CHARACTERISTICS

Inthisspecificcase,anRFIDsystemconsists of three fundamental items:

1)oneormoretransponders(orTAGs)

2)areadingand/orwritingdevice(reader).

3)adatainterfaceordecoder.

The PASSO CARD system allows relays to be activated by RFID (Radio

Frequency IDentification) by just passing the transponder (CARD) close

tothereader.

It can be used in all device control installations, with the following

advantages:

-quickoperationandnocontact,unlikeaconventional key-switch.

-noneedforbatteriesintheportabledevices(TAGs).

- serial connection between the CARD reader and the internal unit with

therelay, increasing security and preventing activation through tampering

withthereader.

- option of combining PASSO CARD readers and PASSO digital keypads

inthesamesystem.

- The system is protected from unauthorised programming and only

PASSO series devices and accessories are enabled within it.

The reader (fig.1) is a protected device with integral antenna, for

installation in a point accessible to users. It has a warning buzzer and a

LEDlightonthefrontforeasyidentificationinthedark.

The receiver unit (fig.3) has two clean-contact relay outputs, each of

whichcanbeprogrammedasfollows:

-Jog(relayactivatedforonesecond)

-Stepping

-Timed 30” (programmable from 2 to 255 seconds with PASSOTS)

31 32

GB GB

Fig.1)

2. Internalantenna

3. B

4. LED

6. V

Fig.2)Readeropening

utton

Terminal

oltageselector

EADER

IndicatorLED

PARTS DESCRIPTION

Fig.3)

2. P1B

3. LED L1

4. P2B

5. M

6. V

Fig. 4) Connection example with

4activationdevices.

RECEIVER

Terminal

utton

emory

oltageselector

INSTALLATION

Find a position for the reader which is easily accessible to the user, while

thereceivershouldbeinstalledindoors,inaprotected position.

Remove the lid of the reader with the aid of a screwdriver (fig. 2) and fix

thebottomfirmly, in a vertical position (the closing clip must be at the top).

Connect terminals 1-2 of the readers and 7-8 of the receiver to a 12 or 24V

power supply. Check that the voltage change jumper (6 in fig. 1 and 2) is

onlyconnectedwithpowersupplyat12V.

Check the communication line between the readers (terminals 3 - 4 fig. 1)

andthereceiver(terminals5-6fig.3).

In multiple systems, up to 4 control units (PASSO TS keypads or CARD

readers) can be used to activate the same receiver; in this case there will

be a single communication line, parallel-connecting all the circuit boards

asshowninfig.4.

Warning! use twisted cable for the data line, complying

with the references. The reader (or keypad) terminals

(A) must be connected to the terminal (A) of the

receiver, and the terminals (B) to(B) ofthe receiver.

Connect the devices to be controlled to the receiver outputs (terminals 1 -

2and/or3-4infig.3).

PROGRAMMING

TwotypesofCARDaresuppliedwitheachPASSO reader:

- MASTERCARD: thisisthe “key” for access to the programming and/or

deletionofcodesinreaders.

In a new system, the MASTER CARD is the first to be memorised, and a

33 34

TECHNICAL SPECIFICATIONS

PASSO CARD M.U. R Receiver

Power supply Vac/Vdc 12/24 12/24

Consumption (at 24Vac) mA 100 120

Relay contacts max. current A - 1

Relay contacts max. voltage Vac - 24

Connection line max. distance m 200

Transmission speed baud 38.400

No. of possible memorised codes nr. - 750

Max. number of receiver nr. 4 -

Operating temperature °C -20+55 -20+55

Protection class IP 54 20

Dimensions mm 102x43x34 79x48x21

eader

readers on

GB GB

Fig.1)

2. Internalantenna

3. B

4. LED

6. V

Fig.2)Readeropening

utton

Terminal

oltageselector

EADER

IndicatorLED

PARTS DESCRIPTION

Fig.3)

2. P1B

3. LED L1

4. P2B

5. M

6. V

Fig. 4) Connection example with

4activationdevices.

