Targa 19" Bedienungsanleitung
LCD-DISPLAY 19"
User manual
GB
IE
CY
Targa Visionary LCD 19-4 Wide
6_tft_19-4_0710.qxd:hb_sc_nb_traveller-kit.qxd 22.10.2007 13:00 Uhr Seite 1
Targa Visionary LCD 19-4 Wide
1
English
Operating Notes
First of all, many thanks for choosing this high-end multiscan
monitor. Before starting installation, please read this manual
completely.
Intended Use
This TFT monitor is an IT electronic device. It may only be used for
private use, not industrial or other commercial purposes.
Furthermore, the device may not be used outdoors or in tropical
climates. Only connection cables and external devices may be
used that comply with safety standards and the electromagnetic
compatibility and shielding quality of this device. This device fulfils
all that relates to CE Conformity, relevant norms and standards.
Any changes to the equipment other than the recommended
changes by the manufacturer may lead to the result that these
directives are not met any more. Only use accessories
recommended by the manufacturer.
Conformity
The LCD screen LCD 19-4 Wide has been tested
and approved for compliance with the basic and
other relevant requirements of the EMC Directive
2004/108/EC and the Low-voltage Directive
2006/95/EC.
Targa Visionary LCD 19-4 Wide
2
English
Table of Contents
Operating Notes.............................................................................. 1
Intended Use ............................................................................................1
Conformity ................................................................................................1
Table of Contents ........................................................................... 2
Safety Information........................................................................... 3
Warnings...................................................................................................3
Disposal of Old Devices ...........................................................................5
Getting Started................................................................................ 6
Back Panel Connectors............................................................................7
Quick Guide..............................................................................................7
Setting the Resolution ..............................................................................8
Front Panel Controls.................................................................................9
Setting the Menu Language ...................................................................10
Button Function Overview ......................................................................11
OSD Menu.................................................................................... 12
Contrast/Brightness................................................................................12
Advanced...................................................................................... 15
Supported resolutions.............................................................................15
Wall-Mounting.........................................................................................16
Technical Specifications.........................................................................17
Troubleshooting......................................................................................18
Pixel Error Classes.................................................................................18
Targa Visionary LCD 19-4 Wide
3
English
Safety Information
During the manufacturing and testing of this monitor, the safety of
the future user was our main goal. However, inadequate operation
or installation can cause damage to the device and harm to the
user. Therefore, please first read the following warnings prior to
starting with its installation. Proceed exactly as described in the
instructions. Keep this manual for any future reference.
Warnings
•Connect the monitor to a grounded wall outlet only, with a
rating identical to those on the label of the back panel of the
unit. If you are not sure about the electrical output, please
contact a qualified electrician or your local electrical company.
•Warning: The wall outlet must be within easy reach and next to
the device.
•Do not use any extension cords.
•Only use accessories recommended by the manufacturer
(cables, stand, cart, etc.).
•Move the device carefully to avoid it from tipping over.
•For your own safety, remember that the monitor will be fully
separated from the mains only when the power cord has been
disconnected from the wall outlet.
•During a thunderstorm, unplug the device from the mains
power by unplugging the power cord. Do this also when you are
not going to use the device for a long period of time.
•Do not attempt to repair the monitor yourself. Any repair must
be performed by a qualified technician.
Targa Visionary LCD 19-4 Wide
4
English
•Do not open the monitor’s housing. The high-voltage
components inside the device may produce an electric shock
even after the power cord has been disconnected.
•Do not use the device if the casing is damaged. If this happens,
it must first be examined by authorized service personnel.
•Place the monitor in a clean, dry environment.
•Do not place any recipients containing liquids (beverages,
vases, etc.) onto or next to the device.
•Do not place any fire sources (e.g. burning candles) on or near
the device.
•Disconnect the power supply immediately if liquid gets into the
device and seek the help of a service technician.
•Unplug the device from the mains before cleaning the monitor.
First spray an ammoniac-free detergent onto a cloth to slightly
dampen it, and do not spray it onto the display itself.
•Do not place the monitor next to any magnetic objects, electric
motors, TV sets or transformers.
•Do not place the device near heat sources such as radiators,
ovens or other appliances emitting heat.
•Do not place heavy objects on the cable or power supply.
Position the cables so that they cannot obstruct or catch
anyone.
•The output connectors of the connected devices must be within
easy reach and next to the monitor.
•Always make sure there is sufficient ventilation. Do not place
any device onto the display preventing proper ventilation and
cooling.
Targa Visionary LCD 19-4 Wide
5
English
•If you notice any smoke, unusual noise or strange smells,
switch off the LCD display immediately and pull the plug out
from the wall outlet. Contact customer service. It is very
dangerous to continue using the LCD display under these
conditions.
•To avoid electric shock or fire, prevent this product from being
exposed to rain, dripping or splashing.
•Children: electrical appliances do not belong in the hands of
children. Do not allow children to play with electrical devices
when not under supervision. Children may not be able to
comprehend the presence of potential risks. Keep all packaging
away from children as this can cause suffocation.
•If you are not using the device within the Republic of Germany,
you must observe the regulations and laws in the country of
use.
Disposal of Old Devices
Devices marked with this symbol are subject to the
European Directive 2002/96/EC. All electric and electronic
devices must be disposed of separately from household
waste at established bodies. Avoid hazards to the
environment and dangers to your personal health by disposing of
the device properly. For further information about proper disposal,
contact your local government, disposal bodies or the shop where
you bought the device.
Targa Visionary LCD 19-4 Wide
6
English
Getting Started
Mount the supplied socket to the base of your LCD 19-4 Wide as
indicated on the bottom of the base.
Please check that delivery contents are complete using the list
below:
1 - Monitor
2 - VGA cable
3 - Audio cable
4 - Power cord
5 - User Manual
Targa Visionary LCD 19-4 Wide
7
English
Back Panel Connectors
6 7 8
Quick Guide
1. Connecting the Video Cable
Power your monitor and computer off.
Use the VGA cable (2) to connect the computer to the port (8)
of the monitor.
2. Connecting the Audio Cable
Use the audio cable (3) to connect the computer’s Audio Out
port to the audio input (7) of your monitor.
3. Connecting the Power Cord
Connect the power cord (4) to the power receptacle (6) of the
monitor. Connect the other end to a wall outlet.
4. Powering On
First turn on your computer then turn on the monitor.
Targa Visionary LCD 19-4 Wide
8
English
Setting the Resolution
The recommended screen resolution for your LCD 19-4 Wide is
1440 x 900 (max. refresh rate 60 Hz). In the following we will
explain the resolution setting for the operating systems Windows®
XP and Windows Vista™.
For Microsoft®Windows®XP:
-Right-click on the Desktop.
-Click on “Properties”.
-Click on the “Settings” tab.
-Use the ruler to select the proper screen resolution.
-Confirm the setting by clicking “OK”.
For Microsoft®Windows Vista™:
-Right-click on the Desktop.
-Click Start/Control Panel to open “Control Panel”.
-From the group “Appearance and Personalization”, click the
“Adjust screen resolution” link.
-Use the ruler to select the proper screen resolution.
-Confirm the setting by clicking “OK”.
If the recommended resolution of 1440 x 900 is not
available on your computer, please update the driver of
the graphics card. Contact the manufacturer of the
computer or the graphics card.
Targa Visionary LCD 19-4 Wide
9
English
Front Panel Controls
11 13 15
12 14 16
11.Display / hide the OSD menu.
12.Decrease value / navigate downwards
13.Increase value / navigate upwards
14.To confirm the settings
15.Power On/Off
16.Power indicator
