TE TE3112 Bedienungsanleitung

Service Manual

TE3124/TE3112.

Thermal Transfer Printer

2 2

Description Part number

TE3124-PRINTER CC9352-000

TE3112-PRINTER CR2120-000

TE Connectivity document number:

412-121032 issue 1

Related Documents

412-121024, TE3124 Operators Manual.

412-121026 TE3112 Operators Manual.

411-121020 Thermal transfer cleaning instructions.

411-121018 Printhead setup for the TE3124/TE3112/

T6112DS.

This documentation as well as translation hereof are property of TE

Connectivity.

The replication, conversion, duplication or divulgement of the whole

manual or parts of it for other intentions than its original intended purpose

demand the previous written authorization by TE Connectivity.

Trademark

Centronics®is a registered trademark of the Data Computer Corporation.

Microsoft®is a registered trademark of the Microsoft Corporation.

Windows 2000®, 2003®, XP®are registered trademarks of the Microsoft

Corporation.

TrueTypeTM is a registered trademark of Apple Computer, Inc.

Editor

Regarding questions or comments please contact TE Connectivity.

Topicality

Due to the constant further development of our products discrepancies

between documentation and product can occur.

Please check

http://www.te.com/commerce/DocumentDelivery/DDEController for the

latest update.

Terms and conditions

Deliveries and performances are effected under the General conditions of

sale of TE Connectivity.

Service Manual

for the following products

United States

Toll Free: 1-800-430-7226 x4

(East) or x5 (West)

Email:

[email protected]

United Kingdom

Toll Free: 0 800988 9177

*Phone is monitored in the

afternoon local time

Email:

[email protected]

Germany

+49(0)173-3169004

Email:

[email protected]

Ireland

Toll Free: 800-557-810

*Phone is monitored in the

afternoon local time

Email:

[email protected]

Rest of Europe

http://www.te.com/help

Email:

[email protected]

Asia

+86-21-33980184

Email:

[email protected]

Australia

Toll Free: 1-800-144-078

Email:

[email protected]

New Zealand

Toll free: 0800-TYCO-HELP

Email:

[email protected]

Representatives in other countries on request.

Global Identication Technical Contact Information

Printer & Software Technical Support:

Disclaimers

The information contained within this document is the

property of TE Connectivity. It is supplied in

confidence and the commercial security of the contents

must be maintained. It must not be used for any

purpose other than that for which it is supplied nor may

any information contained in it be disclosed to

unauthorised persons. It must not be reproduced in

whole or in part without obtaining written permission

from TE Connectivity.

While TE Connectivity has made every reasonable

effort to ensure the accuracy of the information in this

document, TE Connectivity does not guarantee that it is

error-free, nor does TE Connectivity make any other

representation, warranty or guarantee that the

information is accurate, correct, reliable or current.

Tyco Electronics reserves the right to make any

adjustments to the information contained herein at any

time without notice. TE Connectivity expressly

disclaims all implied warranties regarding the

information contained herein, including, but not limited

to, any implied warranties of merchantability or fitness

for a particular purpose. Specifications are subject to

change without notice. Consult TE Connectivity for the

latest dimensions and design specifications.

Table of Contents

1 Important Information............................................................................................................................ 4

1.1 General Safety Instructions...................................................................................................................... 4

1.2 Protective Devices ................................................................................................................................... 4

1.3 Handling Electricity .................................................................................................................................. 5

1.4 Procedure in Case of Accidents .............................................................................................................. 5

2 Cleaning .................................................................................................................................................. 6

2.1 Cleaning by the Operator ......................................................................................................................... 6

2.2 Cleaning the Label Sensor ...................................................................................................................... 7

3 Replacing Assembly Units .................................................................................................................... 8

3.1 Tools......................................................................................................................................................... 8

3.2 Removing and Installing the Plastic Cover............................................................................................... 8

3.3 Replacing the Printhead........................................................................................................................... 9

3.4 Replacing the Printhead .......................................................................................................................... 9

3.5 Replacing the Slipping Clutches .............................................................................................................11

3.6 Replacing the Label Sensor ................................................................................................................... 13

3.6.1 Replacing Standard Label Sensor.................................................................................................... 13

3.6.2 Replacing Label Sensor ................................................................................................................... 14

3.7 Replacing the PCB CPU ........................................................................................................................ 15

3.8 Replacing the Power Supply Unit........................................................................................................... 16

