VoiceOff Movement Activated MP3 Message

Player

Instruction Manual

VoiceOff.com

VOX111

VoiceOff.com

Table of Contents

Part 1 Introduction to the VOX111 1

Part 2 Key Features 2

Part 3 Box Contents 3

Part 4 Required Tools / Handy Extras 3

Part 5 Connections & Wiring 4

1 Alarm Input ..................................................................................................................... 4

2 Micro USB ....................................................................................................................... 5

3 Power ............................................................................................................................. 5

4 Audio Input ..................................................................................................................... 6

5 L/R Out (Audio) ............................................................................................................... 6

Part 6 Powering Up 6

Part 7 Setup Considerations 7

1 Free MP3 MessagesSupplied ......................................................................................... 7

2 PIR .................................................................................................................................. 8

3 Alarm Input ..................................................................................................................... 8

4 Relay Delay (01-99 secs) ................................................................................................. 8

5 Indicator Light (Red) ....................................................................................................... 8

Part 8 Mounting 9

Part 9 Troubleshooting 10

1 Problem – The unit isn’t playing a message. ................................................................ 10

2 Problem – The unit isplaying the wrong messages. .................................................... 10

3 Problem – The unit isn’t triggering a second time ........................................................ 10

Part 10 User Operation 11

Part 11 General Maintenance 11

Part 12 Specifications 12

Part 13 FAQs 12

1 How do I load up a new message file on to the VOX111 MP3 Player? ......................... 12

2 Are there any Free MP3 messages that I can use on the VOX111 MP3 Player? ............ 12

3 How do I do change the output volume on the VOX111? .............................................. 12

Part 14 Further Resources & Contact Details 13

Index

VoiceOff.com

1 Contact Us ..................................................................................................................... 13

Part 15 Conditions 14

1 Product Disclaimer ....................................................................................................... 14

2 General Company Disclaimer ....................................................................................... 14

3 WEEE Declaration ......................................................................................................... 14

4 Copyright ...................................................................................................................... 14

Index 16

23/05/2022

VOX111

VoiceOff.com

Introduction to the VOX111

The VoiceOFF® "VOX111" is a great way to automatically play pre-recorded messages to

visitors at your business.

It features a built-in PIR that plays a pre-recorded message stored in it, when movement is

detected, through a small built-in speaker. You can change the message stored in the

VOX111 with your own personal one to tailor the message to your particular requirements.

The automatic playing of messages is a great reminder to visitors of your policies helping

them and your staff to stay safe during the Covid outbreak. It’s non-confrontational and never

forgets to do its job!

With the ability to change the built in MP3 message, it’s really easy to then use the VOX111

to play other general messages as times change, so you could use it to welcome guests and

take a seat or suggest items you have on special offer.

The VOX111 can also be triggered to play a different MP3 message by triggering its alarm

input. This allows you to link it to others devices such as automatic doors, alarm panels, fire

alarms etc. Inside the VOX111 it has the ability to store the two MP3 messages, one is played

back from being triggered by the PIR, the second being trigged by something external

connected to its alarm input.

The VOX111 is an in-ceiling mount design so that it can sit in a ceiling tile or similar for a

clean and easy installation. It is 12V powered and requires a suitable PSU such as a POW151.

Alternatively you could run a 12V power supply from another 12V system within the

premises for a neat installation.

To change the MP3 sound files stored on the VOX111 you simply connect it to a suitable

computer or laptop and it will see it as a USB drive. Replace the MP3 files with your own

using the correct naming protocol as listed in these instructions.

Index

VoiceOff.com

VOX111 - Movement Activated MP3 Message Player

Key Features

Built in PIR (up to 4M range)

PIR triggers Message 1

Alarm Input from a source such as a door contact, PIR or push button.

Alarm Input triggers Message 2

Ceiling Mounted 3W Speaker Design

Low voltage 12V DC

Low Current Consumption (20-300mA standby/playing)

2 Free MP3 Message (Easily swapped to your own if required)

Free Mini Remote Control for User Operation

External Audio Out put for additional amplifier

External Audio Input allows for general speaker user.

