Targus PAUH210U Bedienungsanleitung

BRUSSELS HANNOVER BARCELONA TOKYO MILANO AMSTERDAM SINGAPORE LONDON PARIS NEW YORK LOS ANGELES TORONTO HONG KONG SYDNEY

USB 2.0 High Speed

4-Port Hub

USER’S GUIDE

Making Your Mobile Life Easier.

Visit our Web site at: www.targus.com

400-0109-001A

USB 2.0 High Speed 4-Port Hub

Introduction

Congratulations on your purchase of a Targus USB 2.0 High

Speed 4-Port Hub. This ultra portable hub is USB 2.0

compliant and connects to a Universal Serial Bus (USB) port

on your desktop or notebook computer.

The hub has four ports for connecting USB (high-speed 2.0 or

standard 1.1) devices to your computer. One or more of these

devices can be additional hubs. You can daisy-chain up to 127

USB (high-speed 2.0 or standard 1.1) devices to your computer

in this way.

The hub also provides a maximum bandwidth of 480 Mbps,

which enables you to connect devices that consume a large

amount of bandwidth, such as an external storage device,

printer, scanner, DVD or CD-RW drive or digital camera, to

your computer.

This user’s guide describes how to connect the hub to your

computer and install default software drivers for the following

hub models:

•PAUH200 – USB 2.0 High Speed 4-Port Switching Hub

•PAUH210 – USB 2.0 High Speed Mini Cable Powered Hub

In addition to this user’s guide, depending on the hub model

that you purchased, this package contains:

PAUH200 PAUH210

•USB 2.0 switching hub

•2 USB 2.0 A to B cables

•AC power adapter

•USB 2.0 hub

•USB “Y” power cable

Features

PAUH200

•Has two type B USB ports that allow a user to connect and

simultaneously use the hub with a second computer

•Supports hot swapping and Plug and Play operation

PAUH210

•Supplied “Y” power cable uses two type A USB connectors,

one for power and data flow (black) and the other for power

only (red), eliminating the need for an AC power adapter

System Requirements

To use the hub, your computer must meet the following

hardware requirements and run one of the operating systems

listed below.

NOTES: The USB 2.0 High Speed 4-Port Hub is backward

compatible, so you can connect it to a computer with either a

USB 1.1 or 2.0 interface.

When using the hub with a computer that has a version 1.1

USB interface, all of the devices attached to the hub will run at

USB 1.1 speed (up to 12Mbps).

Hardware Operating System

•PCwithanIntel

®Pentium®

processor or equivalent and a hard

disk drive

• 64 MB RAM or higher, depending

on the operating system

• USB interface

• Windows®98SE

• Windows®Millennium

Edition

• Windows®2000

• Windows®XP

•MacOSX

Connecting the Hub and Installing

the Drivers

To connect the hub to your computer and install the operating

system’s default drivers, follow the steps listed below for the

hub model that you purchased.

Model PAUH200

The model PAUH200 hub comes with two high-speed A/B

cables so that you can connect it to two host computers. If you

are connecting the hub to only one host computer, keep the

second cable in a safe, easy to remember place for future use.

1 Turn on your computer (if it’s off).

2 Plug the supplied cable’s USB type A connector end into a

USB port on your computer.

USB type A and B connector ends

3 Plug the cable’s USB type B connector end into the hub.

4 Repeat steps 2 and 3 using the second cable to connect the

hub to a second host computer.

5 Attach the supplied AC power adapter to the AC power

jack on the hub and plug the adapter into an available

electrical outlet.

Your computer’s operating system automatically detects

the new hardware and begins installing the appropriate

default drivers.

Type A

Type B

6 Follow the on-screen instructions to complete the driver

installation.

You can now connect USB devices to the hub or

daisy-chain additional hubs.

Model PAUH210

The “Y” power cable that connects the model PAUH210 hub to

your computer has two USB type A connector ends, one black

and one red.

The black connector supports up- and downstream data flow

between the hub and your computer and provides power to the

hub and any device attached to the hub. The red connector only

provides power; data flow is not supported.

