Tally Dascom 7010 Bedienungsanleitung

User Guide 7010 Thermal Printer

7010

7010-300 7010R

Maintenance Manual 7010 Series

iii

CHAPTER 1SPECIFICATIONS

CHAPTER 2 OPERATING PRINCIPLES

CHAPTER 3 DISASSEMBLYAND MAINTENANCE

CHAPTER 4 TROUBLESHOOTING

CHAPTER 5 PARTS LISTS

CHAPTER 6 CIRCUIT DIAGRAMS

APPENDICES

Safety Precautions

To prevent personal injury or property damage, the following shall be strictly observed.

The degree of possible injury and damage due to incorrect use/maintenance or improperly

following instructions is described below.

Indicates a situation which, if not observed and handled properly, could

result in death or serious injury.

Indicates a situation which, if not observed and handled properly, could

result in injury or property damage.

: This is a mark to call attention to the reader.

- Before starting disassembly/reassembly or mechanical adjustment, be sure to

disconnect the power cord from the power source.

- Do not replace a fuse with the power switch turned on.

- When replacing a fuse, use the same rating and type since it is provided to prevent

fire and damage to the Unit, Power Supply.

- DO NOT adjust VR1, VR2, VR3 and VR4 on the SA, Main PCB. (Leave them at the

factory setting condition.) If it is turned, media sensor sensitivity is changed and the

media detection will not be correctly made.

- Do not disassemble/reassemble or adjust the machine, if it functions properly.

Particularly, do not loosen screws on any component, unless necessary.

- After completing an inspection and before turning on the power, be sure to check that

there is no abnormality.

- Never try to print without media.

- Check that the media is properly set.

- Do not lay anything on the cover or lean against it during maintenance or while the

printer is in operation.

- During maintenance, be careful not to leave parts or screws unattached or loose

inside the printer.

- When handling a printed circuit board, do not use gloves, etc., which can easily

cause static electricity. Since ICs, such as CPU, RAM and ROM, might be destroyed

by static electricity, do not touch lead wires or windows unnecessarily.

- Do not put the printed circuit boards directly on the printer or on the floor.

- When disassembling or reassembling, check wires for any damage and do not pinch

or damage them. Also, run wires as they were.

Warning

Caution

Warning

Caution

CHAPTER 1

SPECIFICATIONS

1-2

Chapter 1 Specifications

Table of Contents

1-1. General Specifications......................................................................................................1-3

1-2. Printable Area ...................................................................................................................1-9

1-3. Printing Position Accuracy................................................................................................1-10

1-4. Adjustable Sensors/Front Fixed Sensor...........................................................................1-11

1-1. General Specifications

1-3

1-1. General Specifications

Printing

Printing method Thermal transfer/Direct thermal

Main scanning line density:

203 dots/inch (8 dots/mm) (7010/7010R)

300 dots/inch (11.8 dots/mm) (7010-300)

Sub-scanning line density:

203 dots/inch (8 dots/mm) (7010/7010R)

300 dots/inch (11.8 dots/mm) (7010-300)

Resolution

Head 864 dots (printable dots: 832 dots) (7010/7010R)

Head 1275 dots (printable dots: 1240 dots) (7010-300)

Max. print width 104 mm (7010/7010R)

105 mm (7010-300)

4.1 inch (7010/7010R)

4.1 inch (7010-300)

Max. print length 812.8 mm 32 inch

Print density Print density is adjustable with software

Printing speed setting 2 - 10 inches per second (7010/7010R)

2 - 8 inches per second (7010-300)

Print mode

Batch mode Normal printing (single or multiple sheets)

Tear off mode Feeds back media to the tear-off position after printing is completed.

Cut mode *1Prints while cutting at designated sheet units.

The following two kinds of cut mode operations are done.

• Back feed

• Cut through

(Cut through refers to stopping part-way through printing the ‘next

label’ to make the cut. After cutting, printing restarts but there is a

chance of a small gap or mark at the temporary stop position.)

Peel mode*2Peels labels from the liners after printing them.

Media

Types of media Roll, fanfold

(continuous media, die-cuts, continuous tags, paper or tickets)

Recommended media Thermal transfer:

Direct thermal media:

Max. media width 118.0 mm 4.65"

Min. media width 25.4 mm 1.00"

Min. label width 7.62 mm 0.30"

*1,*2:Options can be separately purchased.

1-1. General Specifications

1-4

Min. label pitch*36.35 mm 0.25"

Max. media thickness 0.254 mm 0.01"

Max. media length 812.8 mm 32"

Min. media length 6.35 mm 0.25"

Min. media thickness 0.0635 mm 0.0025"

Media (continued) Max. outside diameter:

203 mm

On-board roll media

diameter Media core: 38 to 76 mm 1.5 to 3"

Rewinding roll media

diameter (7010R

only)

Media core: 26, 40, or 45 mm 1.02, 1.57, or 1.77”

Ribbon

Recommended ribbon

Max. ribbon width 114.0 mm 4.50"

Min. ribbon width 25.4 mm 1.00"

Min. ribbon length 450.0 m 1,476 ft

Max. roll diameter 86.5 mm 3.40"

Inner diameter of the

paper core 25.4 ±0.25 mm 1.00 ±0.01"

Ribbon end tape

length Max. 80.0 mm 3.15"

Ribbon end detection Ribbon out is detected by the ribbon sensor.

