D150-01-00 1 I56-599-03R

B116LP Plug-in Detector Base

For use with the following smoke detectors:

In US: 1151, 2151

In Canada: 1151A, 2151A

In Europe: 1151E, 2151E

INSTALLATION AND MAINTENANCE INSTRUCTIONS

3825 Ohio Avenue,

St. Charles, Illinois 60174

1-800-SENSOR2, FAX: 630-377-6495

Before Installing

Please thoroughly read the System Sensor manual I56-407,

Guide for Proper Use of System Smoke Detectors, which pro-

vides detailed information on detector spacing, placement,

zoning, wiring, and special applications. Copies of this

manual are available at no charge from System Sensor. (For

installation in Canada, please refer to CAN4-S524, Standard

for the Installation of Fire Alarm Systems and CEC Part 1,

Sec. 32.)

NOTICE: This manual should be left with the owner/user

of this equipment.

IMPORTANT: The detector used with this base must be

Specifications

Base Diameter: 6.2 inches (157 mm)

Base Height: 0.95 inches (24 mm)

Weight: 0.3 lb. (130 g)

Mounting: 4-inch square box with or without plaster ring. Min. Depth–1.5 inches

4-inch octagon box. Min. Depth–1.5 inches

3-1/2 inch-octagon box. Min. Depth–1.5 inches

50 mm box

60 mm box

70 mm box

Operating Temperature Range: 0° to +49°C (32° to 120°F) US and Canadian Installations

10°to 60°C (14° to 140°F) European Installations

Operating Humidity Range: 10% to 93% Relative Humidity

Electrical Ratings – includes base and detector

System Voltage: 24 VDC

Maximum Ripple Voltage: 4 Volts peak to peak

Start-up Capacitance: 0.02µF Maximum

Standby Ratings: 15 VDC Minimum

35 VDC Maximum

120 µA Maximum

Alarm Ratings: 8 V Minimum at 16 mA

12 V Maximum at 100 mA

(Alarm current MUST be limited to 100 mA maximum by the control panel.)

Relay Contact Ratings:

Resistive or Inductive (60% power factor) Load

Form C:* 2.0A @ 30 VAC/DC

0.6A @ 110 VDC

1.0A @ 125 VAC

Reset Voltage: 1.4 VDC Minimum

Reset Time: 0.3 Seconds Maximum

Start-up Time: 34.0 Seconds Maximum

*For Canadian installations relay contact ratings are 2.0A @ 30 VAC/DC.

tested and maintained regularly following NFPA 72 require-

ments. The detector used with this base should be cleaned

at least once a year.

General Description

The model B116LP plug-in detector base is used with

System Sensor model 1151, 1151A, and 1151E ionization

detector heads and model 2151, 2151A, and 2151E photo-

electronic detector heads. The capability of plugging these

detectors into a variety of special bases makes them more

versatile than equivalent direct-wired models. Refer to the

System Sensor catalog for other available plug-in detector

bases.

D150-01-00 2 I56-599-03R

The B116LP base is intended for use in 2-wire systems,

with screw terminals provided for power and relay contact

connections. These bases MUST be current limited by the

system control panel in the alarm state.

Mounting

This detector base mounts directly to 3-1/2-inch and 4-

inch octagon boxes, and 4-inch square boxes (with or with-

out plaster rings). To mount, remove decorative ring by

turning it in either direction to unhook the snaps, then sep-

arate the ring from the base. Install the base to the box

using the screws supplied with the junction box and the

appropriate mounting slots in the base. Place decorative

ring onto base, then turn in either direction until the ring

snaps in place (see Figure 1).

Installation Guidelines

All wiring must be installed in compliance with the

National Electrical Code and the local codes having

jurISdiction. Proper wire gauges should be used. The con-

ductors used to connect smoke detectors to control panels

and accessory devices should be color-coded to prevent

wiring mistakes. Improper connections can prevent a sys-

tem from responding properly in the event of a fire.

For signal wiring (the wiring between inter-connected

detectors), it is recommended that the wire be no smaller

than 18 gauge. Wire sizes up to 12 gauge may be used with

the base. For best system performance, the power (+) and

(–) loop wires should be twisted pair and installed in sep-

arate grounded conduit to protect the loop from extraneous

electrical interference.

