Telit Wireless Solutions GC864 Series Installationshandbuch

GC864 Hardware User Guide

GC864-PY, GC864-QUAD

1vv0300733 Rev. 0 - 12/06/06

GC864 Hardware User Guide

1vv0300733 Rev. 0 - 12/06/06

Contents

1Overview ...........................................................................................................................4

2Hardware Commands ......................................................................................................5

2.1 Turning ON the GC864 ...........................................................................................................5

2.2 Turning OFF the GC864 ........................................................................................................7

2.2.1 Hardware shutdown..........................................................................................................................7

2.3 Hardware Unconditional Reboot...........................................................................................7

3Power Supply ...................................................................................................................9

3.1 Power Supply Requirements.................................................................................................9

3.2 General Design Rules ..........................................................................................................10

3.2.1 Electrical design Guidelines........................................................................................................... 10

3.2.1.1 + 5V input Source Power Supply Design Guidelines ................................................................ 10

3.2.1.2 + 12V input Source Power Supply Design Guidelines .............................................................. 12

3.2.1.3 Battery Source Power Supply Design Guidelines ..................................................................... 13

3.2.1.4 Battery Charge control Circuitry Design Guidelines .................................................................. 13

3.2.2 Thermal Design Guidelines ........................................................................................................... 15

3.2.3 Power Supply PCB layout Guidelines ........................................................................................... 16

4Antenna...........................................................................................................................17

4.1 Antenna Requirements ........................................................................................................17

4.2 GC864 Antenna Connector..................................................................................................17

4.3 Antenna installation Guidelines..........................................................................................18

5GC864 pins allocation....................................................................................................19

NOTE: RESERVED pins must not be connected..........................................................................21

6Serial Port .......................................................................................................................22

6.1 RS232 level translation ........................................................................................................24

6.2 5V UART level translation....................................................................................................26

7Audio Section Overview ................................................................................................28

7.1 Microphone paths characteristic and requirements .........................................................30

7.2 General Design Rules ..........................................................................................................33

7.3 Other considerations. ..........................................................................................................33

7.4 Microphone Biasing .............................................................................................................34

7.4.1 Balanced Microphone biasing........................................................................................................ 34

7.4.2 Unbalanced Microphone biasing ...................................................................................................35

GC864 Hardware User Guide

1vv0300733 Rev. 0 - 12/06/06

7.5 Microphone buffering...........................................................................................................37

7.5.1 Buffered Balanced Mic................................................................................................................... 37

7.5.2 Buffered Unbalanced (Single Ended) Microphone . ...................................................................... 39

8OUTPUT LINES (Speaker)..............................................................................................42

8.1 Short description..................................................................................................................42

8.2 Output lines characteristics . .............................................................................................43

8.3 General Design rules............................................................................................................44

8.3.1 Noise Filtering................................................................................................................................ 44

8.4 Handset earphone design....................................................................................................45

8.5 Hands-free earphone (low power) design ..........................................................................46

8.6 Car Kit speakerphone design..............................................................................................47

9External SIM Holder .......................................................................................................48

9.1 SIM DESIGN GUIDES............................................................................................................48

10 General Purpose I/O.......................................................................................................50

10.1 Using a GPIO pad as INPUT.............................................................................................50

10.2 Using a GPIO pad as OUTPUT.........................................................................................50

10.3 Using the Alarm Output GPIO_06/ALARM......................................................................51

10.4 Using the Buzzer Output GPIO_07/BUZZER...................................................................51

11 Camera ............................................................................................................................52

11.1 Camera characteristics ....................................................................................................52

11.1.1 Camera interface connectors......................................................................................................... 52

11.1.2............................................................................................................................................................. 53

11.1.3............................................................................................................................................................. 53

11.1.4............................................................................................................................................................. 53

11.1.5 EVB for Transchip camera support ............................................................................................... 54

11.1.6 Example usage script for camera .................................................................................................. 55

12 Conformity Assessment Issues....................................................................................56

13 SAFETY RECOMMANDATIONS.....................................................................................57

14 Document Change Log ..................................................................................................58

Annex A – EVK2 schematics ...............................................................................................59

Annex B - Camera EVB schematics ....................................................................................65

GC864 Hardware User Guide

1vv0300733 Rev. 0 - 12/06/06

1 Overview

The aim of this document is the description of some hardware solutions useful for developing a product with the

Telit GC864 module.

