT (TT06) 19

4.2.1 Room air temperature (TT05) control 20

4.2.2 Extract air temperature (TT03) control 21

4.2.3 Temperature control in non-occupied mode 21

4.3 Fan speed control 22

4.3.1 Fixed Fan Speed Control 22

4.3.2 High / low speed operation 22

4.3.3 Air Flow Control 22

4.3.4 High / low air flow operation 22

4.3.5 Supply Duct Pressure Control 22

4.3.1 Supply and exhaust Duct Pressure Control 23

4.3.2 Indoor Air Quality Control 23

4.4 Heat Recovery Monitoring 23

4.4.1 Low Supply Air Temperature Monitoring 23

4.4.2 High Supply Air Temperature Monitoring 23

4.4.3 Frost Protection without Pre-Heating 23

4.5 Filter Monitoring equipped with a pressure sensor 24

4.1 Dry outdoor filter control equipped with a pre-heater 24

4.2 Occupancy Management 24

4.3 Stand alone mode 24

4.3.1 Internal Clock 24

4.3.2 Operation Time Extension 24

4.4 Remote mode 24

4.5 Building Fire Management 25

5 HHFlex – OPTIONAL CONTROL FUNCTIONS 25

5.1 Air Dampers 25

5.2 Hot-water reheating Coil 25

5.3 Water Coil Frost Protection (TA01) 26

5.4 Warm Up at Unit Start Up 26

5.5 Unit Frost Protection 26

5.6 Chilled-water Cooling Coil 26

5.6.1 Temperature Control 26

5.8 Change-over water Coil for Heating and Cooling 27

5.8.1 Heat/Cool Thermostat (TS01) 27

5.8.2 Temperature Control 27

5.8.3 Water Coil Frost Protection (TA05) 27

5.8.5 Warm Up at Unit Start Up 28

5.8.6 Unit Frost Protection 28

5.8.7 Defrost of heat-pump 28

5.8.8 Backup electric heater 28

5.9 Electrical reheating Coil 29

5.9.1 Temperature Control 29

5.9.2 Overheating protection (TA04) 29

5.9.3 Cool down at unit stop 29

5.10 Electrical pre-heating Coil 30

5.10.1 Heat Recovery Frost Protection 30

5.10.2 Overheating protection (TA03) 30

5.10.3 Cool down at unit stop 30

5.11 Hot water pre-heating Coil 31

5.11.1 Heat Recovery Frost Protection 31

5.11.2 Water Coil Frost Protection (TA01) 31

5.11.3 Warm Up at Unit Start Up 31

5.11.4 Unit Frost Protection 31

5.12 Direct-expansion coil 32

5.12.1 Condensing unit/reversible unit with staged capacity 32

5.12.2 Condensing unit/reversible unit with variable capacity 32

5.13 Water pump anti-blocking system 32

5.14 Recirculation air damper (CD06) 32

5.15 Mixing Box management 33

5.15.1 ON/OFF recirculation 33

5.15.2 Modulated recirculation as heating/cooling capacity 33

5.15.3 Minimum fresh air threshold 33

5.15.5 Modulated recirculation using CO2 sensor 34

5.15.6 Modulated recirculation as heating/cooling capacity with fresh air calculation 34

5.17 Fast building temperature warm-up/cool-down before an occupied period 35

5.18 Operation of chilled beams during unoccupied periods 35

5.19 Heat pump defrost 35

5.20 Minimum/maximum room temperature in an unoccupied period 35

5.21 Humidification control 36

5.21.1 Description control algorithm 36

5.21.2 Default settings for relative humidity control 37

5.23 Dehumidification control 38

5.23.1 Description control algorithm 38

5.23.2 Default settings for relative humidity control 38

6 DIAGNOSTICS & TROUBLESHOOTING 39

6.1 General 39

6.2 Displaying Alarms 39

6.2.1 E-DSP External display unit 39

6.2.2 Web Panel 39

6.3 Alarm report 39

6.4 Resetting Alarms 39

6.5 Alarms List 40

7 BUS COMMUNICATION 42

7.1 General 42

7.2 Modbus 42

7.2.1 Communication Settings 42

7.2.2 Modbus type 42

7.2.3 Modbus functions 42

7.2.4 Max. 47 registers 42

7.2.5 Communication limits 42

7.2.6 Scale factor 42

7.3 BACnet IP 43

7.4 ANNEX 1 - BACNET PROTOCOL IMPLEMENTATION AND CONFORMITY 44

The manufacturer reserves the right to change the specifications without prior notice.

Graphics and photos are for illustration purposes only and not contractually binding.

