T-Mobile Z915 Leitfaden

第1页

第2页

GETTING TO KNOW YOUR MOBILE HOTSPOT

Part

Description

micro-SIM card slot

Install the micro-SIM card.

Charging/USB port

Charge your device.

Connect the client to your Z915 via USB cable.

ON/OFF switch

Slide it to turn on or off your Z915.

LCD screen

It shows the signal type, signal strength, battery, Wi-Fi,

LCD screen

micro-SIM card slot

Charging & USB port

ON/OFF switch

OK key

Back key

Left key

Right key

第3页

etc.

OK key

Press to enter or select an item.

Press to wake the LCD screen up.

Press and hold to unlock or lock the LCD screen.

Left key

Check the on-screen menu from right to left.

Right key

Check the on-screen menu from left to right.

Back key

Go back to the previous screen.

Coverage not available in some areas. Please see coverage details at T-Mobile.com. Device

and screen images are simulated. Capable device is required to achieve 4G speeds.

Reset point

Insert a pin and hold it for 3

seconds to reset your device.

第4页

INDICATORS

Indicates that your Mobile HotSpot

is on T-Mobile’s 2G network.

Indicates that your Mobile HotSpot

is connected to the Internet.

Indicates that your Mobile HotSpot

is on T-Mobile’s 3G network.

Wi-Fi status and number of the

connected users.

Indicates that your Mobile HotSpot

is on T-Mobile’s 4G network.

Battery power indication.

Indicates that your Mobile HotSpot

is on T-Mobile’s 4G LTE network.

Indicates that the battery power is

full.

Connected to the Internet

automatically.

Shows and checks the device

information.

Connected to the Internet manually.

Shows and checks the data

connection information.

第5页

There is no signal.

Shows and checks the clients

connected to your device.

Network signal strength.

Set the WPS function.

There are new messages or unread

messages.

Set your device.

The message inbox is full.

SET UP YOUR MOBILE HOTSPOT

1. Lift the micro-SIM card cover and Install the micro-SIM

card.

第6页

2. Power on.

Charge your Mobile HotSpot

You can charge your Mobile HotSpot using the charger included in the

box or by plugging it into your computer using the USB cable.

Slide to turn on

第7页

CONNECT & GO

Connect your Wi-Fi device to your Mobile HotSpot

1. Power on your Mobile HotSpot.

2. On your computer or other Wi-Fi enabled device, search

for available Wi-Fi Networks and select the default

Network Name (SSID) for your Mobile HotSpot.

3. Enter the default password and click OK

Note

It may take up to a minute to establish a connection

The default Network Name (SSID) and password will appear

in the screen on your Mobile HotSpot

4. Open a web browser and go to

www.T-Mobile.com/ConnectMe



Simply

the

on-screen

instr

uctions

set

your

Annual

Contract

data

service.

Note: Service or use is your agreement to T-Mobile’s Terms and Conditions.

T-Mobile requires ARBITRATION of disputes UNLESS YOU OPT-OUT WITHIN

30 DAYS OF ACTIVATION. See T-Mobile’s Terms and Conditions for details at

www.T-Mobile.com/terms-conditions.

第8页

MANAGING YOUR MOBILE HOTSPOT

Access T-Mobile 4G LTE Mobile HotSpot

You can access your 4G LTE Mobile Hotspot device information, using an Internet browser.

To access via Wi-Fi, do the following:

1. Connect to your hotspot device via Wi-Fi using the network connection software on

your computer. Enter the Wi-Fi network password if requested.

2. Open a browser and enter http://Mobile.Hotspot in the address bar. The T-Mobile

4G Mobile Hotspot login screen appears.

3. Enter your Password in the field provided. The default password is admin.

第9页

4. Select the Save Password checkbox if you wish to bypass the login screen in the

future.

5. Click Login. If you entered the correct password, the Dashboard screen appears.

To access via USB cable, do the following:

1. Connect your hotspot device to the PC with the USB cable.

2. Power on your device.

3. Your computer's operating system detects and recognizes new hardware (your

hotspot device) and finishes the installation automatically. After successful

installation, the icon will appear on your desktop.

NOTE: If the system does not launch installation automatically, you can run the

installation program in path of My Computer > Mobile Hotspot.

4. Double-click the icon to open the login screen.

5. Enter your Password in the field provided. The default password is admin.

6. Select the Save Password checkbox if you wish to bypass the login screen in the

future.

7. Click Login. If you entered the correct password, the Dashboard screen appears.

Change Mobile Hotspot Admin Password

1. Access http://Mobile.Hotspot

2. Click Settings in the navigation area.

3. Select the Device Settings tab.

第10 页

4. Follow the steps under Account Management to update your Password.

5. Click Apply. If everything is entered correctly, theAdmin Password Changed

dialog appears indicating the password was successfully changed.

Change Mobile Hotspot Network Name (SSID)

1. Access http://Mobile.Hotspot.

2. Click Settings in the navigation.

3. Select the Wi-Fi Settings tab.

4. Change the name that appears in the Network Name (SSID) field in the SSID

area.

5. Select or deselect the Broadcast Network Name (SSID) checkbox to enable or

disable broadcasting the hotspot’s Network Name (SSID).

6. Click Apply to save your changes on the Wi-Fi Settings tab of the Settings screen.

Change Mobile Hotspot Wi-Fi Password

1. Access http://Mobile.Hotspot.

2. Click Settings in the navigation area.

3. Select the Wi-Fi Settings tab.

4. Change the value that appears in the Password field in the SSID area.

5. Click Apply to save your changes on the Wi-Fi Settings tab of the Settings screen.