RECEIVER

Terminal

utton

emory

oltageselector

INSTALLATION

Find a position for the reader which is easily accessible to the user, while

thereceivershouldbeinstalledindoors,inaprotectedposition.

Remove the lid of the reader with the aid of a screwdriver (fig. 2) and fix

thebottomfirmly, in a vertical position (the closing clip must be at the top).

Connect terminals 1-2 of the readers and 7-8 of the receiver to a 12 or 24V

power supply. Check that the voltage change jumper (6 in fig. 1 and 2) is

onlyconnectedwithpowersupplyat12V.

Check the communication line between the readers (terminals 3 - 4 fig. 1)

andthereceiver(terminals5-6fig.3).

In multiple systems, up to 4 control units (PASSO TS keypads or CARD

readers) can be used to activate the same receiver; in this case there will

be a single communication line, parallel-connecting all the circuit boards

asshowninfig.4.

Warning! use twisted cable for the data line, complying

with the references. The reader (or keypad) terminals

(A) must be connected to the terminal (A) of the

receiver, and the terminals (B) to(B) ofthe receiver.

Connect the devices to be controlled to the receiver outputs (terminals 1 -

2and/or3-4infig.3).

PROGRAMMING

TwotypesofCARDaresuppliedwitheachPASSO reader:

- MASTERCARD: thisisthe “key” for access to the programming and/or

deletionofcodesinreaders.

In a new system, the MASTER CARD is the first to be memorised, and a

33 34

TECHNICAL SPECIFICATIONS

PASSO CARD M.U. R Receiver

Power supply Vac/Vdc 12/24 12/24

Consumption (at 24Vac) mA 100 120

Relay contacts max. current A - 1

Relay contacts max. voltage Vac - 24

Connection line max. distance m 200

Transmission speed baud 38.400

No. of possible memorised codes nr. - 750

Max. number of receiver nr. 4 -

Operating temperature °C -20+55 -20+55

Protection class IP 54 20

Dimensions mm 102x43x34 79x48x21

eader

readers on

GB GB

secondone(optional)mayalsobeadded.

- USER CARD: this is the tag used to activate the receiver channel.

Each CARD sold has a different code, which can only be saved with the

aid of the MASTER CARD. Two or more USER CARDS can be copied

withtheaidofthePRGCARDprogrammer.

SavingtheMASTERCARD

In a new system (with no Master code in the memory), as soon as the

reader is powered up, beeps will be heard. Place the MASTER CARD

nexttothereadertoacquirethecodeandstopthebeeps.

ThesameMASTERCARDcanbesavedonseveralreaders.

ToenterthesecondMASTERCARD:

- place the first MASTER CARD next to the reader; it will start emitting

beeps

- place the new MASTER CARD for memorisation next to the reader; it

willconfirmtheoperationbygivingadoublebeep.

*WARNING! Take good care of all the MASTER CARDS and keep

them in a safe place. MASTER CARDS cannot be replaced or deleted

from the reader, and if they are lost no further programming is

possible.

SavingtheUSERCARDS

TheMASTERCARDmemorisedisrequiredforthisoperation.

Basic principle: passing the MASTER CARD over the reader once or

more sets the future operating mode of the USER CARDS about to be

saved.

ProcedureforactivatingnewUSERSonrelay1(OUT1)ofthereceiver:

-passtheMASTERCARDoverthereaderonce

-aseriesofsingleflashesoftheLEDonthefront,andbeeps,willstart

- pass the new USER CARD to be memorised over the reader; a flash and

alongerbeepconfirmthatthecodehasbeenacquired*

-proceedtomemorisemorecards,orwaitfortheLEDtostopflashing.

ProcedureforactivatingnewUSERSonrelay2(OUT2)ofthereceiver:

CLEARING THE RECEIVER MEMORY

-passtheMASTERCARDoverthereadertwice

-aseriesofdoubleflashesoftheLEDonthefront,andbeeps,willstart

- pass the new USER CARD to be memorised over the reader; a flash and

alongerbeepconfirmthatthecodehasbeenacquired*

-proceedtomemorisemorecards,orwaitfortheLEDtostopflashing.