1 SAFETY CONSIDERATIONS

1.1 General

Installation, start-up and servicing of equipment can be hazardous if certain factors particular to the installation are not

considered: operating pressures, presence of electrical components and voltages and the installation site (elevated plinths

and built-up up structures). Only properly qualified installation engineers and highly qualified installers and technicians,

fully trained for the product, are authorized to install and start-up the equipment safely. During all servicing operations

all instructions and recommendations which appear in the installation and service instructions for the product, as well as

on tags and labels fixed to the equipment and components and accompanying parts supplied separately, must be read,

understood and followed.

•Apply all standard safety codes and practices.

•Wear safety glasses and gloves.

•Use the proper tools to move heavy objects. Move units carefully and set them down gently.

1.2 Avoid Electrocution

Only personnel qualified in accordance with IEC (International electro technical Commission) recommendations may be

permitted access to electrical components. It is particularly recommended that all sources of electricity to the unit be shut

off before any work is begun. Shut off the main power supply at the main circuit breaker or isolator.

1.3 Abbreviations used

AHU Air Handling Unit

AI Analog Input

AO Analog Output

CHO Change Over Coil

CWC Cold Water Coil

DI Digital Input

DO Digital Output

EAT Extract Air Temperature

HWC Hot Water Coil

IAT Inlet Air Temperature (Sensor placed just before heat recovery exchanger)

OAT Outdoor Air Temperature

RAM Random Access Memory (volatile memory)

2 CONTROLLER DESCRIPTION

HHFlex controller is an electronic control system to regulate Air Handling Units.

The control system consists of two controllers which are described hereafter.

2.1 Overview

Controller Overview

Port 2 and TCP/IP are only available on the main controller

2.2 Power Supply

Each controller operates at 24 VDC and has a power consumption of 4 VA (without load, without display).

In the event of a power supply interrupt, the unit restarts automatically without the need for an external command. However, any

faults active when the supply is interrupted are saved and may in certain cases prevent unit from restarting.

2.3 Battery

The resources and the program are stored in RAM. To ensure that they are not lost and that the hardware clock

continues to run when there is a power failure, the controller is equipped with a buffer battery.

The buffer time is at least 5 years.

The buffer battery is a 3V lithium battery (CR2032).

The battery voltage is monitored. When battery is low the P/B Indication LED lights red.

2.4 Indications

The upper left corner of each controller contains four LEDs which give the status indication of the controller.

Designation Colour Description

P1 RxTx Yellow/

Green

Port 1: Receiving/transmitting

P2 RxTX Yellow/

Green

Port 2: Receiving/transmitting

TCP/IP Green/

Yellow

Fixed green: Link

Flashing green: Traffic

Flashing yellow: Identification

P/B Green/

Red

Power supply / Low battery

level

2.5 Mapping of Inputs/Outputs

2.6 Technical data

2.6.1 Common Data Controller

Supply voltage 24 VAC ±15%, 50….60 Hz or 20…36 VDC

Power consumption 4 VA (without load, without display)

BTL approval EXOreal 3.1-1-02 or later

+C output +24 V DC, 0,15 A, short-circuit proof

Operating system EXOreal C

Battery backup Memory and real-time clock, at least 5 years

Ambient temperature 0…50⁰C

Storage temperature -20…+70⁰C

Relative humidity (non-condensing) Max. 95%

Dimensions (WxHxD) 149 x 121 x 60 mm

Din controller width 8 ½

EMC emissions and immunity standard: This product conforms to the requirements of the EMC Directive

2004/108/EC through product standards EN 61000-6-1 and EN 61000-6-3.

RoHs: This product conforms to the Directive 2011/65/EU of the European Parliament and of the Council.

2.6.2 Communication

Serial RS485 (EXOline or Modbus with automatic detection/change over)

TCP EXOline-TCP, BACnet/IP, Modbus/IP (requires EXOreal 3.1.1-01 or later)

Modbus 8 bits, 1 or 2 stop bits. Odd, even (Fs) or no parity.

Speed (Port 1 and Port 2) adjustable 1200-38400 bps

2.6.3 Casing

Protection class IP20

Mounting DIN-rail mounting or mounting in cabinet

Plastic Polycarbonate, PC

2.6.4 Inputs

Analogue inputs, AI 0(4)…20 mA, 0…10 V, 0…200 mV, PT-1000, DIN Ni1000, LGNi1000,

12 bits A/D

Digital inputs, DI Potential-free contact, 24 V DC, configurable for pulse input

Universal inputs. UI AI or DI (see above)

2.6.5 Outputs

Analogue outputs, AO 0…10 V DC, 5 mA, 12 bit D/A, short circuit-protected

Digital outputs, DO Mosfet 24 V AC/DC, 2 A. Max 8 A in total.

24 V DC output 0.15 A, short circuit-protected

2.6.6 External display

Models E3-DSP, ED9200 or ED-RU

Connection 4P4C modular connector.