4 Adjustments ......................................................................................................................................... 17

4.1 Measuring and Adjusting the Winding Torques ...................................................................................... 17

4.1.1 Measuring the Winding Torques ....................................................................................................... 17

4.1.2 Adjusting the Winding Torques ......................................................................................................... 20

4.2 Adjusting the Printing Mechanism.......................................................................................................... 21

4.2.1 Preparing the Printer for Adjustment ................................................................................................ 21

4.2.2 Adjusting the Printhead Position....................................................................................................... 22

4.2.3 Adjusting the Printhead Pressure..................................................................................................... 23

4.2.4 Adjusting the Transfer Ribbon Feed Path......................................................................................... 24

4.2.5 Final Test .......................................................................................................................................... 24

4.3 Adjusting the Belt Tension at the Main Drive Motor ............................................................................... 25

Adjusting the Head Switch ..................................................................................................................... 26

5 Troubleshooting and Error Correction............................................................................................... 27

5.1 Failure of Device Functions.................................................................................................................... 27

5.2 Hardware Faults..................................................................................................................................... 28

Block Diagram ...................................................................................................................................... 29

7 Layout Diagram PCB CPU............................................................................................................. 30, 31

8 Index...................................................................................................................................................... 32

4 4

1 Important Information

1.1 General Safety Instructions

This service manual is intended for use by qualied service and maintenance personnel. For more operation and

conguration information, refer to the user or conguration manual.

Follow the general safety rules below:

• Keep the area around the device clean at all times!

• Work with safety in mind.

• Parts of device that are removed during the maintenance work must be put in a safe place.

• Avoid risks of tripping over.

Danger!

Danger to life and limb from increased current ow through metal parts in contact with the device.

XDo not wear clothing with metal parts.

XDo not wear jewelry.

XDo not wear spectacles with metal frames.

Warning!

Items of clothing drawn into the device by moving parts can lead to injuries.

XDo not wear any items of clothing which could get caught by moving parts.

1.2 Protective Devices

Warning!

There is a risk of injury if protective devices are missing or defective.

XReplace all protective devices (covers, safety notices, grounding cables etc) after maintenance work

has been completed.

XReplace parts that have become defective or unusable.

Wear protective goggles for:

• Knocking pins or similar parts in or out with a hammer.

• Using spring hooks.

• Inserting or removing springs, retaining rings or grip rings.

• Using solvents, cleansers or other chemicals.

1 Important Information

1.3 Handling Electricity

The following work may only be done by trained and qualied electricians:

• Work on electrical components.

• Work on an open device still connected to the mains supply.

General precautions before starting maintenance work:

• Find out where the emergency and power switches are so that they can be quickly operated in an emergency.

• Disconnect the current supply before carrying out the following work:

- Installing or removing power units.

- Working in the immediate vicinity of open power supply components.

- Mechanical check of power supply components.

- Modifying circuits in the device.

• Test the zero potential of the device parts.

• Check the working area for possible sources of danger, such as wet oors, defective extension cables, defective

protective conductor connections.

Additional precautions in the case of exposed voltages:

• Ask a second person to remain near the working site. This person must know where the emergency and power

switches are, and how to switch the current off if danger arises.

• Only use one hand to work on electric circuits of devices that are switched on. Keep the other hand behind your

back or in your pocket.

This prevents electricity from owing through your own body.

1.4 Procedure in Case of Accidents

• Act calmly and with great care.

• Avoid danger to yourself.

• Switch off power.

• Request medical assistance.

• Give rst aid, if qualied.

6 6

2 Cleaning

2.1 Cleaning by the Operator

The following cleaning work is described in the “Thermal Transfer Printer cleaning instructions“ TE document number:

411-121020.

• cleaning the device

• cleaning the printhead

• cleaning the print roller

• cleaning the label sensor

Danger!

Risk of death via electric shock!

XBefore opening the housing cover, disconnect the device from the mains supply and wait at lease one

minute until the power supply unit has discharged.

XAny electrical work must be carried out by a fully trained and qualied Electrical Engineer.

2.2 Cleaning the Label Sensor

2423

Fig. 1 Cleaning the label sensor Fig 2 Removing the label sensor

Danger!

Risk of death via electric shock!

XBefore opening the housing cover, disconnect the device from the mains supply and wait at lease one

minute until the power supply unit has discharged.