(*) A series of 8 beeps and flashes of the LED indicates that the code is

alreadyinthememory.

ProcedurefordeletingaUSERCARD

-passtheMASTERCARDoverthereader4times

-aseriesof4flashesoftheLEDonthefront,andbeeps,willstart

- pass the USER CARD to be deleted over the reader; a flash and a longer

beepconfirmthatthecodehasbeendeleted

-proceedtodeletemorecards,orwaitfortheLEDtostopflashing.

WARNING! This procedure deletes all the codes in the receiver

memory.

Any PASSO digital keypads connected to this receiver will be

restored to their default condition, with MASTER code 1-2-3-4-5-6-7-

Procedure: hold down button P1 on the receiver for about 10 seconds

untiltheredLEDL1lightsup(det.2and3infig.3).

ThisoperationdoesnotdeletetheMASTERCARDS.

35 36

GB GB

secondone(optional)mayalsobeadded.

- USER CARD: this is the tag used to activate the receiver channel.

Each CARD sold has a different code, which can only be saved with the

aid of the MASTER CARD. Two or more USER CARDS can be copied

withtheaidofthePRGCARDprogrammer.

SavingtheMASTERCARD

In a new system (with no Master code in the memory), as soon as the

reader is powered up, beeps will be heard. Place the MASTER CARD

nexttothereadertoacquirethecodeandstopthebeeps.

ThesameMASTERCARDcanbesavedonseveralreaders.

ToenterthesecondMASTERCARD:

- place the first MASTER CARD next to the reader; it will start emitting

beeps

- place the new MASTER CARD for memorisation next to the reader; it

willconfirmtheoperationbygivingadoublebeep.

*WARNING! Take good care of all the MASTER CARDS and keep

them in a safe place. MASTER CARDS cannot be replaced or deleted

from the reader, and if they are lost no further programming is

possible.

SavingtheUSERCARDS

TheMASTERCARDmemorisedisrequiredforthisoperation.

Basic principle: passing the MASTER CARD over the reader once or

more sets the future operating mode of the USER CARDS about to be

saved.

ProcedureforactivatingnewUSERSonrelay1(OUT1)ofthereceiver:

-passtheMASTERCARDoverthereaderonce

-aseriesofsingleflashesoftheLEDonthefront,andbeeps,willstart

- pass the new USER CARD to be memorised over the reader; a flash and

alongerbeepconfirmthatthecodehasbeenacquired*

-proceedtomemorisemorecards,orwaitfortheLEDtostopflashing.

ProcedureforactivatingnewUSERSonrelay2(OUT2)ofthereceiver:

CLEARING THE RECEIVER MEMORY

-passtheMASTERCARDoverthereadertwice

-aseriesofdoubleflashesoftheLEDonthefront,andbeeps,willstart

- pass the new USER CARD to be memorised over the reader; a flash and

alongerbeepconfirmthatthecodehasbeenacquired*

-proceedtomemorisemorecards,orwaitfortheLEDtostopflashing.

(*) A series of 8 beeps and flashes of the LED indicates that the code is

alreadyinthememory.

ProcedurefordeletingaUSERCARD

-passtheMASTERCARDoverthereader4times

-aseriesof4flashesoftheLEDonthefront,andbeeps,willstart

- pass the USER CARD to be deleted over the reader; a flash and a longer

beepconfirmthatthecodehasbeendeleted

-proceedtodeletemorecards,orwaitfortheLEDtostopflashing.

WARNING! This procedure deletes all the codes in the receiver

memory.

Any PASSO digital keypads connected to this receiver will be

restored to their default condition, with MASTER code 1-2-3-4-5-6-7-

Procedure: hold down button P1 on the receiver for about 10 seconds

untiltheredLEDL1lightsup(det.2and3infig.3).

