User Guide

Targus Multimedia Presentation Remote

Introduction

Thank you for your purchase of the Targus Multimedia Presentation

Remote. This combination remote, with laser pointer and cursor control,

works with both Microsoft PowerPoint® and Apple Keynote®. This cordless

remote also offers true plug and play capability with no need for software

drivers, while the long-range 2.4 GHz technology allows for effective

presentations up to 50 feet (15 m).

System Requirements

Hardware

• USB port

Operating System

• Microsoft Windows®2000

• Microsoft Windows®XP

• Microsoft Windows Vista®

• Microsoft Windows® 7

• Mac OS®X 10.4 or later

Contents

• Targus Multimedia Presentation Remote

• Mini USB Receiver

• 2 x AAA Batteries

• User Guide

Targus Multimedia Presentation Remote

Setting Up Your Remote

Installing the Batteries

Press the battery cover release button to open the battery cover and

carefully lift the cover as shown.

Battery

cover

Insert the supplied batteries, making sure the positive (+) and negative

(-) ends of the batteries match the polarity indicators inside the battery

compartment.

Spare battery compartment

Battery cover

release button

Targus Multimedia Presentation Remote

NOTE: THE SPARE BATTERY COMPARTMENT PROVIDES CONVENIENT STORAGE

FOR A SEPARATE BATTERY (INCLUDED) WHICH CAN BE USED FOR EMERGENCY

POWER.

Remove the mini USB receiver stored inside the center compartment.

Slide the battery cover back into position until it “clicks” firmly into place.

Targus Multimedia Presentation Remote

Using Your Remote

Before using the remote, please select your computer type and preferred

presentation software. Locate the switch inside the battery compartment

as shown.

PC PowerPoint®

Mac KeyNote®

Mac PowerPoint®

This remote is a plug and play device. It will automatically operate when

the USB receiver is connected to the computer. Plug the mini USB

receiver into any available USB port on your computer.

NOTE: SELECT “PC POWERPOINT” IF YOU USE A COMPUTER MADE BY:

HP/COMPAQ, DELL, TOSHIBA, GATEWAY, PANASONIC, FUJITSU, SONY,

IBM/LENOVO, ACER, ASUS, ETC.

Targus Multimedia Presentation Remote

Turn on the remote by pressing and holding the On/Off power button for

3 seconds.

Targus Multimedia Presentation Remote

Keys and Functions

This device can function as a presenter or a wireless mouse by using the

mode switch (12).

1Power button

Press and hold for 3 seconds to turn on the remote.

LED ring will turn green.

Press and hold for 3 seconds to turn off the remote.

LED ring will shut off.

Targus Multimedia Presentation Remote

Using the Device — Presenter Mode

2Blank screen button The screen will become blank/dark.

3Slide show

Start - Press once to begin.

Stop - Press and hold for 2 seconds to stop the slide

show.

4Page Forward/Next slide Press once to go to next slide.

5Page

Backward/Previous slide Press once to go back one slide.

6Laser pointer Laser light is emitted from the opening.

7LED ring Power and KeyLockTM indicator.

8KeyLock button

Press once to enable KeyLock function.

- Disables all keys except the laser, page forward/ next

slide and page backward/previous slide buttons.

- LED ring will become RED.

Press once to exit the KeyLock function.

- LED ring will return to GREEN.

9Laser pointer button Press and hold to activate the laser pointer.

10 Volume up button Press to increase the volume.

11 Volume down button Press to decrease the volume.

Targus Multimedia Presentation Remote

4Right mouse click Right mouse click.

5Left mouse click Left mouse click.

7LED ring Power indicator.

8KeyLock button Disabled in mouse mode.

9Joystick Pressing the joystick resembles left mouse click.

Moves the mouse cursor.

10 Volume up button Press to increase the volume.

11 Volume down button Press to decrease the volume.

Using the Device — Mouse Mode

Targus Multimedia Presentation Remote

Safety Measures

• To avoid possible eye damage, never point the remote’s laser at people,

especially their faces, or look directly into the remote’s laser beam.

• Avoid pointing the remote’s laser beam at a mirror or other highly-reflective

surface.

• Keep the remote away from young children.

• Never view the remote’s laser beam using telescopic devices, such as a

microscope or binoculars.

• Any attempt to disassemble, adjust or repair the remote may result in exposure

to laser light or other safety hazards.

Troubleshooting

What do I do if the response time of the remote is slow or it intermittently

stops working?

• Make sure that the remote is within 50 feet (15 m) of the mini USB receiver and

computer.

• Increase the distance between the remote’s receiver and the base units of other

wireless devices.

• Turn off any wireless devices and their base units that are near the remote’s

receiver.

• Replace the battery.
