TAO 89350 Bedienungsanleitung

ENGLISH

digital photo

Frame

5x7 INCH DIGITAL PHOTO FRAME

Digital Frame User Guide

Please Read This First

This guide explains how to prepare the Digital Photo Frame and

use its basic features

The Components

Preparation

Menus and Settings

Loading Photos (PC)

FOR USE WITH MODELS S U#

89350~89369

Flowchart and Reference Guides

The following guides and support are available. Refer to

them as necessary according to the flowchart below

For information on included

items and items sold separately

The Components Guide

Preparations

asic hardware preparation, func-

tions and settings..

Menus and Settings

Loading Photos/Files

Frequently Asked Questions

Handling precautions, refer-

ences to various slideshow and

media functions

Troubleshooting

Packaging Exterior

asic Manual

TAO Website

asic Manual

TAO Website

www.taoelectronics.com

The Components Guide

Front View

A. Display Screen

Back View

1. Tool utton

2. Next utton

3. Play/Pause

4. Previous utton

5. On/Off utton

6. A/C Adapter Slot

7. US Flash Drive Slot

8. PC connection Slot

The Components Guide

1 2 3 4 5

Overview & Specifications

Features

• Load and display rich color photos in RG

JPEG/JPG format up to 12 megapixel resolution.

• Play your favorite songs as background music to

your photo slideshows.

• Display and rotate photos as full screen stills,

automated slide shows, or as a dynamic split-

screen slide show.

• Rotate and adjust the frame stand to show land-

scape and portrait style photos.

• Display the time and calendar as an overlay to

your favorite photos.

Specifications

Display screen: 5.6" TFT LCD - 320 x 234

Internal memory: 128 M

Photos: 56 ~ 100

Memory cards: CFI, CFII, SD, MMC, MS

Audio: yes ( speaker )

Formats: JPEG, Motion JPEG, MP3.

Frame: Replaceable for any standard 5x7 frame

PC interface: US Host/Slave (2.0, 1.1)

Remote control: yes (RF, radio frequency)

Software: not required

Weight: 2 lb

Dimension:10" x 8" x 2.5" ( varies on the design)

Includes: AC adaptor, remote, US cable, user's manual

Warranty: 1 year Domestic RMA

www.taoelectronics.com

Getting Started

Clock and Setup Menu Overview

• Remove the protective film covering the LCD screen by

lifting the pull tab.

• Plug the included AC Power Adapter into the frame,

and then into a standard110-220 volt AC electrical out-

let.

• Power on the Digital Photo Frame by pressing the

power button on the remote control or the frame.

• If there are photos stored in the internal memory or on

an inserted memory card, a the Thumbnail Screen will

appear.

Preparation

The digital LCD panel has a viewing angle of approximately

25 degrees in either direction. You can achieve a better

viewing angle by ad usting the frame stand height.

• Extend the frame stand to a position for greatest stabil-

ity.

• Extend or retract the strand by pushing the tab on the

stand, and adjusting the length.

• Release the tab to lock the frame into position.

Adjusting the Viewing Angle

Turning the Power On/Off

Turning the Digital Photo Frame On

1. Press the On/Off button.

Turning the Digital Photo Frame Off

Main Menu

1. Press the Tool button on the back of your frame to

enter the Main Menu.

2. Press the Next or Previous button to cycle through

modes.

Photo: Displays Digital Photos as stills, slideshow, or

split-screen slideshow.

Clock: Date and Time settings

Music: Access and play MP3 music files.

Setup: General Settings and Preferences.

1. Connect the AC adapter to a power source.

2. Press the On/Off button (back of the frame).

www.taoelectronics.com

First Time Settings

Clock and Setup Menu Overview.

▪ Press the Previous and Next buttons to select the clock icon.

▪ Press the Play button to select.

(1) Adjusts the date.

(2) Adjusts the time.

(3) Adjusts the alarm time.

(4) Adjusts the auto-on time.

(5) Adjusts the auto-off time.

