Tascam US-224 Bedienungsanleitung

US-224 Technical Specifications

General

Frequency Response

20 Hz - 20KHz 1.0 dB / -3.0 dB

LINE INPUT A/B to LINE OUTPUT

TRIM min., +4 dBu input

LINE OUTPUT level max.

Noise Level

Better than 92 dB A Weight

MIC INPUT A/B to LINE OUTPUT

TRIM min., 150 ohm terminated

LINE OUTPUT level max.

Signal Processing Delay

Less than 2 ms

MIC/LINE to LINE OUT Input Monitor

Fs = 44.1KHz

THD

Better than 0.01%

MIC INPUT A/B to LINE OUTPUT

0 dBu input TRIM min.

LINE OUTPUT level max.

LINE INPUT A/B to LINE OUTPUT

TRIM min., +20 dBu input

LINE OUTPUT level max.

Crosstalk

Better than 85 dB at 1KHz

LINE INPUT A/B to LINE OUTPUT

TRIM min., +4 dBu input

LINE OUTPUT level max.

Click: Less than -35 dBu

Fader Attenuation: Better than -90 dB at

1 KHz

Mute Level: Better than -90 dB at 1 KHz

Dimensions:

12" x 8.3" x 2.4" (30.4 x 21.1 x 6.2 cm)

Weight (unit itself): 0.85 Kg (1.9 lbs)

Power Consumption: 2W

MIC INPUT A/B (Analog)

Connector: XLR-3-31

( 1:= GND, 2:= Hot, 3:= Cold ) : Balanced

Input Impedance: 2.2k ohm

Nominal Input Level (TRIM max.): -54 dBu

Nominal Input Level (TRIM min.): -16 dBu

Maximum Input Level: 0 dBu (TRIM min.)

LINE/GUITAR INPUT A/B (Analog)

Connector: 1/4"

(Tip:Hot; Ring:Cold; Sleeve:GND)

(Balanced at LINE, Unbalanced at

GUITAR)

Input Impedance 22k ohm at LINE

680k ohm at GUITAR

Nominal Input Level (Trim max.):

-34 dBu at LINE

-48 dBV (-36.8 dBu) at GUITAR

Nominal Input Level (TRIM min.):

+4 dBu at LINE

- 10 dBV (-7.8 dBu) at GUITAR

Maximum Input Level (TRIM min):

+20 dBu at LINE

+6 dBV (+8.2 dBu) at GUITAR

LINE OUTPUT (Analog)

Connector: RCA pin jack, Unbalanced

Output Impedance: 100ohm

Nominal Output Level: -10 dBV (-7.8 dBu)

(LINE LEVEL -10dB)

Maximum Output Level: +6 dBV (+8.2

dBu)

(LINE LEVEL max)

PHONES output (Analog)

Connector: 1/4" TRS Stereo

(Tip:L, Ring:R, Sleeve:GND)

(when nominal impedance 40 Ohms

loaded)

Maximum Output Power: 10m W + 10m

Maximum Output Level: +6 dBV (+8.2

dBu)

DIGITAL IN

Connector: RCA pin jack

Format: IEC60958 Type2

Input impedance: 75 ohm

Input Level: 0.5Vp-p

DIGITAL OUT

Connector: RCA pin jack

Format: IEC60958 Type 2

Output Impedance: 75 ohm

Output Level: 0.5Vp-p

MIDI IN

Connector: 5P DIN

Format: Standard MIDI Format

MIDI Out

Connector: 5P DIN

Format: Standard MIDI Format

USB

Connector: USB Down stream connector

Format: USB Version 1.1

ADC / DAC

AD/DA Converter

24Bit, 64 times oversampling

Delay: 17 samples (ADC), 15.4 samples

(DAC)

Audio Performance

MIC INPUT (A, B XLR Analog INPUT to

DIGITAL OUT)

Frequency Response

20 Hz - 20KHz + 0.5dB / -1.0 dB

TRIM min., -16 dBu input

S/N

Better than 93 dB A Weight

TRIM min., 150 ohm terminated

LINE OUTPUT max.

T.H.D.

Better than 0.007% at 1kHz

TRIM min., 0 dBu input

LINE INPUT (A, B 1/4" Analog INPUT to

DIGITAL OUT)

Frequency Response

20 Hz - 20KHz, +0 .5 dB / -1.0 dB

TRIM min., +4 dBu input

S/N

Better than 93 dB A Weight

TRIM min., 150 ohm terminated

LINE OUTPUT max.

T.H.D

Better than 0.007% at 1KHz

TRIM min., +20 dBu input

LINE OUTPUT (DIGITAL IN to LINE OUTPUT)

Nominal Output: +6dBV

0 dBFs input, LINE OUTPUT max.

Frequency Response:

20 Hz - 20KHz, +0.5 dB / -1.0 dB

–16 dBFs input, LINE OUTPUT max.

S/N:

Better than 97 dB A Weight, 0 dBFs input,

LINE OUTPUT max.

T.H.D.

Better than 0.007% at 1KHz

TRIM min., 0 dBFS input

LINE OUTPUT max.

PHONES Output

Maximum Output: More then 10m W +

10m W at 1KHz, 40 ohm loaded

Frequency Response:

100 Hz - 20KHz, +1.0 dB / -3.0 dB

Nominal level, 40 ohm loaded

T.H.D.: Better than 1 %

1KHz, Output 10m W + 10m W, 40 ohm

loaded
