Tanaka TBL-7600/R Einrichtungshandbuch
IllustrIllustr
IllustrIllustr
Illustraa
aa
ated Pted P
ted Pted P
ted Parar
arar
arts Mants Man
ts Mants Man
ts Manualual
ualual
ual
Model Number:
TBL-7600/R
BACKPACK BLOWER
P/N 32769
Rev 000
Date 5-4-07
Nikko Tanaka Engineering U.S.A.,Ltd.• 1028 4th Street SW, Bldg B • Auburn, WA98001 • Phone: (253) 333-1200 • Fax: (253) 333-1212
www.tanakapowerequipment.com [email protected]
www.tanakapowerequipment.com
PARTSINFORMATION
Page 1
TBL-7600
CYLINDER, PISTON, CRANKSHAFT • FIGURE 1
www.tanakapowerequipment.com
PARTSINFORMATION
Page 2
TBL-7600
CYLINDER, PISTON, CRANKSHAFT • FIGURE 1
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
1-2 0011600090 CYLINDER SET 1 Includes gasket
1-4 0171600020 GASKET,CYLINDER 1
1-9 8131600020 BOLT 4
1-14 0301600090 PISTON SET 1 Includes rings & circlips
1-15 0371600020 PISTON PIN 1
1-16 0411600090 RING,PISTON SET 1
1-17 0461600080 CRANKSHAFT 1
1-18 8001600020 BEARING,NEEDLE 1
1-20 0391600020 CIRCLIP 2
1-21 0601600020 SPACER 2
1-22 0161600020 COVER,CYLINDER 1
1-23 7381600080 PROTECTOR,MUFFLER 1
1-24 8121600020 BOLT 2
1-25 8111600020 SCREW 1
1-26 8311600020 WASHER 2
1-27 8301600020 WASHER,A 2
1-28 7381600020 COVER,PLUG 1
1-30 2511600020 CAP,SPARK PLUG 1
1-31 2521600020 TERMINAL,SPARK PLUG 1
1-36 8411600020 TUBE,PROTECTION 1
1-37 0181271020 PLUG,SPARK 1
1-39 2021600020 GROMMET,B 1
www.tanakapowerequipment.com
PARTSINFORMATION
Page 3
TBL-7600
CRANKCASE, FLYWHEEL, IGNITION • FIGURE 2
www.tanakapowerequipment.com
PARTSINFORMATION
Page 4
TBL-7600
CRANKCASE, FLYWHEEL, IGNITION • FIGURE 2
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
2-3 0901600020 GASKET,CRANKCASE 1
2-5 0721600090 CRANKCASE 1
2-7 8011600020 BEARING,BALL 2
2-8 0441600020 SEAL,OIL 2
2-10 8061600020 SCREW,A 1
2-11 8141600020 SCREW 4
2-12 8401600020 KNOCK PIN 2
2-13 8201600020 PACKING 1
2-19 8021600020 SHIM,CRANKSHAFT V
2-19 8031600020 SHIM,CRANKSHAFT V
2-19 8041600020 SHIM,CRANKSHAFT V
2-19 8051600020 SHIM,CRANKSHAFT V
2-29 1551600080 MAGNETO 1
2-32 1671600080 COIL,IGNITION 1
2-33 8421600020 WIRE 1
2-34 8431600020 WASHER,S 1
2-35 0681600020 KEY,WOODRUFF 1
2-38 2031600020 GROMMET,A 1
2-40 8151600020 BOLT 2
2-41 8291600020 NUT 1
2-54 7981600090 PULLEY ASSY,STARTER 1
2-55 2581600020 RING,STOP 1
2-56 7661600020 SPRING,STARTER PAWL 1
2-57 7651600020 PAWL,STARTER 1
2-58 0321600020 NUT,SPECIAL 1
2-59 8321600020 WASHER,C 2
www.tanakapowerequipment.com
PARTSINFORMATION
Page 5
TBL-7600
CARBURETOR & MUFFLER • FIGURE 3
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
3-1 8181600020 GASKET,MANIFOLD 1
3-2 8191600090 INTAKE MANIFOLD SET 1
3-3 8171600020 SCREW 2
3-4 4031600020 GASKET,INSULATOR 1
3-5 8281600020 NUTS 2
3-6 8261600020 BOLT 2