In this document all the basic functions of a mobile phone will be taken into account; for each one of them a

proper hardware solution will be suggested and eventually the wrong solutions and common errors to be

avoided will be evidenced. Obviously this document can not embrace the whole hardware solutions and

products that may be designed. The wrong solutions to be avoided shall be considered as mandatory, while the

suggested hardware configurations shall not be considered mandatory, instead the information given shall be

used as a guide and a starting point for properly developing your product with the Telit GC864 module. For

further hardware details that may not be explained in this document refer to the Telit GC864 Product Description

document where all the hardware information is reported.

NOTICE

(EN) The integration of the GC864 GSM/GPRS cellular module within user application shall be

done according to the design rules described in this manual.

(IT) L’integrazione del modulo cellulare GSM/GPRS GC864 all’interno dell’applicazione

dell’utente dovrà rispettare le indicazioni progettuali descritte in questo manuale.

(DE) Die Integration des GC864 GSM/GPRS Mobilfunk-Moduls in ein Gerät muß gemäß der in

diesem Dokument beschriebenen Konstruktionsregeln erfolgen

(SL) Integracija GSM/GPRS GC864 modula v uporabniški aplikaciji bo morala upoštevati

projektna navodila, opisana v tem priročniku.

(SP) La utilización del modulo GSM/GPRS GC864 debe ser conforme a los usos para los

cuales ha sido diseñado descritos en este manual del usuario

(FR) L'intégration du module cellulaire GC864 GSM/GPRS dans l'application de l'utilisateur

sera faite selon les règles de conception décrites dans ce manuel

(HE)

The information presented in this document is believed to be accurate and reliable. However, Telit

Communication assumes no responsibility for its use, nor any infringement of patents or other rights of third

parties which may result from its use. No license is granted by implication or otherwise under any patent rights of

Telit Communication other than for circuitry embodied in Telit products. This document is subject to change

without notice.

GC864 Hardware User Guide

1vv0300733 Rev. 0 - 12/06/06

2 Hardware Commands

2.1 Turning ON the GC864

To turn on the GC864 the pad ON# must be tied low for at least 1 second and then released.

The maximum current that can be drained from the ON# pad is 0,1 mA.

A simple circuit to do it is:

NOTE: don't use any pull up resistor on the ON# line, it is internally pulled up. Using pull up

resistor may bring to latch up problems on the GC864 power regulator and improper power

on/off of the module. The line ON# must be connected only in open collector configuration.

NOTE: In this document all the lines that are inverted, hence have active low signals are

labeled with a name that ends with a "#" or with a bar over the name.

NOTE: The GC864 turns fully on also by supplying power to the Charge pad (provided there's

a battery on the VBATT pads).

ON#

Power ON impulse

GND

GC864 Hardware User Guide

1vv0300733 Rev. 0 - 12/06/06

For example:

1- Let's assume you need to drive the ON# pad with a totem pole output of a +3/5 V microcontroller

(uP_OUT1):

2- Let's assume you need to drive the ON# pad directly with an ON/OFF button:

GC864 Hardware User Guide

1vv0300733 Rev. 0 - 12/06/06

2.2 Turning OFF the GC864

The turning off of the device can be done in three ways:

• by software command (see GC864 Software User Guide)

• by hardware shutdown

When the device is shut down by software command or by hardware shutdown, it issues to the

network a detach request that informs the network that the device will not be reachable any more.

2.2.1 Hardware shutdown

To turn OFF the GC864 the pad ON# must be tied low for at least 1 second and then released.

The same circuitry and timing for the power on shall be used.

The device shuts down after the release of the ON# pad.

TIP: To check if the device has powered off, the hardware line PWRCTL should be monitored.

When PWRCTL goes low, the device has powered off.

2.3 Hardware Unconditional Reboot

To unconditionally Reboot the GC864, the pad RESET# must be tied low for at least 200 milliseconds

and then released.

The maximum current that can be drained from the ON# pad is 0,15 mA.

A simple circuit to do it is:

NOTE: don't use any pull up resistor on the RESET# line nor any totem pole digital output.

Using pull up resistor may bring to latch up problems on the GC864 power regulator and

improper functioning of the module. The line RESET# must be connected only in open

collector configuration.

RESET#

Unconditional Reboot

impulse

GND

GC864 Hardware User Guide

1vv0300733 Rev. 0 - 12/06/06

TIP: The unconditional hardware reboot should be always implemented on the boards and

software should use it as an emergency exit procedure.