Bar code

For Datamax®emulation*4

One-dimension • Code 3 of 9 • UPC-A • UPC-E • EAN-13 (JAN-13)

• EAN-8 (JAN-8) • Interleaved 2 of 5 • Code 128

• HIBC (Modulus 43-used code 3 of 9) • Codabar (NW-7)

• Int 2 of 5 (Modulus 10-used Interleaved 2 of 5) • Plessey

• Case Code • UPC 2DIG ADD • UPC 5DIG ADD

• Code 93 • Telepen • ZIP • UCC/EAN 128

• UCC/EAN128 (for K-MART)

• UCC/EAN128 Random Weight • FIM

Two-dimension • UPS Maxi Code • PDF-417 • Data Matrix • QR Code • Aztec

• RSS

*3: When a media pitch of less than 1" is used, activate the "Small Label Printing" setting in

the "Printing Setting".

*4: Datamax®is a registered trademark of Datamax Bar Code Products Corporation.

1-1. General Specifications

1-5

Bar code (continued)

For Zebra®emulation*5

One-dimension • Code 11 • Interleaved 2 of 5 • Code 39 • EAN-8 • UPC-E

• Code 93 • Code 128 • EAN-13 • Industrial 2 of 5

• Standard 2 of 5 • ANSI CODABAR • LOGMARS • MSI • Plessey

• UPC/EAN Extensions • UPC-A • POSTNET • Planet

Two-dimension • Code 49 • PDF-417 • CODA BLOCK • UPS Maxi Code

• Micro PDF-417 • Data Matrix • QR Code • R SS • TLC39

Font

For Datamax®emulation*4

1. Seven kinds of fixed pitch font

Overseas, English fonts and European fonts

2. OCR fonts

OCR-A*

6, OCR-B*6

3. Proportional fonts

CG TriumvirateTM smooth font

CG TriumvirateTM Bold smooth font

(6, 8, 10, 12, 14, 18, 24, 30, 36, 48 points) (7010/7010R)

(4, 5, 6, 8, 10, 12, 14, 18, 24, 30, 36, 48 points) (7010-300)

• Character set: Conforms with code page 850 standards

4. TrueTypeTM rasterizer *7

For Zebra®emulation*5

1. Five kinds of fixed pitch font

Overseas, English fonts and European fonts

2. OCR fonts

OCR-A, OCR-B

3. Proportional font

CG TriumvirateTM Condensed Bold

4. True type™ rasterizer*7

*5: Zebra®is a registered trade mark of ZIH corp.

*6: The OCR font may have a low recognition rate according to the reader.

*7: It is equipped with UFSTTM and TrueTypeTM rasterizer that are licensed from Monotype

Imaging, Inc.

TrueTypeTM is a trademark of Apple Computer.

UFSTTM and CG TriumvirateTM are trademarks of Monotype Imaging, Inc.

1-1. General Specifications

1-6

Symbol set

PC866U Ukraina, PC Cyrillic, ISO 60 Danish/Norwegian, DeskTop,

ISO 8859/1 Latin 1, ISO 8859/2 Latin 2, ISO 8859/9 Latin 5, ISO

8859/10 Latin 6, ISO 8859/7 Latin/Greek, ISO 8859/15 Latin 9, ISO

8859/5 Latin/Cyrillic, ISO 69: French, ISO 21: German, ISO 15:

Italian, Legal, Math-8, Macintosh, Math, PC-858 Multilingual,

Microsoft Publishing, PC-8, Code Page 437, PC-8 D/N, Code Page

437N, PC-852 Latin 2, PC-851 Latin/Greek, PC-862 Latin/Hebrew, Pi

Font, PC-850 Multilingual, PC-864 Latin/Arabic, PC-8 TK, Code Page

437T, PC-1004, PC-775 Baltic, Non-UGL, Generic Pi Font, Roman-8,

Roman-9, ISO 17: Spanish, ISO 11: Swedish, Symbol, PS Text, ISO

4: United Kingdom, ISO 6: ASCII, Ventura International, Ventura

Math, Ventura US, Windows 3.1 Latin 1, Wingdings, Windows 3.1

Latin 2, Windows 3.1 Baltic (Latv, Lith), Windows 3.0 Latin 1,

Windows Latin/Cyrillic, Windows 3.1 Latin 5

Control language

Conforms to Datamax®programming language*4and Zebra®

programming language*5

Outline of electronic devices

CPU 32-bit RISC CPU

ROM Standard equipment: FLASH ROM 4M bytes (User area: 1M byte)

RAM Standard equipment: SDRAM 16M bytes (User area: 1M byte)

RAM (for Zebra®L) Standard equipment: SDRAM 16MBytes (User area: 4M byte)

Media detection sensors

Transparent sensor Detects media gap between labels, notches on tags, and media out

Reflective sensor Detects reflective mark on back of media and media out

Label peeling sensor *1

Communication interfaces

Parallel*8IEEE1284 (Compatible, Nibble, ECP mode)

Serial 2400 4800 9600 19200 38400 57600 115200 bps

USB FULL Speed USB1.1

Communication interface options

Network Wired Ethernet (10-BASE-T/ 100-BASE-TX) or Wireless LAN

*8: This interface is Non-L. P. S. (Limited Power Source).