Max. cable length 100 m

2.6.7 TCP/IP port

Connection RJ45, 10Base-T/100Base-TX auto-negotiation

Cable length Max. 100 m (min Cat 5)

Power consumption + 1 VA in addition to basic consumption.

3 HUMAN MACHINE INTERFACE

3.1 E-DSP External display unit

3.2 Overview

The display menu system is accessed using seven buttons:

The LEDs have the following functions:

Designation Function Colour

There are one or more

unacknowledged

alarm(s)

Flashing red

There are one or

more remaining,

acknowledged alarm(s)

Fixed red

You are in a dialogue

box where it is possible

to switch to change mode

Flashing

yellow

Change mode Fixed yellow

3.3 Log in

The standard passwords are 3333 for basic level with the lowest access (guest) and 2222 for level giving more access (operator).

Menu tree external display

3.4 Menu tree external display

ACTUAL /

SETPOINTS

ACTIVATE OUT

OF HOUR

OUT OF HOURS

OVERRIDE TIME

TEMPERATURE

HUMIDITY

DE-HUMIDITY

AIR VOLUME /

FANSPEED

DUCT PRESSURE

INDOOR AIR

QUALITY

FILTER SENSOR

HEAT RECOVERY

UNIT

CONFIGURATION

OUTDOOR

TEMPERATURE

SUPPLY

TEMPERATURE

ROOM

TEMPERATURE

EXTRACT

TEMPERATURE

INLET HUMIDITY

SUPPLY HUMIDITY

ROOM HUMIDITY

EXTRACT HUMIDITY

INLET HUMIDITY

SUPPLY HUMIDITY

ROOM HUMIDITY

EXTRACT HUMIDITY

SUPPLY FAN

EXHAUST FANSUPPLY DUCT

EXHAUST DUCT

SUPPLY

EXHAUST

ENDRUNMODE

TEMPERATURE

CONTROL

HUMIDITY

CONTROL

FANCONTROL

OUTDOOR

COMPENSATION

NIGHTCOOLING

MAIN CONTROLLER

SLAVE 1

CONTROLLER

SLAVE 2

CONTROLLER

TIME SCHEDULE RUN SCHEDULE

LOW SPEED

NIGHTCOOLING

RECIRCULATION

PUMPTEST

HOLIDAYS

SETTINGS

PRESSURE FAILURE

SUPPLY

TEMPERATURE

FILTER SENSOR SUPPLY

EXHAUST

END

LOW

HIGH

SUPPLY FAN

EXTRACT FAN

FACTORY

INPUTS/ OUTPUTS

RUNTIME

ADJUST

TIME/ DATE

COMMUNICATION

DEFAULT SCREEN SOFTWARE

VERSION

TYPE AND SERIAL

NR.

MODBUS CONFIG

BACNET IP CONFIG

MANUAL-AUTO

ACCES RIGHTS

MAIN CONTROLLER

SLAVE 1

CONTROLLER

SLAVE 2

CONTROLLER

GATEWAY

EXOLINE ADDRES

CURRENT IP

ADDRESS

SUBNETMASK

ELECTRIC FROST

HEATER

ELECTRIC BOOSTER

HEATER

AHU ON

HEAT DEMAND

COLD DEMAND

RELEASE DX

PUMP PREHEATER

PUMP BOOSTER

HEATER

PUMP COOLER/

CHANGE-OVER

PUMP RUN-A-

ROUND COIL

HUMIDIFIER

MAIN CONTROLLER

SLAVE 1

CONTROLLER

SLAVE 2

CONTROLLER

LOG ON

LOG OFF

CHANGE

PASSWORD

FIRE ALARM

SETTINGS

ALARM LOG

GATEWAY

DNS

ALARM SETTINGS

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere System air Steuereinheit Handbücher

System air

System air PKI-C Series Bedienungsanleitung

System air

System air TCA 150D2 Bedienungsanleitung

System air

System air Topvex Series Bedienungsanleitung

System air

System air IAM Bedienungsanleitung

System air

System air TControl POD glass 3s white Bedienungsanleitung

System air

System air SYSCONTROL CWC 02 Bedienungsanleitung

System air

System air Villavent Bedienungsanleitung

System air

System air fantech ECO-FEEL 414729 Bedienungsanleitung

System air

System air PCA 1000D Bedienungsanleitung

System air

System air BOR-S Series Bedienungsanleitung

System air

System air SPI Bedienungsanleitung

System air

System air AM-PKI Bedienungsanleitung

System air

System air SPLIT-AHU Kit 0-10V LNS Bedienungsanleitung

System air

System air EC Vent Bedienungsanleitung

System air

System air IAM Bedienungsanleitung

System air

System air SAVE CONNECT Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