3-7 4041600090 INSULATOR,SET 1
3-8 4021600020 GASKET,CARBURETOR 1
3-9 4551600090 CARBURETOR SET 1 Includes gasket
3-42 7041600090 MUFFLER SET 1
3-43 8101600020 SCREW 4
3-44 7321600020 ARRESTER,SPARK 1
3-45 7511600020 GASKET,TAIL PIPE 1
3-46 8261600020 BOLT 2
3-47 7371600020 GASKET,MUFFLER 1
3-48 8271600020 SCREWS 1
3-49 4361600020 BASE,CLEANER 1
3-50 8081600020 SCREW 1
3-51 4761600020 BOARD,CHECK 1
3-52 8091600020 SCREW 2
3-55 8351600020 WASHER 2
www.tanakapowerequipment.com
PARTSINFORMATION
Page 6
TBL-7600
STARTER • FIGURE 4
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
4-0 7621600090 STARTER ASSY 1
4-1 7801600020 GUIDE,ROPE 1
4-2 8331600020 STOP,ROPE 1
4-3 7621600020 STARTER BODY 1
4-4 7631600020 PLATE,RECOIL 1
4-5 7851600020 HANDLE,STARTER 1
4-6 7831600020 ROPE,STARTER 1
4-7 7691600020 REEL,STARTER ROPE 1
4-8 7791600020 SPRING,STARTER 1
4-9 8071600020 SCREW,SET 1
4-10 8341600020 WASHER,E 1
4-11 8161600020 SCREW 4
www.tanakapowerequipment.com
PARTSINFORMATION
Page 7
TBL-7600
CARBURETOR • FIGURE 5
0
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
5-0 4551600090 CARBURETOR SET 1 Includes gasket
5-10 5752515380 BODY,PUMP 1
5-11 57825007200 SCREEN,INLET 1
5-17 4752515320 GASKET,DIAPHRAGM 1
5-18 47425001800 DIAPHRAGM,METERING 1
5-19 4422515180 PUMP,PRIMING 1
5-20 44725108200 BULB,PRIMING 1
5-21 4762515120 COVER,DIAPHRAGM 1
5-22 5482515120 SCREW,SET 4
5-23 51425100200 SCREW,THROTTLE SET 2
5-24 54425164200 STAY,ADJUST,CABLE 1
5-25 61425137200 ADJUSTER,CABLE 1
5-26 99101060013 NUT,6 1
5-27 55025100200 O-RING 1
5-28 5992527920 JET,MAIN #52 1
5-29 53925120200 SWIVEL 1
5-30 5492516520 WASHER,THRUST 1
5-31 48925100200 RING,STOP 1
5-32 4310634C200 GASKET,CLEANER 1
5-33 57725100200 GASKET,PUMP 1
5-34 57625100200 DIAPHRAGM,PUMP 1
65025124900 KIT,CARB REPAIR 1
www.tanakapowerequipment.com
PARTSINFORMATION
Page 8
TBL-7600
FRAME • FIGURE 6
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
6-16 0303190020 CUSION,RUBBER,BOTTOM 2
6-26 0193131980 BAND 2
6-27 8123190020 SCREW,G,M6x16 2
6-28 83531900200 NUT,F.M6 2
6-29 0163190020 STAY,BAND 1
6-30 0293131320 NUT,SPECIAL 4
6-31 0213190020 PAD,CUSHION 1
6-32 0463190020 FASTENER 4
6-34 5913190080 TANK,FUEL 1
6-35 5953190090 CAP,TANK 1
6-36 2233190090 PIPE,FUEL ASSY 1
6-37 8153190020 SCREW,J,M5x14 2
6-38 8303190020 WASHER,A 2
6-40 0203190080 FRAME 1
6-41 03031307200 BUFFER 2
6-42 0603190020 COLLAR 2
6-43 8313190020 WASHER PACKING 2
6-44 67531900900 FILTER,FUEL ASSY 1
N/A N/A GROMMET,RETURN 1 Order #36 Fuel Pipe Assy
6-46 6803190020 CLIP 2
N/A N/A PIPE,FUEL A 1 Order #36 Fuel Pipe Assy
N/A N/A PIPE,FUEL B 1 Order #36 Fuel Pipe Assy
6-50 0263190020 WASHER,CAP 2
NOTE - Ring shown
below gas cap is
the cap retainer, not
a gasket.
