1400A Direct Wire
Ionization Smoke Detector
INSTALLATION AND MAINTENANCE INSTRUCTIONS
Before Installing
Please thoroughly read the System Sensor manual I56-
407-XX, Guide for Proper Use of System Smoke Detec-
tors. This manual provides detailed information on detector
spacing, placement, zoning, wiring, and special appli-
cations. Copies of this manual are available at no charge
from System Sensor. Please also refer to CAN/ULC-S524,
Standard for the Installation of Fire Alarm Systems and
CEC Part 1, Sec. 32..
General Description
System Sensor 1400A dual-chamber ionization smoke de-
tectors utilize state-of-the-art, unipolar sensing chambers.
These detectors are designed to provide open area pro-
tection, and to be used with compatible ULC-listed, 2-wire
control panels only. The detector’s operation and sensitiv-
ity can be tested in place.
Specifications
Diameter: 5.5 inches (140 mm)
Height: 3.12 inches (80 mm)
Weight: 0.7 lb. (310 g)
Operating Temperature: 0oto +49oC (32oF to 120oF)
Latching Alarm: Reset by momentary power interruption.
Operating Humidity: 10% to 93% Relative Humidity, Noncondensing
Electrical Ratings:
System Voltage: 12/24 VDC
Maximum Ripple Voltage: 4 Volts peak to peak
Start-up Capacitance: 20 pf Maximum
Standby Ratings: 8.5 VDC Minimum
35 VDC Maximum
100 uA Maximum
Alarm Ratings: 4.2 VDC Minimum at 10 mA
6.6 VDC Minimum at 100 mA
Alarm current must be limited to 100 mA maximum by the control panel. If used,
the RA400ZA Remote Annunciator operates within the specied detector alarm cur-
rents.
Reset Voltage: 2.5 VDC Minimum
Reset Time: 0.3 S Maximum
Start-up Time: 35 S Maximum
Each detector includes an LED that provides a local visual
indication of the detector’s status. The LED blinks every
ten seconds as an indication that power is applied to the
detector and lights continuously in alarm. These detectors
also have the latching alarm feature. The alarm can be re-
set only by a momentary power interruption.
The detector also has provision for the connection of
an optional Model RA400ZA Remote Annunciator. The
RA400ZA provides a visual indication of an alarm and
mounts to a single gang box.
Spacing
CAN\ULC-S524 denes the spacing requirements for
smoke detectors. Typically, this is 30 feet when the detec-
tors are installed on a smooth ceiling. However, ALL instal-
lations must comply with CAN/ULC-S524 and/or special
requirements of the authority having jurisdiction.
Mounting
Each 1400A detector is supplied with a mounting bracket
kit that permits the detector to be mounted:
6581 Kitimat Rd., Unit #6, Mississauga, Ontario, L5N 3T5
1-800-SENSOR2, FAX: 905-812-0771
www.systemsensor.ca
D400-07-00 REV#-002 2 I56-1006-002
1. Directly to a 3-1/2 inch or 4 inch octagonal, 1-1/2 inch
deep electrical box, or
2. To a 4 inch square electrical box by using a plaster ring
with the supplied mounting bracket kit.
Installation Wiring Guidelines
All wiring must be installed in compliance with the National
Electrical Code and all applicable local codes and any spe-
cial requirements of the authority having jurisdiction, us-
ing the proper wire size. The conductors used to connect
smoke detectors to control panels and accessory devices
should be color-coded to reduce the likelihood of wiring
errors. Improper connections can prevent a system from
responding properly in the event of a re.
For signal wiring (the wiring between interconnected de-
tectors), it is recommended that the wire be no smaller
than AWG 18. However, the screws and clamping plate
can accommodate wire sizes up to AWG 12. The use of
twisted pair wiring for the power (+ and -) loop is recom-
mended to minimize the effects of electrical interference.
Smoke detectors and alarm system control panels have
specications for allowable loop resistance. Consult the
A78-534-00
control panel manufacturer’s specications for the total
loop resistance allowed for the control panel being used
before wiring the detector loops.
Begin electrical connections by stripping about 3/8" insu-
lation from the end of the wire. Then, slide the bare end of
the wire under the clamping plate and tighten the clamping
plate screw. A wiring diagram for a typical 2-wire detector
system is shown in
Figure 3.