For example:

1- Let's assume you need to drive the RESET# pad with a totem pole output of a +3/5 V

microcontroller (uP_OUT2):

GC864 Hardware User Guide

1vv0300733 Rev. 0 - 12/06/06

3 Power Supply

The power supply circuitry and board layout are a very important part in the full product design and

they strongly reflect on the product overall performances, hence read carefully the requirements and

the guidelines that will follow for a proper design.

3.1 Power Supply Requirements

The GC864 power requirements are:

• Nominal Supply Voltage: 3.8 V

• Max Supply Voltage: 4.2 V

• Supply voltage range: 3.4 V - 4.2 V

• Max Peak current consumption (impulsive): 1.9 A

• Max Average current consumption during GPRS transmission (rms): 500 mA

• Max Average current consumption during VOICE/CSD transmission (rms): 270 mA

• Average current during Power Saving: ≈4 mA

• Average current during idle (Power Saving disabled) ≈19 mA

The GSM system is made in a way that the RF transmission is not continuous, else it is packed into

bursts at a base frequency of about 216 Hz, the relative current peaks can be as high as about 2A.

Therefore the power supply has to be designed in order to withstand with these current peaks without

big voltage drops; this means that both the electrical design and the board layout must be designed for

this current flow.

If the layout of the PCB is not well designed a strong noise floor is generated on the ground and the

supply; this will reflect on all the audio paths producing an audible annoying noise at 216 Hz; if the

voltage drop during the peak current absorption is too much, then the device may even shutdown as a

consequence of the supply voltage drop.

TIP: The electrical design for the Power supply should be made ensuring it will be capable of a

peak current output of at least 2 A.

GC864 Hardware User Guide

1vv0300733 Rev. 0 - 12/06/06

3.2 General Design Rules

The principal guidelines for the Power Supply Design embrace three different design steps:

- the electrical design

- the thermal design.

- the PCB layout.

3.2.1 Electrical design Guidelines

The electrical design of the power supply depends strongly from the power source where this power is

drained. We will distinguish them into three categories:

• +5V input (typically PC internal regulator output)

• +12V input (typically automotive)

• Battery

3.2.1.1 + 5V input Source Power Supply Design Guidelines

• The desired output for the power supply is 3.8V, hence there's not a big difference between the

input source and the desired output and a linear regulator can be used. A switching power supply

will not be suited because of the low drop out requirements.

• When using a linear regulator, a proper heat sink shall be provided in order to dissipate the power

generated.

• A Bypass low ESR capacitor of adequate capacity must be provided in order to cut the current

absorption peaks close to the GC864, a 100μF tantalum capacitor is usually suited.

• Make sure the low ESR capacitor on the power supply output (usually a tantalum one) is rated at

least 10V.

• A protection diode should be inserted close to the power input, in order to save the GC864 from

power polarity inversion.

Andere Handbücher für GC864 Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Telit Wireless Solutions Steuereinheit Handbücher

Telit Wireless Solutions

Telit Wireless Solutions ME50-868 Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions GM862GPS Series Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions GC864-QUAD-C2 Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions DE910-DUAL Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions GL865 QUAD Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions BlueMod+S42M Betriebsanleitung

Telit Wireless Solutions

Telit Wireless Solutions GE864-QUAD Automotive V2 Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions SE868K A Series Technisches Datenblatt

Telit Wireless Solutions

Telit Wireless Solutions SE867-AGPS Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions FN980m TLB Leitfaden

Telit Wireless Solutions

Telit Wireless Solutions LE50-868 Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions JF2 Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions WE310F5-I Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions LE910C1-NAD Leitfaden

Telit Wireless Solutions

Telit Wireless Solutions SL869T3-I Technisches Datenblatt

Telit Wireless Solutions

Telit Wireless Solutions UL865N3G Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions GS2101M Series Betriebsanleitung

Telit Wireless Solutions

Telit Wireless Solutions NL865H2 Series Leitfaden

Telit Wireless Solutions

Telit Wireless Solutions LN940A11 SERIES Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions ME910C1 Series Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions CC864-DUAL Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions SC872-A Technisches Datenblatt

Telit Wireless Solutions

Telit Wireless Solutions HE863 Series Installationshandbuch

Telit Wireless Solutions

Telit Wireless Solutions GC864-QUAD-C9 Installationshandbuch

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
