Telos VSet Desktop

Controller

For use with Telos VX, Hx6, and iQ6 Systems

Installation & User’s Guide

Software Version: 1.0.0 or newer |November, 2018

For use with:

Telos VX, VX Prime, VX Enterprise, VX Prime+, Telos Hx6 Six-Line POTS Talkshow System,

Telos iQ6 Six-Line POTS Telco Gateway

P/N: 1490-00205-001 --- USER MANUAL: VSDC

TelosAlliance.com

User Warnings and Cautions

The installation and service instructions in this manual are for use by qualiﬁed personnel only. To avoid

electric shock, do not perform any servicing other than that contained in the operating instructions

unless you are qualiﬁed to do so. Refer all servicing to qualiﬁed personnel

This instrument has an autoranging line voltage input. Ensure the power voltage is within the speciﬁed

range of 100-240VAC. The ~ symbol, if used, indicates an alternating current supply.

This symbol, wherever it appears, alerts you to the presence of uninsulated, dangerous voltage

inside the enclosure – voltage which may be suﬃcient to constitute a risk of shock.

This symbol, wherever it appears, alerts you to important operating and maintenance instruc-

tions. Read the manual.

CAUTION: HAZARDOUS VOLTAGES

The instrument power supply incorporates an internal fuse. Hazardous voltages may still be present on

some of the primary parts even when the fuse has blown. If fuse replacement is required, replace fuse

only with same type and value for continued protection against ﬁre.

WARNING:

The product’s power cord is the primary disconnect device. The socket outlet should be located near

the device and easily accessible. The unit should not be located such that access to the power cord is

impaired. If the unit is incorporated into an equipment rack, an easily accessible safety disconnect

device should be included in the rack design.

To reduce the risk of electrical shock, do not expose this product to rain or moisture. This unit is for

indoor use only.

This equipment requires the free ﬂow of air for adequate cooling. Do not block the ventilation openings

on the rear and sides of the unit. Failure to allow proper ventilation could damage the unit or create a

ﬁre hazard. Do not place the units on a carpet, bedding, or other materials that could interfere with any

panel ventilation openings.

If the equipment is used in a manner not speciﬁed by the manufacturer, the protection provided by the

equipment may be impaired.

USA CLASS A COMPUTING DEVICE INFORMATION TO USER.

WARNING:

This equipment generates, uses, and can radiate radio-frequency energy. If it is not installed and used as

directed by this manual, it may cause interference to radio communication. This equipment complies

with the limits for a Class A computing device, as speciﬁed by FCC rules, part 15, subpart j, which are

designed to provide reasonable protection against such interference when this type of equipment is op-

erated in a commercial environment. Operation of this equipment in a residential area is likely to cause

interference. If it does, the user will be required to eliminate the interference at the user’s expense.

Note: objectionable interference to TV or radio reception can occur if other devices are connected to

this device without the use of shielded interconnect cables. FCC rules require the use of shielded cables.

CANADA WARNING:

“This digital apparatus does not exceed the Class A limits for radio noise emissions set out in the radio

interference regulations of the Canadian department of communications.”

“Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables

aux appareils numériques (de Class A) prescrites dans le règlement sur le brouillage radioélectrique

édicté par le ministère des communications du Canada.”

CE CONFORMANCE INFORMATION:

This device complies with the requirements of the EEC council directives:

♦93/68/EEC (CE MARKING)

♦73/23/EEC (SAFETY – LOW VOLTAGE DIRECTIVE)

♦89/336/EEC (ELECTROMAGNETIC COMPATIBILITY)

Conformity is declared to those standards: EN50081-1, EN50082-1.

Trademarks, Patents, and Licenses

Telos is a trademark of TLS Corp. All other trademarks are the property of their respective holders.

All versions, claims of compatibility, trademarks, etc. of hardware and software products not made by

The Telos Alliance which are mentioned in this manual or accompanying material are informational

only. The Telos Alliance makes no endorsement of any particular product for any purpose, nor claims

any responsibility for operation or accuracy. We reserve the right to make improvements or changes

in the products described in this manual which may aﬀect the product speciﬁcations, or to revise the

manual without notice.

This document and its content are copyrighted by TLS Corporation and may not be copied, reproduced,

or distributed in any form without expressed written permission.