NOTE: Break the wire at each terminal to ensure that the
connections are supervised. Do NOT loop the wire
under the terminals.
Tamper-resistant Feature
This detector includes a tamper-resistant feature that ef-
fectively prevents removal of the detector without the use
of a tool. To make the detector tamper-resistant, break off
the smaller tab at the scribed line on the tamper resistant
tab, on the detector mounting bracket (see Figure 2), then
install the detector. To remove the detector from the brack-
et once it has been made tamper resistant, use a small
screwdriver to depress the tamper-resistant tab located
in the slot on the mounting bracket and turn the detector
counterclockwise for removal.
Installation
WARNING
Disconnect the power to the alarm system control unit be-
fore installing detectors.
1. Wire the detector following the installation guidelines.
2. Line up arrows on the detector with the arrows on the
mounting bracket.
3. Rotate the detector clockwise until it clicks into place.
4. After all detectors have been installed, apply power to
the control unit.
5. Test the detector as described under TESTING.
6. Reset the detector at the system control panel.
7. Notify the proper authorities that the system is in op-
eration.
CAUTION
Dust covers can be used to help limit dust entry to the
detector, but they are not a substitute for removing the
detector during building construction. Remove any dust
covers before placing system in service.
Testing
Before testing the detector, look for the presence of the
ashing LED. If it does not ash, power has been lost to
TAMPER
RESISTANT
TAB
TO MAKE DETECTOR TAMPER RESISTANT,
BREAK OFF TAB EXTENSION
AT SCRIBED LINE
Figure 2. Model 1400A detector mounting bracket:
Figure 1. Surface mounting of Model 1400A de-
tector on 3-1/2 and 4 inch octagonal box:
A78-1554-02
D400-07-00 REV#-002 3 I56-1006-002
the detector (check the wiring), or it is defective (return for
repair – refer to Warranty).
Detectors must be tested after installation and following
periodic maintenance. Notify the proper authorities that the
system is undergoing testing. The 1400A may be tested as
follows:
A. Recessed Test Switch
1. A test switch is located on the detector housing (See
Figure 4).
2. Push and hold the recessed test switch with a 0.1
inch maximum diameter tool.
3. The LED on the detector should light within 5
seconds.
B. Test Module (System Sensor Model No. MOD400R)
The MOD400R is used with an analog or digital volt-
meter to check the detector sensitivity as described in
the test module manual.
C. Aerosol Generator (Gemini 501)
Set the generator to represent 4%/Ft. to 5%/Ft. obscu-
ration as described in the Gemini 501 manual. Using
the bowl shaped applicator, apply aerosol until the unit
alarms.
Notify the proper authorities that the system is back on-
line.
Detectors that fail these tests should be cleaned as de-
scribed under MAINTENANCE and retested. If the detec-
tors still fail these tests, they should be returned for repair.
Maintenance
NOTE: Before starting, notify the proper authorities that
the smoke detector system is undergoing main-
tenance and, therefore, will be temporarily out of
service. Disable the zone or system undergoing
maintenance to prevent unwanted alarms.
The 1400A is cleaned as follows:
1. Remove the detector screen and cover assembly by
depressing the three lock prongs on the top of the cover,
rotating the cover counter-clockwise, and pulling the
screen cover assembly away from the detector (see
Figure 5). Use of the System Sensor CRT400 cover
+
REMOTE
ANNUNCIATOR -
+-
+
REMOTE
ANNUNCIATOR
CLASS A OPTIONAL WIRING
NOTE: IF REMOTE ANNUNCIATOR IS NOT USED, POLARITY TO DETECTOR MAY BE REVERSED.
EOL
RESISTOR
INITIATING
LOOP
ULC LISTED
COMPATIBLE
CONTROL
PANEL
+
-
-
-
+
3
21
3
21
Figure 3. Wiring diagram for 1400A smoke detector used with two-wire control panel:
A78-1554-00
PUSH RECESSED TEST SWITCH WITH
A 0.1" MAX. DIAMETER TOOL.