23/05/2022

VOX111

VoiceOff.com

Box Contents

The VOX111 contains the following items:

1 x VOX111 VoiceOff Movement Activated

MP3 Message Player

1 x Mini Remote Control handset

1 x Micro USB to USB Lead.

Required Tools / Handy Extras

Holesaw (Dia 108mm)

12V DC PSU (min 400mA) with a standard 2.1mm DC Plug

Screwdriver if adding additional alarm inputs

Alarm Cable if adding an alarm input extra to the built-in PIR

Alarm Input device (PIR, Door Contact) if adding a secondary alarm input

PC or Laptop (if intending to swap over the existing MP3 messages)

Phono Plugs or Leads (if connecting up the External Audio In and Outputs)

Index

VoiceOff.com

Connections & Wiring

No.

Label

Description

L/R Out

3.5mm audio socket for audio output

Audio Input

3.5mm audio socket for audio input

12V DC

2.1mm DC Socket for connecting PSU

USB

Micro USB Socket for connecting to PC

COM NC TG GND

Screw terminal block for connecting alarm input and ouput

5.1 Alarm Input

A 4-way terminal strip used in conjunction with an

external alarm input such as a wireless keyfob, door

contact, push button, a secondary PIR or a DVR/NVR

alarm output.

To trigger the second MP3 message (SQ02.mp3)

connect "TG" to "GND" on the VOX111's relay

terminals.

23/05/2022

VOX111

VoiceOff.com

5.2 Micro USB

Used for connecting the unit to a PC, the micro USB leads connects into the rear of the player

whilst the USB connects into the USB on your PC or Laptop. The player is seen as a USB drive

allowing the free message (MP3) files to be swapped over to meet your exact requirements.

When replacing your MP3 message files please ensure the following naming conventions are

adhered to:

SQ01.mp3 (PIR triggered message)

SQ02.mp3 (external alarm input triggered message)

Further free messages for the unit can be downloaded by visiting our website and entering

your unit’s serial number at:

voiceoff.com

5.3 Power

The unit requires 12V DC up to 300mA to operate. This is connected using the 2.1mm DC

socket on the rear of the speaker case.

Index

VoiceOff.com

5.4 Audio Input

A standard 3.5mm audio jack input that allows the unit to be used as a standard (loud)

speaker unit.

Please note: when the unit detects an external input on this port, it will override any other

message functions.

5.5 L/R Out (Audio)

A standard 3.5mm audio jack socket connection for line audio output can be connected to an

external amplifier for playing messages in a second area.

The output is line level output (-10dBV) which is around 0.5V peak to peak. If the amplifier

being used does not have a line or mic input for lower line level inputs then a pre-amp may

be required.

Note this output is not an axillary output, which tends to have a high line level output of

around (0dBV) 1.0-1.2V peak to peak.

Powering Up

The VOX111 VoiceOFF® should be powered using a regulated 12V DC power supply of a

minimum rating of 400mA. This can be plugged in using the 2.1mm DC power socket on the

rear of the speaker case. The unit uses 20mA in standby mode and up to 300mA whilst

operating.

23/05/2022

VOX111

VoiceOff.com

Setup Considerations

It is worth taking a couple of minutes to conduct a site survey and bench test the unit to try

out the messages before before mounting the VOX111 in situ. It may be that you wish to

switch around the messages played by the unit and this is easier to do near a PC or laptop

rather than once it is installed.

7.1 Free MP3 Messages Supplied

The unit is supplied with 2 free messages that are named to automatically play once

triggered by their respective inputs as follows:

SQ01.mp3 (PIR triggered message)

The PIR input on the VOX11 has been wired to trigger the following message:

SQ01.mp3 - this is the following free message as shipped at time of writing:

“Welcome face coverings are required whilst in this store, thank you for helping to keep us all

safe.”

SQ02.mp3 (External alarm input triggered message)

The external alarm input connection has been setup to trigger the following message:

SQ02.mp3 - this is the following free message as shipped at time of writing:

“Please observe the social distancing measures we have in place during your visit.”

Other messages

A selection of free messages (plus 1000s of others) can be downloaded at our website for

numerous uses including:

Welcome Messages for Reception Areas, Health & Safety Announcements, Customer Service

Advice, CCTV In Operation Messages, Sirens and more...

Please visit: voiceoff.com