When the USB type A connectors are used together, the “Y”

power cable provides enough power to run any attached

device, even devices that consume large amounts of

bandwidth, eliminating the need for an AC power adapter (if

the device has one).

1 Turn on your computer (if it’s off).

2 Using the supplied “Y” power cable, plug the black USB

type A connector end into a USB port on your computer.

“Y” power cable with USB type A and B connector ends

3 Plug the red USB type A connector end into another USB

port on your computer for additional power to the hub.

NOTE: If you are using the hub with just one USB connection,

any devices attached to the hub that require heavy power,

such as a printer or external storage device, may operate

slower due to reduced bandwidth. To increase speed, use the

device’s AC power adapter, or connect the red USB type A

connector to your computer.

4 Plug the cable’s USB type B connector end into the hub.

Your computer’s operating system automatically detects

the new hardware and begins installing the appropriate

default drivers.

5 Follow the on-screen instructions to complete the driver

installation.

You can now connect USB devices to the hub or

daisy-chain additional hubs.

Connecting Devices to the USB Hub

To connect a USB device, plug it into a USB port on the hub

and follow any additional instructions provided with the

device.

When connecting new devices to the hub, consider the

following guidelines:

• If your computer is running the Windows®98 operating

system, a series of screens appear, beginning with the Add

New Hardware Wizard, to guide you through the driver

installation process.

• If your computer is running the Windows®Millennium

Edition, Windows®2000 or Windows®XP operating

system, the device drivers may install automatically.

• When connecting a new device to the hub, you must run the

Setup or Install program for that device.

• When connecting a device to the hub, to avoid possible

damage, never force the cable connector into the port on the

hub. If the cable connector does not attach smoothly, remove

the connector, turn it over and try attaching it again.

LED Status Indicator Lights

Once the default drivers are installed, the LED status indicator

lights glow and you can connect devices to the hub.

The LED lights display as follows:

Model PAUH200

• Power light glows green when the hub is receiving power

from your computer and glows orange when it’s receiving

power from the AC power adapter.

• Hub status light A glows green when a host computer is

connected.

• Hub status light B glows red if a second host computer is

connected.

NOTE: Use only the supplied AC power adapter with the hub

to avoid possible damage.

Model PAUH210

• Power light glows green when the hub is receiving power

from your computer via the “Y” cable.

Specifications

NOTE: Specifications are for all models unless indicated

otherwise.

Models

PAUH200 and PAUH210

Dimensions

PAUH200: 0.93 x 2.8 x 1.8 inches (23.5 x 70 x 45 mm)

PAUH210: 0.93 x 2.4 x 1.5 inches (23.5 x 61 x 38 mm)

Weight

1.6 ounces (45 g)

Operating Temperature

32 to 158 degrees Fahrenheit (0 to 70 degree Celsius)

Standards

USB Specification Revision 2.0 and 1.1 compatibility

Data Speed

USB v1.1: 12 Mbps

USB v2.0: 480 Mbps

Connector Ports

PAUH200

Hub to computer: 2 (series B receptacle)

Hub to devices: 4 (series A receptacle)

PAUH210

Hub to computer: 1 (series B receptacle)

Hub to devices: 4 (series A receptacle)

LED Indicators

PAUH200

Power: 1 (Orange - with AC power adapter,

Green - running off computer’s power

supply)

Hub to computers: 2 (A - Green, B - Red)

PAUH210

Power: 1 (Green)

Per-Port Current

500 mA (with the AC power adapter or “Y” power cable)

External Power - AC Power Adapter

DC 5 Volt

Cable length

3-foot (1 m)

Troubleshooting

General

Can I connect USB 1.1 compatible devices to the hub?

Yes, the hub is backward compatible with USB 1.1 devices.

Can I use the model PAUH210 hub if I have only one

available USB port?

Yes, the model PAUH210 hub works with one USB port if you

connect it to your computer with the black USB connector. For

more information, refer to “Model PAUH210” on page 6.
