Team Orion VortexR8X Pro Bedienungsanleitung
INSTRUCTION MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
2 Copyright Team Orion © 2014
Warnings.............................................................................. 3
Warranty.............................................................................. 4
Connections......................................................................... 5
ESC Calibration.................................................................... 6
Programming your ESC....................................................... 8
Available Parameters and default settings..................... 9
Features ............................................................................. 10
Status LED Function.......................................................... 10
Audio Warning Tones ....................................................... 10
ESC Parameters Setup ...................................................... 11
Available Parameters....................................................... 12
1. Running Mode .................................................................12
2. Drag Brake Force.............................................................13
3. Low Voltage Cut-o.........................................................13
4. Start mode “punch”.........................................................14
5. Max Brake Force..............................................................14
6. Max Reverse Force..........................................................14
7. Initial Brake Force (minimum brake) ............................14
8. Neutral Range..................................................................15
9. Timing...............................................................................15
12. Motor Rotation Direction .............................................15
13. LiPO Cells .......................................................................15
14. BEC Voltage....................................................................16
Restore Default Settings.................................................. 16
Program Box...................................................................... 16
PC Software ....................................................................... 17
Setting Proles.................................................................. 17
INSTRUCTION MANUAL · ENGLISH
www.teamorion.com 3
WARNINGS
• Do not let children use this product without the
supervision of an adult.
• Never leave the ESC unsupervised while it is powered on.
• The ESC might get hot during use, be careful when
handling it.
• Always disconnect the battery after use, do not store with
the battery connected.
• Do not use near ammable materials.
• If the ESC has suspicious reactions, immediately
disconnect the battery and discontinue use.
4 Copyright Team Orion © 2014
WARRANTY
Team Orion guarantees this product to be free from
manufacturing and workmanship defects. The warranty
does not cover incorrect installation, components worn by
use, or any other problem resulting from incorrect use or
handling of the product. No liability will be accepted for any
damage resulting from the use of this product. By the act of
connecting and operating this product, the user accepts all
resulting liability. Is considered incorrect use:
• Failure to follow instructions.
• Improper use of the product (abusive use, out of spec,
etc.)
• Failure to adapt settings for proper function (improper
connections, wrong gearing, installation, setup, etc.).
• Overload, overheating (desoldering, melting, etc.).
• Running in inadequate conditions (damage or rust from
rain, humidity, etc.).
• Improper maintenance (presence of dirt, etc.).
• Disassembly, modication by the user (modifying original
connectors, wires, components, etc.).
• Mechanical damage due to external causes.
www.teamorion.com 5
Sensorless brushless motors
When using a motor without sensors, if the motor spins in
the wrong direction, simply reverse two of the motor wires.
Sensor brushless motors
When using a motor equipped with sensors, the motor
should also be connected to the ESC via a sensor wire.
WARNING! When using sensor equipped motors, you must
respect the A-B-C wire connection order, you can’t connect
the wires randomly or the motor will not spin at all!
CONNECTIONS
Motor
Servo
Receiver
Vortex R8X
Switch
+ (red)
SET
ST/CH1
TH/CH2
On/O
- (black) Battery
6 Copyright Team Orion © 2014
ESC CALIBRATION
In order to ensure proper function, the ESC must be
calibrated to your transmitter inputs. Center the trims and
reset all settings inside the transmitter before proceeding to
the calibration
Calibration procedure
A. Make sure the ESC is switched o and then switch the
transmitter on.
B. Press and hold the setup button (located on the switch),
then switch on the ESC. Release the button as soon as the
red LED starts to ash.
C. Calibrate the throttle points by pressing the button once
after each step.
1. Neutral point (1 ash)
2. Full throttle (2 ashes)
3. Full brakes/reverse (3 ashes)
D. The motor will run 3 seconds after the last step is
completed.
www.teamorion.com 7
1
3
LED
2
ON/OFF
Press and
hold the
SET button
Switch ON Keep
pressing
the SET
button
Release as
soon as soon as
the red LED
starts to blink
LED
4 5 6
LED LED
Press
once Press
once Press
once
8 Copyright Team Orion © 2014
PROGRAMMING YOUR ESC
OR
2 2
33 3
1
7
4
6
5
Connect the battery
Enter Programming Mode
S
elect the parameter you wish to modify
Reset to factory default settings
Press the
SET button
for 1s
Press the
SET button
for 5s
Press the SET button
1 time to select the
1st parameter...
...press the SET button
2 times to select the
2nd parameter etc.
Switch ON
Switch OFF
ESC to complete
the procedure
LED
blinks
LED blinks 1 time
LED blinks
1 time
LED blinks 2 times
Press the SET button
for 3s to modify
the setting of the
parameter
Press the SET button
for 3s to save the
new setting
Use the SET button
to change the setting
of the parameter.
Press 1 time
LED blinks
2 times
Press 2 times etc.
www.teamorion.com 9
AVAILABLE PARAMETERS AND DEFAULT SETTINGS
Parameter
(indicated by
green LED )
Setting (indicated by red LED )
1 2 3 4 5 6 7 8 9
Standard Parameters (adjustable with on/o switch)
1 Running
Mode
Forward
with
Brake
Forward/
Reverse
with
Brake
Foward/
Reverse
(For
Rock
Crawler)
2 Drag Brake
Force 0% 5% 10% 20% 25% 30% 100%
User set
in 1%
steps
3 Low Voltage
Cut-O
Threshold
No
Protection 2.6V/Cell 2.8V/
Cell
3.0V/
Cell 3.2V/Cell 3.4V/Cell
User set
in 0.1V
steps
4 Start Mode
(Punch) Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7 Level
8Level 9
5 Max Brake
Force 25% 50% 75% 100% Disable
6 Max Reverse
Force 25% 50% 75% 100%
7 Initial Brake
Force
Drag
Brake
Force
0% 20% 40%
8 Neutral
Range
6%
(Narrow)
9%
(Normal)
12%
(Wide)
9 Timing 1 2 3 4 56 7 8
12 Motor
Rotation
Direction
CCW CW
13 LiPO Cells Auto 2S 7.4V 3S 11.1V 4S 14.8V 5S 18.5V 6S 22.2V
14 BEC Voltage 6V 7.2V
10 Copyright Team Orion © 2014
Thank you for purchasing a Team Orion Brushless ESC.
This ESC features the latest brushless technologies. Our
World Championship winning development team has
spent countless hours developing this ESC so that you
can experience ultimate performance. Please read these
instructions thoroughly before using the ESC.
FEATURES
• Designed for on-road and o-road 1/8 scale cars
• 6V or 7.2V adjustable BEC for more servo performance
• Works with sensor and sensorless motors
• New case design with improved cooling system
• Highly customizable software
• Easy set-up via the setup button or optional digital
program box
STATUS LED FUNCTION
• When you switch on the ESC, the green LED ashes
according to the number of cells of the battery (4 cells = 4
ashes / 4 beep tones).
• In the neutral position, no LED are lit
• The red LED lights when the car is moving forward,
backwards or is braking.
AUDIO WARNING TONES
1. Input voltage: as it is switched on the ESC checks the
input voltage and emits a number of beep tones according
to the number of battery cells detected (4 cells = 4 beep
tones). If an issue is detected, the ESC emits two beep tones
