Takegawa 09-12-1010 Bedienungsanleitung
COPY
‑1‑ Mar./29/07
◎Please be informed that, mainly because of improvement in performance, design changes, and cost increase, the product specifications and
prices are subject to change without prior notice.
◎This manual should be retained for future reference.
・Thank you for purchasing one of our TAKEGAWA-made products. Please strictly follow the following instructions in installing and using the parts.
・Before installing the products, please be sure to check the their contents. Should you have any questions about the products, please contact your
local motorcycle dealer.
Read all instructions first before starting the installation.
○This rear stand, for performing maintenance of motorcycles, is made of lightweight aluminum, coming with a caster.
○This maintenance stand weighs as light as about 2 kg, and is strong and rigid, being made of aluminum.
○The width of the stand is adjustable in 5 steps from 222 mm to 258 mm to meet the swing arm width.
This rear stand matches any kinds of swing arms from a stock swing arm on the Monkey and Ape to our aluminum swing arm.
○The rubber hook of the bracket is anti-slip finished with grooves. And the caster with 6 spokes comes in two colors: clear red and black.
Both the rubber hook and the caster have an original logo on each of them.
○As this rear stand is designed for use with 12-inch or smaller tires, it is compact in size and light in weight. This stand is for mini bikes only, being easy
to handle even when loading onto a space-limited car.
〜Features〜
◎This stand is designed and manufactured solely for motorcycle maintenance. Therefore, do not place this stand under the weight of more than the
body weight such as getting on the motorcyle or kick-starting with the motorcycle placed on the stand. Otherwise, the stand may get damaged or
break.
◎As the caster is attached to this product, be sure to use this stand on level, even ground.
◎We do not take any responsibility for any accident or damage whatsoever arising from the use of the products not in conformity with the instructions
in this manual.
◎We shall be held free from any responsibility or compensation whatsoever for any glitch in the parts other than ours if the glitch takes place after the
installation and use of these products.
◎If you make modifications to any product, we shall be held free from any guarantee of the product.
Instruction Manual for
Aluminum Rear Stand with Caster
Item No.
Fits ：０９−１２−１０１０
：for general use, but limited to bikes
with tire sizes of 8 to 12 inches
・Always start the engine in a well-ventilated place, and do not turn on the engine in an airtight place.
(Otherwise, you will suffer from carbon monoxide poisoning.)
・Before doing work, make sure your motorcycle is secure on level ground for safety's sake.
(Otherwise, your motorcycle could overturn and injure you while you are working.)
・Keep plastic bags for packing the products out of children's reach, or discard them.
(If children get them on, there will be a danger of their suffocating.)
The following show the envisioned possibility of human death or serious injuries to human bodies as a result of disregarding the
following warnings.
WARNING
COPY
‑2‑ Mar./29/07
Kit includes:
〜Handling Instructions〜
※Please order repair parts by indicating the Repair Part Item No. as listed above.
As you see from the list, there are some parts for which we are not in a position to accept
your order in the quantity of one. In this case, please order the required parts as a set part
unit.
●Precautions for handling
・To make the space between swing arm and bracket as small as possible,
adjust the space by changing the locations of the spacers (No.6).
・Place 10mm washers (No.7) so they sandwitch the rear-stand frame at
both sides of the frame.
・If the holder S (No.4) holding the bracket (No.5) gets loose, ease the socket
cap screw (No.9) and adjust the angle. And fasten them.
Tightening torque: 8〜10 N・m (0.8 〜1.0 kgf・m)
●Adjustment of the rear stand width:
１
２３
４５
６
７８
９
１０
１１
No. Part Name Qty Repair Part Item No. in packs of
1Main pipe COMP. 1
2Caster Comp. 4
3Hinge pins 2
4Holders S 2
5Brackets 2
6Spacers 450508-MRS-T00 1
7Washers, 10 mm 4BW-01-0003 10
8Snap pins, 10 mm 2
9Socket cap screws, M6 x 20 2BW-00-0015 10
10 Washers, 6 mm 2BW-01-0001 10
11 Snap rings, 10 mm 4
・Before using this rear stand, carefully place the stand on safe level
ground for safety’s sake.
・Before placing your motorcyle on this rear stand, be sure to set the
width of this stand to meet the swing arm width. Otherwise, the motor
cycle may fall off the rear stand or overturn.
・Immediately wipe off the oil, grease and chemicals if these
substances adhere to the caster or bracket. Otherwise, these
substances may cause the materials to deteriorate or cause your
motorcycle to skid.
・Prior to placing your motorcycle on this stand, check that no grease is
on the rubber of the bracket or on the lower part of the swing arm
(where the bracket is fixed).
(The adhering oil or grease causes the motorcycle to skid, to fall off
the rear stand or to overturn while you are working.)
・This stand is designed and manufactured solely for motorcycle
maintenance. Therefore, do not place this stand under the weight of
more than the body weight such as getting on the motorcyle or kick-
starting with the motorcycle placed on the stand. (Otherwise, the rear
stand may get damaged or motorcycle may fall down.)
The following show the envisioned possibility of
injuries to human bodies and property damage as
a result of disregarding the following cautions.
CAUTION
６６ ７
９
about 222 to 258 mm
about146to182mm
3-5-16 Nishikiorihigashi Tondabayashi Osaka Japan
TEL : 81-721-25-1357 FAX:81-721-24-5059
URL : http://www.takegawa.co.jp