TEST MODULE
SOCKET
LED
RECESSED
TEST SWITCH TAMPER SLOT
Figure 4. Bottom and side views showing position of test switch:
A78-1554-03
D400-07-00 REV#-002 4 I56-1006-002
© System Sensor 2003
Figure 5. Removal of cover and screen for cleaning:
LOCK PRONG
REMOVABLE
SCREEN
REMOVABLE
COVER FOR
CLEANING
LOCKING
PRONGS
removal tool is recommended.
2. Remove the screen from the cover.
3. Use a vacuum cleaner to remove dust from the screen,
the cover, and the sensing chamber.
4. After cleaning, snap the screen into the cover, then
place the cover and screen assembly on the detector
turning clockwise until it is locked in place.
5. Test the detector as described in TESTING.
6. Notify the proper authorities that the system is back on
line.
A78-1554-04
Three-Year Limited Warranty
System Sensor warrants its enclosed smoke detector to be free from defects in ma-
terials and workmanship under normal use and service for a period of three years
from date of manufacture. System Sensor makes no other express warranty for this
smoke detector. No agent, representative, dealer, or employee of the Company has
the authority to increase or alter the obligations or limitations of this Warranty. The
Company’s obligation of this Warranty shall be limited to the repair or replacement
of any part of the smoke detector which is found to be defective in materials or work-
manship under normal use and service during the three year period commencing
with the date of manufacture. After phoning System Sensor’s toll free number 1-800-
SENSOR2 (736-7672) for a Return Authorization number, send defective units post-
age prepaid to: System Sensor, Repair Department, RA #__________, 6581 Kitimat
Rd., Unit #6, Mississauga, Ontario, L5N 3T5. Please include a note describing the
malfunction and suspected cause of failure. The Company shall not be obligated to
repair or replace units which are found to be defective because of damage, unrea-
sonable use, modications, or alterations occurring after the date of manufacture. In
no case shall the Company be liable for any consequential or incidental damages
for breach of this or any other Warranty, expressed or implied whatsoever, even if
the loss or damage is caused by the Company’s negligence or fault. Some states do
not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This Warranty gives you specic
legal rights, and you may also have other rights under common law.
Please refer to insert for the Limitations of Fire Alarm Systems
Inhaltsverzeichnis
Andere System Sensor Rauchmelder Handbücher
System Sensor
System Sensor BEAM200S Bedienungsanleitung
System Sensor
System Sensor FSB-200 Bedienungsanleitung
System Sensor
System Sensor TEMPORAL TONE SOUNDER BASE B501BHT Bedienungsanleitung
System Sensor
System Sensor B112LPA Bedienungsanleitung
System Sensor
System Sensor 2100D Bedienungsanleitung
System Sensor
System Sensor 2400 Bedienungsanleitung
System Sensor
System Sensor FAAST Bedienungsanleitung
System Sensor
System Sensor Innovair DH100LP Bedienungsanleitung
System Sensor
System Sensor Innovair flex 2D51 Bedienungsanleitung
System Sensor
System Sensor B501BH Bedienungsanleitung
System Sensor
System Sensor BEAM200A Bedienungsanleitung
System Sensor
System Sensor 1112/24B Bedienungsanleitung
System Sensor
System Sensor Innovair DH100ACDCLWP Bedienungsanleitung
System Sensor
System Sensor 2351BR-IV Bedienungsanleitung
System Sensor
System Sensor 2351B Bedienungsanleitung
System Sensor
System Sensor FTX-P1 Bedienungsanleitung
System Sensor
System Sensor PERTRONIC Innovair flex D4120 Bedienungsanleitung
System Sensor
System Sensor D4120 Bedienungsanleitung
System Sensor
System Sensor DH400ACDCP Bedienungsanleitung
System Sensor
System Sensor INNOVAIR FLEX JD4P120 Bedienungsanleitung
Beliebte Rauchmelder Handbücher anderer Marken
Resolution Products
Resolution Products RE612 CryptiX Bedienungsanleitung
First Alert
First Alert PC900V Bedienungsanleitung
Eminent
Eminent EM6590 E-Domotica Bedienungsanleitung
Ei Electronics
Ei Electronics Ei Ei168RC Bedienungsanleitung
Carrier
Carrier Kidde Quell Q301 Bedienungsanleitung
VESDA
VESDA VLF-500 Bedienungsanleitung