Preparation

(6) Selects the slide show speed.

(7) Toggles the time display in photo mode.

(8) Toggles the calendar display in photo mode.

(9) Selects the music repeat settings.

(10) Toggles the aspect ratio for photo mode.

(11) Adjusts the volume.

Setting the Date

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Clock

3. Press the Play button to select.

1. Press the Play button to select “DATE”.

2. Press the Previous and Next buttons to cycle

through the year, and press the Play button to

confirm. This will highlight the month.

3. Press the Previous and Next buttons to cycle

through the months, and press the Play button to

confirm. This will highlight the day.

4. Press the Previous and Next buttons to cycle

through the days, and press the Play button to

confirm.

www.taoelectronics.com

Menus and Settings

Setting the Time

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Clock

3. Press the Play button to select.

1. Press the Next button to highlight “TIME”, and

press the Play button to select.

2. Press the Previous and Next buttons to cycle

through the hours, and press the Play button to

confirm. This will highlight the minutes.

3. Press the Previous and Next buttons to cycle

through the minutes, and press the Play button to

confirm. This will highlight the seconds.

4. Press the Previous and Next buttons to cycle

through the seconds, and press the Play button to

confirm.

Setting the Alarm

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Clock

3. Press the Play button to select.

1. Press the Next button to highlight “Alarm”, and

press the Play button to select.

2. Press the Previous and Next buttons to cycle

through the hours, and press the Play button to

confirm. This will highlight the minutes.

3. Press the Previous and Next buttons to cycle

through the minutes, and press the Play button to

confirm. This will highlight the seconds.

4. Press the Previous and Next buttons to cycle

through the seconds, and press the Play button to

confirm.

www.taoelectronics.com

Menus and Settings

Setting the Auto On and Off Time

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Setup

Alarm.”

3. Press the Play button to select.

ote: The Auto-On Feature is used in conjunction with

the Auto-Off Feature, and is designed to turn the frame

off for a period of time each day. The main power

switch must be turned ON for this feature to work.

When the Auto On Time is turned on, the frame will

automatically turn on at the specified time.

1. Press the Next button to highlight “Auto on”, and

press the Play button to select.

2. Press the Previous and Next buttons to cycle

through the hours, and press the Play button to

confirm. This will highlight the minutes.

Cont. Setting the Auto On and Off Time

3. Press the Previous and Next buttons to cycle through the

minutes, and press the Play button to confirm. This will

highlight the seconds.

4. Press the Previous and Next buttons to cycle through the

seconds, and press the Play button to confirm.

5. Press the Previous and Next buttons to toggle between

having the Auto On feature ON or OFF, and press the

Play button to confirm.

6. Press the Next button to select “Auto off.”

When the Auto Off Time is turned on, the frame will automati-

cally turn Off at the specified time.

1. Press the Next button to highlight “Auto off”, and press the

Play button to select.

2. Press the Previous and Next buttons to cycle through the

hours, and press the Play button to confirm. This will

highlight the minutes.

3. Press the Previous and Next buttons to cycle through the

minutes, and press the Play button to confirm. This will

highlight the seconds.

4. Press the Previous and Next buttons to cycle through the

seconds, and press the Play button to confirm.

5. Press the Previous and Next buttons to toggle between

having the Auto On feature ON or OFF, and press the

Play button to confirm.

www.taoelectronics.com

Menus and Settings

Setting the Slide Show Transition Speed

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Setup .”

3. Press the Play button to select.

1. Press the Play button to select “Slide Interval”.

2. Press the Previous and Next buttons to toggle

between the different time seetings and press the

Play button to confirm.

• 5 sec 5 seconds between photos.

• 10 sec 10 seconds between photos.

• 30 sec 30 seconds between photos.

• 60 sec 60 seconds between photos.

Toggling Clock and Calendar Overlay

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Setup .”

3. Press the Play button to select.

When the Show Time or Show Calendar modes are

turned ON, the clock or calendar overlays will appear

during photo mode. Turn these modes off to display

photos only.

