1. Outline
●CCD line scan camera with 2048 pixels of image sensor and of 40MHz data rate.
●Digital video signal (10 bit) and analog video signal (0 to 2.5V at 75Ω-terminated) are delivered at a time
as in the case of UFD series camera.
2. Features
●Restriction on the encoder signal specs is significantly relaxed as the asynchronous shutter function is
incorporated. Hence, clear images can be obtained even when the line speed of the object is not stable.
●Equipped with anti-blooming function.
●Sensitivity can be changed from 50 to 400 V/Lux·sec in 4 steps. (Factory default :100 V/Lux.sec)
●The equipment operates with a single DC12V power source.
●Best suited usage for different purposes is feasible as the GAIN setting can be changed in the x1 to x 8
sensitivity range.(1,2,4,8-fold).
●A pixel size is small enough (10μm×10μm) to capture high-definition images.
3. Applications
●Image input device for image processor
●Appearance inspection device
●Dimensional measurement device
●Surface inspection device for sheet-like object
