CD-RW900 · CD-RW901

Professional CD Recorders

CD-RW900 · CD-RW901

Professional CD Recorders

CD-RW901 and CD-RW900 are rugged

CD Recorders for high-quality audio

recording on CD-R and CD-RW media in

professional and semi-professional areas.

Differences can be found among their

features, while audio performance is

virtually identical for both units.

Over the CD-RW900, the CD-RW901

offers balanced analogue inputs and

outputs and can receive and output

digital audio not only in SPDIF format

but also in professional AES/EBU format.

Furthermore, it offers parallel and serial

(RS-232C) ports for easy integration into

media control systems. With its Auto Cue,

Auto Ready and Call functions as well as

additional editing capabilities for track

and index marks, the CD-RW901 is ideal

for live applications in broadcast studios,

theatres or permanent installations, while

the CD-RW900 is a good choice for home

and live concert recording or for any other

semi-professional use.

24-bit converters

Input sample rate converter

(32 kHz to 48 kHz)

Independant L/R analogue

input level control

Digital volume

Sync recording function

Auto or manual track

division

Digital fade in/out from 1 to

30 sec in 1-sec steps

Rec mute function to record

silence

Erase/un-ﬁnalize CD-RWs

Supports CD-Text

Computer keyboard can be

used for CD-Text input and

as a remote control

Timer function (play when

power comes on)

Continuous, single, random,

or program (up to 99 songs)

play

All, single, or A-B repeat

playback

Plays MP3 ﬁles on CDs

(128 Kb/s only)

Plays MP3 ﬁles inside

directories

Shows MP3 tags on Display

(ID3)

Pitch control (±16% in 0.1 to

1.0% steps)

Key control (±6 semi-tones)

Key original function

(change tempo without

changing key)

Digital I/O

(SPDIF coaxial and optical)

RCA unbalanced analogue I/O

Wireless remote control

included (CD-RW901: Wired

remote control)

2-U rack mount construction

CD-RW901

additional features

Balanced XLR analogue I/O

AES/EBU digital I/O

RS-232C port

Parallel port

Auto Cue, Auto Ready, Call

functions

Manually adjust track marks

Add track marks every 1 to 10

minutes

Set/search index marks

Selectable copy ID

All trademarks are property of their respective holders.

Visit www.tascam-europe.com or www.tascam.com for most up-to-date information.

www.tascam-europe.com

TEAC Europe GmbH Bahnstr. 12, 65205 Wiesbaden, Germany

TEAC UK Ltd. Unit 19 & 20, The Courtyards, Hatters Lane, Watford, Hertfordshire WD18 8TE, UK

CD-RW900 · CD-RW901

Professional CD Recorders

Specifications CD-RW901 CD-RW900

Recordable media CD-R, CD-RW, CD-R-DA, CD-RW-DA

CD-RW: Multi speed (1–4x) and High speed (4–10x)

CD-R, CD-RW, CD-R-DA, CD-RW-DA

Quantisation 16-bit linear 16-bit linear

Sampling frequency 44.1 kHz 44.1 kHz

Frequency converter input 32–48 kHz 32–48 kHz

Frequency response 20 Hz to 20 kHz, ±0.8 dB (Playback)

20 Hz to 20 kHz, ±1.0 dB (Recording)

20 Hz to 20 kHz, ±0.8 dB (Playback)

20 Hz to 20 kHz, ±1.0 dB (Recording)

Signal-to-noise ratio 95 dB (Playback), 90 dB (Recording) 95 dB (Playback), 90 dB (Recording)

Dynamic range 95 dB (Playback), 90 dB (Recording) 95 dB (Playback), 90 dB (Recording)

Total harmonic distortion <0.006 % (Playback), <0.008 % (Recording) <0.006 % (Playback), <0.008 % (Recording)

Channel separation >90 dB (Playback, at 1 kHz), >80 dB (Recording, at 1 kHz) >90 dB (Playback, at 1 kHz), >80 dB (Recording, at 1 kHz)

Analogue inputs and outputs CD-RW901 CD-RW900

Analogue input, unbalanced RCA RCA

Input level nominal/maximum, impedance –10 dBV (–16 dBFS) / +6 dBV, 22 kOhm –10 dBV (–16 dBFS) / +6 dBV, 22 kOhm

Analogue output, unbalanced RCA RCA

Output level nominal/maximum, impedance –10 dBV (–16 dBFS) / +6 dBV, 600 Ohm –10 dBV (–16 dBFS) / +6 dBV, 600 Ohm

Analogue input, balanced XLR –

Input level nominal/maximum, impedance +4 dBu (–16 dBFS) / +20 dBu, 14 kOhm –

Analogue output, balanced XLR –

Output level nominal/maximum, impedance +4 dBu (–16 dBFS) / +20 dBu, 75 Ohm –

Headphones output 6.3-mm stereo jack 6.3-mm stereo jack

Nominal output power 2 x 20 mW (into 32 Ohm) 2 x 20 mW (into 32 Ohm)

Digital inputs and outputs CD-RW901 CD-RW900

Coaxial Cinch, IEC60958 Type II (SPDIF) Cinch, IEC60958 Type II (SPDIF)

Optical TOS, IEC60958 Type II (SPDIF) TOS, IEC60958 Type II (SPDIF)

AES/EBU XLR, IEC60958 (AES/EBU) –

Other specifications CD-RW901 CD-RW900

Voltage requirements Europe: 230 V / 50 Hz Europe: 230 V / 50 Hz

Power consumption 19 W 18 W

Dimensions (W x H x D) 483 mm x 93 mm x 309 mm 483 mm x 93 mm x 308 mm

Weight 5.4 kg 4.9 kg

Supplied accessories Wired remote control Infra-red remote control

CD-RW901

Rear panel

CD-RW900

Rear panel