1. Remove media from the printer.

2. Remove the Allen key (5) from its retainer.

3. Remove the rear cover of the printer.

4. Unscrew knurled thumb screw (1).

5. Unplug the cable (3) from the plug on the rear end of the label sensor (2).

6. Push the label sensor (2) so deep as possible into the guide prole toward the chassis.

7. Slide out the label sensor assembly (2) toward the back side cover.

8. Clean label sensor and sensor units (2) with brush or cotton swab soaked in pure alcohol.

9. Push label sensor back toward the print head side of printer so you can see the hole in the label sensor over the

long hole in the prole (guide).

10. Connect the cable (3) to the label sensor (2).

11. Attach knurled thumb screw (1).

12. Pull the label sensor (2) via knurled thumb screw (1) so far as possible toward cover side. This prevents the cable

(3) from being pinched when installing the rear cover.

13. Install the rear cover of the printer.

14. Adjust label sensor  operators manual.

15. Insert the Allen key (5) into its retainer.

2 Cleaning

8 8

3 Replacing Assembly Units

3.1 Tools

XDo not use any worn of damaged tools.

XOnly use tools and testing devices that are suitable for the task at hand.

special tools:

• Test collar for transfer ribbon winder (5534199)

Standard tools:

• Phillips-head screwdriver, size 1

• Allen key 1,5 mm

• Screw driver Torx, size TX 20

• Snap ring pliers ZGG 0

• Cylindrical dynamometer (spring scale), 0 - 10 N

• Cylindrical dynamometer (spring scale), 0 - 25 N

• Jaw wrench 8 mm

3.2 Removing and Installing the Plastic Cover

!Attention!

The plastic cover can be damaged via careless handling.

XDo not use force.

XDo not twist the plastic cover when removing it or pressing it on.

Fig. 3 Removing and installing the plastic cover

Removing the plastic cover :

1. Swivel the plastic cover up 90° and hold it in this position with both hands.

2. Carefully pull the hinges of the plastic cover out of the front mount and then the rear mount.

3. Put the plastic cover in a safe place.

Installing the plastic cover :

1. Place the hinges of the plastic cover onto the mounts with the open side downward.

2. First carefully press the rear hinge onto the respective mount and then do the same with the front hinge.

3. Swivel the plastic cover closed.

3 Replacing Assembly Units

3.3 Replacing the Printhead

3.4 Replacing the Printhead

The printhead of the printer can be replaced without the need for ne adjustment. The printhead must be replaced if

worn or when switching to a printhead with higher or lower resolution. For better identication, the print heads have a

label stating the printer type and resolution.

1 Head plate

2 Plug connection

3 Plug connection

4 Screw

5 Printing line

6 Pins

7 Printhead

Fig.4 Structure of the printhead

!Attention!

The printhead (7) is adjusted on a head plate (1) and precisely aligned at the factory. Do not loosen the

screws (4) under any circumstances.

!Attention!

The printhead can be damaged by static electricity discharges and impacts!

XSet up printer on a grounded, conductive surface.

XGround your body, e.g. by wearing a grounded wristband.

XDo not touch contacts on the plug connections (2, 3).

XDo not touch printing line (5) with hard objects or your hands.

Fig. 5 Removing and installing the printhead

Note:

Location of item

11 has moved

on more recent

printer models

10 10

3 Replacing Assembly Units

Removing the printhead

1. Turn lever (10) counterclockwise to lift the printhead.

2. Remove labels and transfer ribbon from the printer.

3. Remove Allen key (11) from its retainer.

4. Lightly keep printhead mounting bracket (9) on the print roller with one nger and screw out screw (8) with the

Allen key and remove it and the washer.

5. Swivel printhead mounting bracket (9) upward.

6. Remove printhead from the printhead mounting bracket (9) if necessary.

7. Loosen both plug connections (2, 3) on the printhead and set printhead down on a clean, soft surface.

Installing the printhead

1. Attach plug connections (2, 3).

2. Position printhead in printhead mounting bracket (9) in such a way that the pins (6) are secured in the corre-

sponding holes in the printhead mounting bracket (9).

3. Lightly keep printhead mounting bracket (9) on the print roller with one nger and check for correct positioning of

the printhead mounting bracket (9).

4. Screw in screw (8) with washer with the Allen key and tighten it.

5. Reload labels and transfer ribbon.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere TE Drucker Handbücher

TE HTP600 Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