Patent information can be found at www.TelosAlliance.com/legal

Updates

Telos VSet Desktop Controller features and operations are determined largely by software. The Telos

Alliance strives to provide the most stable and feature-rich software available. We encourage you to

check for software updates from time to time by visiting our website or by contacting us directly.

Feedback

We welcome feedback on any aspect of our products or this manual. In the past, many good ideas from

users have made their way into software revisions or new products. Please contact us with your

comments or suggestions.

We support you…

By Phone/Fax

You may reach our Telos Support Team in emergencies by calling +1 216-622-0247. For billing questions

or other non-emergency technical questions, call +1 216-241-7225 between 9:00 AM to 5:00 PM USA

Eastern Time, Monday through Friday.

By Email.

Non-emergency technical support is available at Support@TelosAlliance.com.

By Web

The Telos Web site has a variety of information that may be useful for product selection and support. The

URL is https://www.TelosAlliance.com/Telos .

SERVICE

You must contact Telos Alliance before returning any equipment for factory service. We will need your

unit’s serial number, located on the back of the unit. We will issue a return authorization number, which

must be written on the exterior of your shipping container. Please do not include cables or accessories un-

less speciﬁcally requested by the Technical Support Engineer. Be sure to adequately insure your shipment

for its replacement value. Packages without proper authorization may be refused. US customers, please

contact Telos Alliance Technical Support at +1-216-622-0247. All other customers should contact local

representative to make arrangements for service.

Warranty

For the latest Telos Alliance warranty, visit: telosalliance.com/warranty

telosalliance.com/product-registration/

The Telos Alliance

1241 Superior Ave. Cleveland, OH 44114 USA

+1 (216) 241-7225

For Telos Support:

24/7 telephone: +1 (216) 622-0247

Email: [email protected]

Web: telosalliance.com/support-request

Table of Contents

Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . ii

We support you… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

1 VSet Desktop Controller Anatomy 1

2 Installation 3

Before You Begin…. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Connect Your VSet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Assign an IP Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Connect to theTelos System . . . . . . . . . . . . . . . . . . . . . . . . . 5

Select Studio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Select Show . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

(Vx Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3 User Operation 7

Talent and Producer Modes . . . . . . . . . . . . . . . . . . . . . . . . . 7

Line Status Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Line Button Columns . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Hold Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Drop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Next Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Block All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Numeric Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Hx6 & iQ6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Vx Engine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Take it Easy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4 Menu Button 13

Call History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Address Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Select Show (VX Systems Only) . . . . . . . . . . . . . . . . . . . . . . 13

Mute Ringer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Status and About . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

VSet Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

HTTP Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Telnet Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

24-Line Mode and Default Fader (VX Systems Only) . . . . . . . . . . . . . 14

Reset to Factory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Test Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Engine Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Engine IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Vx Engine List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

User and Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Select Studio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

User Preferences Menu . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Auto Hold. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Lockless Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Auto Dial Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

5 Web Graphical User Interface 17

The Default login is: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Screenshot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Cong . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Firmware Upgrade and Version . . . . . . . . . . . . . . . . . . . . . . . . 18

User Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Syslog Server Conguration . . . . . . . . . . . . . . . . . . . . . . . . .19

Warranty 20

Creating the Most Exciting and Engaging

Audio Experiences Imaginable

Congratulations on your new Telos Alliance product!

The gang here at Telos is committed to shaping the future of audio by delivering innovative, intuitive

solutions that inspire our customers to create the most exciting and engaging audio experiences imaginable.

We’re grateful that you have chosen audio tools from Telos® Systems, Omnia® Audio, Axia® Audio,

Linear Acoustic®, 25-Seven Systems®, and Minnetonka Audio®. We’re here to help you make your

work truly shine. We hope that you enjoy your Telos Alliance product for many years to come and won’t

hesitate to let us know if we can help in any way.

The Telos Alliance

Chapter 1 | 1

VSet Desktop Controller Anatomy

1 VSet Desktop Controller Anatomy

1. Number Keypad

2. Menu Button

3. Hook-Flash / Transfer Button

4. Block All Button

5. Screen Hold Button

6. Left Line 1-6 Buttons

7. Left Line 7-12 Buttons

8. Right Line 1-6 Buttons

9. Right Line 7-12 Buttons

10. Top Display

11. Bottom Display

12. Left Hold Button

13. Left Drop Button

14. Right Hold Button

15. Right Drop Button

16. Next Button

17. User Dump GPIO Button
