tech21 Comp Tortion Bedienungsanleitung
OUT
D.C.
IN
D.C.
OUT
LEVEL
TM
Comp
LEVEL TONE TORTION COMP
POWER REQUIREMENTS
*Utilizes standard 9V alkaline battery (not included).To install, simply remove
back plate. (NOTE: The Input activates battery.To conserve energy, unplug
when not in use.) Power Consumption: approx. 12mA.
*USE DC POWER SUPPLY ONLY! Failure to do so may damage the unit
and void warranty. DC Power Supply Specifications:
-9V DC regulated or unregulated, 100mA minimum;
-2.1mm female plug, center negative (-).
Optional factory power supply is available:Tech 21 Model #DC2.
WARNINGS:
* Attempting to repair unit is not recommended and may void warranty.
* Missing or altered serial numbers automatically void warranty. For your own
protection, be sure serial number labels on the unit’s back plate and exterior
box are intact.
ONE YEAR LIMITED WARRANTY. PROOF OF PURCHASE
REQUIRED. Manufacturer warrants unit to be free from defects in materials
and workmanship for one (1) year from date of purchase.This warranty does not
include damage resulting from accident, misuse, abuse, alteration, or incorrect cur-
rent or voltage. If unit becomes defective within warranty period,Tech 21 will
elect to repair or replace it free of charge. After warranty expires,Tech 21 will
repair defective unit for a fee.
ALL REPAIRS for residents of U.S.: Call Tech 21 for Return Authorization
Number. Manufacturer will not accept packages without prior authorization,
pre-paid freight (UPS preferred) and proper insurance. International purchasers
should contact the authorized Tech 21 distributor in their particular country.
FOR PERSONAL ASSISTANCE & SERVICE:
Contact Tech 21, Inc., weekdays from 10:00 AM to 5:00 PM, EST.
MADE IN THE U.S.A.
TECH 21. NYC
333 West 52nd Street, NY, New York 10019
212-315-1116 / Fax: 212-315-0825 / www.tech21nyc.com
PRODUCT OVERVIEW
The CompTortion logically, and uniquely, combines two effects:
compression and distortion. No other single pedal offers this kind of
control over such a range of sounds - - from totally clean to light distor-
tion to smooth and creamy overdrive, and from zero compression to
completely squashed.
The CompTortion is multifunctional and exceptionally versatile. Musically
voiced to complement each other, the effects are independently
adjustable so you can determine the formula that best suits your particu-
lar taste.You have the option of using the compression by itself or just
the distortion alone.And, of course, you can mix the two together.You
can also use the CompTortion solely for a clean boost, up to 12dB.
Compression and distortion in the same signal chain are inherently very
noisy. Even if you had “the best” compressor hooked up with “the best”
distortion unit, there would be so much noise you wouldn’t be able to
use them without an outboard noise gate. Having specifically designed
these two effects into one unit, noise reduction was engineered directly
into the circuitry.
Characteristic of all Tech 21 products, the CompTortion will not deper-
sonalize your guitar tone. It is highly interactive with your individual play-
ing style, your individual musical style, and your instrument’s individual
tonality. It is our hope that the CompTortion will be a useful tool for
stimulating your creativity and, ultimately, providing the inspiration to play
your best.
APPLICATIONS
The CompTortion is designed for use with any amp - - tube or solid
state, vintage or modern.You can achieve the same results using the
CompTortion with any of our highly-acclaimed SansAmpTM models of
Tube Amplifier Emulators, as there is no speaker simulation within the
CompTortion’s circuitry.
The 100% analog technology can also add warmth and dimension to
any digital signal processor.
Simply plug your guitar into the CompTortion, and plug the
CompTortion into the input of your amp (or the input of a SansAmp).
GUIDE TO CONTROLS
COMP (Compression)
controls the amount of compression and sustain without any distortion.
Ranges from minimum at 1:1 to maximum at 15:1.
TORTION (Distortion)
controls the amount of distortion and sustain without any compression.
At minimum, setting is completely clean.
TONE
is a traditional passive shelving tone control.
LEVEL
adjusts the output level without altering any tonal characteristics.
NOTEWORTHY NOTES & SUGGESTIONS
--For guitar amps that tend to be on the bright side, we recommend you
begin experimenting with the Tone control set lower than 12 o’clock.
When available, use the Normal channel on your amp, rather than the
Bright channel.
--Whenever you’re not playing, we suggest turning your guitar volume to
minimum. Outside interference can trigger the noise gate to open,
causing unwanted background noise to be present (particularly with
single coil pickups).
--Having both Comp and Tortion set at maximum at the same time may
cause microphonic feedback in live performances and excess noise in
recording applications.When using one at maximum, we recommend
using the other sparingly.
--The LED will fade as the battery runs low.
USING THE COMPTORTION
WITH OTHER EFFECTS
For best results, plug your guitar directly into the CompTortion.This will
preserve the interactive nature of the unit. Otherwise, place the
following effects:
BEFORE: Chorus, Envelope Filter/Follower,Wah-Wah
AFTER: Chorus, Distortion (other), Echo, Reverb, SansAmp,
Volume Pedal
SAMPLE SETTINGS
Warm/Medium Overdrive
(Recommended
Starting Point)
Clean Boost
Distortion for Lead
LEVEL TONE TORTION COMP
Country Picking
LEVEL TONE TORTION COMP
LEVEL TONE TORTION COMP
Blues
LEVEL TONE TORTION COMP
LEVEL TONE TORTION COMP