ThisoperationdoesnotdeletetheMASTERCARDS.

35 36

GB GB

CHANGING THE OUTPUT OPERATING MODE

Thereceiveroutputsareabletooperateinoneofthefollowingmodes:

PULSE: the relay is activated for about 1 second whenever it reads a

card.

STEPPING: the first time the card is passed the relay closes the contact

and it remains active until the next time a code present in the memory is

read.

TIMER: in this mode, when a code present in the memory is read, the

outputisactivatedfor30seconds.

If the system includes a PASSO keypad, the timer time setting can be

modifiedfrom2to255seconds(seePASSO manual).

The mode selected refers to the individual output; all the codes saved

previouslyorsubsequentlywillhavetheoperating mode chosen.

Procedure:

- Press the reader button and the red LED comes on (det. 3 and 4 in fig.

1).

- Pass the MASTER CARD over the reader and the LED will start to

flash.

- Press the button (det. 3 in fig. 1) several times to choose one of the

followingsettings:

1 Flash=tosetOUT1inPULSEmode.

2 Flashes=tosetOUT1inSTEPPING mode.

3 Flashes=tosetOUT1inTIMERmode(30”).

4 Flashes=tosetOUT2inPULSEmode.

5 Flashes=tosetOUT2in STEPPINGmode.

6 Flashes=tosetOUT2inTIMERmode(30”).

- Pass the MASTER CARD over the reader to confirm and quit the

programmingfunction.

OPERATION AND SIGNALS

MODIFICATIONS OR REPLACEMENTS IN THE

SYSTEM

PasstheCARDoverthereadertoactivatethedevices.

If the LED (DET. 1 in fig. 1) goes out for a moment and/or a beep is heard,

the CARD is in the memory and the receiver has activated the associated

output.

A sequence of 4 beeps and LED flashes, after a CARD is read, indicate

that the code read is not in the memory, and the receiver will not activate

eitheroutput.

A sequence of 10 beeps and LED flashes, after a CARD is read, indicate

thatthecommunicationlinetothereceiverhasfailed.

The MASTER CARDS are only enabled for programming functions and

cannotbeusedtoactivatedevicesdirectly.

To replace a reader (in the event of a failure) or add another to the

receiver,proceedasfollows:

-Maketheconnectionsasdescribedintheinstallation section.

-MemorisetheMASTERCARD

The USER codes will not be lost because they are retained in the receiver

part.

If the receiver part is replaced, to avoid losing all the codes saved, remove

thememory(det.5infig.3)fromtheoldreceiverandfitit in the new one.

37 38

Andere Handbücher für PASSO CARD Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Telcoma Kartenleser Handbücher

Telcoma

Telcoma PASSO CARD Series Installationshandbuch

Beliebte Kartenleser Handbücher anderer Marken

Lindy

Lindy 43185 Bedienungsanleitung

Lindy

Lindy 43185 Bedienungsanleitung

ViziT

ViziT RD-4F Bedienungsanleitung

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Bedienungsanleitung

AVID ID

AVID ID AVID1043 Bedienungsanleitung

Conrad

Conrad PCMCIA Bedienungsanleitung

Rosslare

Rosslare DR-6255 Bedienungsanleitung

Lindy

Lindy 51541 Bedienungsanleitung

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Bedienungsanleitung

Johnson Controls

Johnson Controls Kantech tyco ioSmart Bedienungsanleitung

ACS

ACS ACR122L Bedienungsanleitung

Secukey

Secukey S2-MF Bedienungsanleitung

Elecom

Elecom MR-SMC07 series Bedienungsanleitung

Alien

Alien ALR-9800 Bedienungsanleitung

ACS

ACS ACR310 Bedienungsanleitung

Datamars

Datamars R-IN1300 MID Bedienungsanleitung

Alarm Lock

Alarm Lock AL-PRE2 Bedienungsanleitung

xpr

xpr B100PROX-AH Benutzerhandbuch