Smoke detectors and alarm system control panels have

specifications for allowable loop resistance. Consult the

control panel manufacturer’s specifications for the total

loop resistance allowed for the particular model control

panel being used before wiring the detector loops.

Locate installations where normal ambient temperatures do

not exceed 100°F.

Wiring Instructions

For system supervision — For terminals 2, 3, and 5 do not

use looped wire under terminals. Break wire run to provide

system supervision of connections.

Wire connections are made by simply stripping insulation

from the end of the wire, sliding the bare end of the wire

under the clamping plate, and tightening the clamping

plate screw. Use the strip gauges molded into the inside

CAUTION

and underside of the base for ease of wiring to terminals 1

through 5, and to terminals 12 through 14, respectively.

System Sensor smoke detectors and mounting bases are

marked with a compatibility identifier located as the last

digit of a five digit code stamped on the back of the prod-

uct. Connect detectors/mounting bases only to compatible

control units as indicated in System Sensor’s compatibility

chart which contains a current list of UL listed control units

and detector head/base combinations. A copy of this list is

available from System Sensor upon request.

The zone wiring of the detector base should be checked

before the detector heads are installed in them. To make

this possible, this base contains a special spring-type short-

ing jumper. After a detector base is properly wired and

mounted on an electrical box, make sure that the jumper

spring is in contact with the base of Terminal 3. This tem-

porary connection shorts the positive-in and positive-out

leads and permits the wiring of the loop to be checked for

continuity.

SNAP ON

DECORATIVE

RING

SCREWS (NOT

SUPPLIED)

DETECTOR

BASE

BOX (NOT

SUPPLIED)

SHORTING

SPRING

Figure 1. Mounting base to box:

A78-1175-01

CAUTION

Once all the detector bases have been wired and mounted,

and the loop wiring has been checked, the detector heads

may be installed in the bases. The shorting spring in the

base will disengage automatically when the detector head

is removed from the base. DO NOT remove the shorting

spring since it reengages as the detector head is fully

turned into the base, completing the circuit.

Tamper-resistance Feature

Do NOT use the tamper-resistance feature if the XR2

Removal Tool will be used.

This detector base includes a tamper-resistance feature that

prevents removal of the detector without the use of a tool.

To activate this feature, break off the tab on the detector

base shown in Figure 3A, then install the detector. To

D150-01-00 3 I56-599-03R

Figure 2. Typical wiring diagram:

(+) POWER LOOP

2-WIRE CONTROL PANEL

(–) POWER LOOP

11213

14 COM CONTACT

N.C. AUXILIARY

N.O. FORM C

CLASS A OPTIONAL WIRING

A78-1577-00

remove the detector from the base once the tamper-resist-

ance feature has been activated, place a small-bladed

screwdriver into the small hole on the side of the base and

push plastic lever away from the detector head (see Figure

3B). This will allow the detector to be rotated counter-

clockwise for removal.

NOTE: Head removal after the tamper-resistance feature

has been activated requires removal of the decora-

tive ring.

The tamper-resistance feature can be defeated by breaking

and removing the plastic lever from the base, however this

prevents using the feature again.

PLASTIC LEVER

BREAK TAB AT

DOTTED LINE BY

TWISTING TOWARD

CENTER OF BASE.

USE SMALL-BLADED

SCREWDRIVER TO

PUSH PLASTIC LEVER

IN DIRECTION OF

ARROW.

A78-1175-03

Figure 3B. Removing detector head from base:Figure 3A. Activating tamper-resistance feature:

D150-01-00 4 I56-599-03R

Three-Year Limited Warranty

System Sensor warrants its enclosed smoke detector base to be free from

defects in materials and workmanship under normal use and service for a

period of three years from date of manufacture. System Sensor makes no

other express warranty for this smoke detector base. No agent, represen-

tative, dealer, or employee of the Company has the authority to increase

or alter the obligations or limitations of this Warranty. The Company’s

obligation of this Warranty shall be limited to the repair or replacement of

any part of the smoke detector base which is found to be defective in

materials or workmanship under normal use and service during the three

year period commencing with the date of manufacture. After phoning

System Sensor’s toll free number 800-SENSOR2 (736-7672) for a Return

Authorization number, send defective units postage prepaid to: System

Sensor, Repair Department, RA #__________, 3825 Ohio Avenue, St.