1. Press the Play button to select “Show Time”.

2. Press the Previous and Next buttons to toggle

between ON or OFF and press the Play button to

confirm.

3. Repeat this process for “Show Calendar”.

www.taoelectronics.com

Menus and Settings

Music Repeat

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Setup .”

3. Press the Play button to select.

1 Press the Play button to select “Music Repeat.”

2 Press the Previous and Next buttons to toggle

between the Music Repeat modes and press the

Play button to confirm.

one: Music will end once the current song is over

One: The current song will play repeatedly.

All: Songs will play in alphabetical order, and

repeat once the last song has finished.

Selecting Aspect Ratio

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Setup .”

3. Press the Play button to select.

1 Press the Play button to select “Aspect

2 Press the Previous and Next buttons to toggle

between the Aspect modes and press the Play

button to confirm.

Available view modes:

4:3 (default)

16:9

www.taoelectronics.com

Menus and Settings

Adjusting the Volume

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Setup .”

3. Press the Play button to select.

1 Press the Play button to select “Volume.”

2 Press the Previous and Next buttons to toggle

between the numbers and press the Play button

to confirm.

Volume numbers are on a 0-9 scale, with 0 as a muted

state, and 9 as the loudest.

Photo Mode

This mode displays a grid of photos in clusters of 9.

You can toggle through different view modes by

pressing the Play utton, and the current view mode

will appear on the upper-right corner of the screen.

FullSize: View a single photo, and press next/

previous to cycle images.

SlideShow: View photos as a slide show.

SplitShow: View photos in a split-screen slide

show.

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Photo.”

3. Press the Play button to select.

www.taoelectronics.com

Menus and Settings

Music Menu

1. Press the Tool utton to enter the Main Menu.

2. Use the Previous and Next buttons to select “Music .”

3. Press the Play button to select.

1. Press the Next and Previous buttons to cycle

through songs.

2. Press the Play button to play the selected song.

Volume and Music Repeat settings can be changed in

the Setup Menu. (pg. 13, 15)

Memory Cards and USB Flash Drives

With your TAO Digital Photo Frame, you are able to display

photos directly from your memory card or US Flash.

The memory card slots are located on the side of your digi-

tal photo frame, and are labeled for your convenience.

Simply insert the memory card or US flash drive, and enter

the Photo mode to view your photos.

Andere Handbücher für 89350

Dieses Handbuch passt für folgende Modelle

Andere TAO Digitaler Bilderrahmen Handbücher

TAO

TAO 89350 Bedienungsanleitung

TAO

TAO 83000 Bedienungsanleitung

Beliebte Digitaler Bilderrahmen Handbücher anderer Marken

LENCO

LENCO DF-830 Bedienungsanleitung

NIX

NIX Advance X10G Bedienungsanleitung

Nextar

Nextar N7S-100 Bedienungsanleitung

Sungale

Sungale TD350A Bedienungsanleitung

texet

texet DPF-830 Montageanleitung

Philips

Philips SPF2017 Bedienungsanleitung

Philips

Philips SPF1327 Bedienungsanleitung

Philips

Philips SPF7010/10 Bedienungsanleitung

Digital Spectrum

Digital Spectrum MemoryVue MV-1500 Bedienungsanleitung

ViewSonic

ViewSonic VFM1042-52 Bedienungsanleitung

YURAKU

YURAKU YUR.PHOTO 7B4C Bedienungsanleitung

Denver

Denver PFF-710WHITE MK2 Bedienungsanleitung

Pandigital

Pandigital PAN8000DWPCF1 Bedienungsanleitung

Rekam

Rekam Deja View HD-850 Bedienungsanleitung

Majestic

Majestic DF 918HD MP3 Bedienungsanleitung

ViewSonic

ViewSonic DPF8-CAM Bedienungsanleitung

Philips

Philips SPF2527 Bedienungsanleitung

Digital Foci

Digital Foci Image Moments IMT-063 Bedienungsanleitung