Charles, IL 60174. Please include a note describing the malfunction and

suspected cause of failure. The Company shall not be obligated to repair

or replace units which are found to be defective because of damage,

unreasonable use, modifications, or alterations occurring after the date of

manufacture. In no case shall the Company be liable for any consequen-

tial or incidental damages for breach of this or any other Warranty,

expressed or implied whatsoever, even if the loss or damage is caused by

the Company’s negligence or fault. Some states do not allow the exclusion

or limitation of incidental or consequential damages, so the above limita-

tion or exclusion may not apply to you. This Warranty gives you specific

legal rights, and you may also have other rights which vary from state to

state.

Please refer to insert for the Limitations of Fire Alarm Systems

Andere System Sensor Rauchmelder Handbücher

System Sensor

System Sensor DNRA Bedienungsanleitung

System Sensor

System Sensor 1151E Bedienungsanleitung

System Sensor

System Sensor BEAM1224A Bedienungsanleitung

System Sensor

System Sensor Inovair Flex D4240 Bedienungsanleitung

System Sensor

System Sensor FAAST 7100X Bedienungsanleitung

System Sensor

System Sensor B210LP Bedienungsanleitung

System Sensor

System Sensor 7251DH Bedienungsanleitung

System Sensor

System Sensor B112LPA Bedienungsanleitung

System Sensor

System Sensor 4WT-B Bedienungsanleitung

System Sensor

System Sensor 2251B Bedienungsanleitung

System Sensor

System Sensor 2312/24TB Bedienungsanleitung

System Sensor

System Sensor FTX-P1 Bedienungsanleitung

System Sensor

System Sensor Innovair DH100 Bedienungsanleitung

System Sensor

System Sensor ECO2000 Series Bedienungsanleitung

System Sensor

System Sensor InnovairFlex D4240 Bedienungsanleitung

System Sensor

System Sensor 1151 Bedienungsanleitung

System Sensor

System Sensor Innovair DH100ACDCLWP Bedienungsanleitung

System Sensor

System Sensor Innovair Flex DNRW Bedienungs- und Wartungsanleitung

System Sensor

System Sensor PERTRONIC Innovair flex D4120 Bedienungsanleitung

System Sensor

System Sensor 22051EI Bedienungsanleitung

System Sensor

System Sensor 6424 Technische Daten

System Sensor

System Sensor 1400 Bedienungsanleitung

System Sensor

System Sensor BEAM1224SA Bedienungsanleitung

System Sensor

System Sensor 1412A Bedienungsanleitung

Beliebte Rauchmelder Handbücher anderer Marken

x-sense

x-sense SD19-W Bedienungsanleitung

BRK electronic

BRK electronic First Alert P1010 Bedienungsanleitung

FireAngel

FireAngel Thermoptek ST-622 Bedienungsanleitung

teko

teko Astra-42A Bedienungsanleitung

Safetec

Safetec SDS-2/6 Betriebsanleitung

Siemens

Siemens PE-11C Bedienungsanleitung

Resolution Products

Resolution Products RE612 CryptiX Bedienungsanleitung

First Alert

First Alert PC900V Bedienungsanleitung

Eminent

Eminent EM6590 E-Domotica Bedienungsanleitung

Ei Electronics

Ei Electronics Ei Ei168RC Bedienungsanleitung

Carrier

Carrier Kidde Quell Q301 Bedienungsanleitung

VESDA

VESDA VLF-500 Bedienungsanleitung

ELRO

ELRO FS8110 Bedienungsanleitung

Heiman

Heiman SMOKI NS-626PHS Bedienungsanleitung

Regin

Regin SDD-S65 Bedienungsanleitung

Family Gard

Family Gard FG225 Bedienungsanleitung

Greystone

Greystone DSD120 Bedienungsanleitung

Aparton

Aparton ASD-10 Bedienungsanleitung
