TELTONIKA ModemCOM/G10
(CM1100)
User Manual V0.1
ModemCOM-TM2 User’ Manual v2.1.1.19
2
Table of Contents
TABLE OF CONTENTS..........................................................................................................................2
1. ATTENTION..................................................................................................................................3
2. SAFETY INSTRUCTION ............................................................................................................3
3. LEGAL NOTICE ...........................................................................................................................5
4. INTRODUCTION .........................................................................................................................5
5. PACKAGE CONTENTS..............................................................................................................5
6. TECHNICAL SPECIFICATIONS..............................................................................................6
6.1 Data transferring ...............................................................................................................................6
6.2 Mechanical specifications.................................................................................................................6
6.3 Electrical and operating specifications...........................................................................................6
6.4 Indication............................................................................................................................................7
6.5 Pins of DB9 (COM) connector.......................................................................................................9
7. MODEM SETUP ..........................................................................................................................10
7.1 Connecting to the computer..........................................................................................................10
7.2 Installation of “Modem Control Tool”........................................................................................10
7.3 Setting up an Internet connection ................................................................................................13
7.4 Sending Short Text Messages (SMS)............................................................................................16
7.5 Changing security settings..............................................................................................................17
8. ACRONYMS..................................................................................................................................21
9. TECHNICAL SUPPORT............................................................................................................22
ModemCOM-TM2 User’ Manual v2.1.1.19
3
1. ATTENTION
Do not rip the device. Do not touch the device if the device is
broken or his connecting wires are without isolation
All wireless devices for data transferring may be susceptible to
interference, which could affect performance.
Only qualified personnel may install or repair this product.
Your device is not water-resistant. Keep it dry.
2. SAFETY INSTRUCTION
General safety requirements
In this document you will be introduced how to use the “ModemCOM/G10” device safely.
You will avoid dangerous situations and harming of yourself if you stick to these requirements and
recommendations. You have to be familiar with the safety requirements before starting using the
device!
The device requires 9V power supply. The PC, to which the device “ModemCOM/G10” is to
be connected, must have a COM port. Nominal power supply voltage is 9 V. Available power supply
source range is 6 V … 32 V.
To avoid burning and voltage caused traumas of the personnel working with the device, please
follow these safety requirements.
ModemCOM-TM2 User’ Manual v2.1.1.19
4
In the installation place and supply circuits the protective devices should be tooled up (bipolar
release device) which will protect the device from short-circuit and grounding troubles (Picture 1.1).
The power of the release device should satisfy the power of connected to it devices. The interstice
between release contacts should not be less than 3mm. The power supply network should be installed
near device on easily accessible place.
Picture 1.1. Scheme for safe connection of the device
Full disconnection of the device is performed by pulling out the constant current DC plug from
the device.
Data transfer cable for connection to another device must not be longer than 2 meters.
Maintenance of the device:
If the device starts working faulty only qualified personnel may repair this product. We
recommend dismantling the device and forwarding it tit repair center or to manufacturers. No
exchangeable parts in the device.
The PC and power supply source, to which the device “ModemCOM-TM2” is connected should
satisfy LST EN 60950-1 standards. The device can be used with the first (Personal Computer)
or the second (Notebook) computer safety class.
ModemCOM-TM2 User’ Manual v2.1.1.19
5
To use the devise needed:
AC/DC supply source. The power supply should be 6V@580mA to 32V@108mA.
3. LEGAL NOTICE
Copyright © 2008 TELTONIKA Ltd.
All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of TELTONIKA Ltd is prohibited.
Other product and company names mentioned herein may be trademarks or trade names of their
respective owners.
4. INTRODUCTION
This document will provide you with the instructions how to install and use
„ModemCOM/G10“ and its software.
„ModemCOM/G10“ is a device designed for data transmission via GSM Network. The design of
this modem enables the connection to your PC through COM interface. „ModemCOM/G10“
supports the following data-bearers: GPRS, CSD, CSF and SMS.
5. PACKAGE CONTENTS
„ModemCOM/G10“ is supplied to clients in carton with all contents, which are needed for
connection to PC and normal work.
Package contents:
1) „ModemCOM/G10“ modem;
2) RS232 connecting cable;
3) CD with User’s Guide, drivers and Software;
4) External GSM antenna (just upon special orders);
5) AC/DC mains adapter.
Notice: the producer does not provide a SIM card among other items of a package, which is necessary
for connection to GSM Network! You can obtain a SIM card from your local GSM service provider!
If any of the components is missing please contact your local distributor.
To avoid dangerous voltage effect, the power supply and the PC must be disconnected from the
electric network before starting dismantling it.
ModemCOM-TM2 User’ Manual v2.1.1.19
6
6. TECHNICAL SPECIFICATIONS
6.1 Data transferring
„ModemCOM/G10“ supports bearers presented below. Which data type is used depends on
GSM operator and data transfer capacity in the chosen GSM Network.
•GPRS class 10 (class B);
•CSD;
•CSF;
•SMS textual messages.
6.2 Mechanical specifications
„ModemCOM/G10“ housing is made of metal. It is light and durable – suitable for using in
home, office or industrial environment. The external dimensions and measures of the unit casing are:
100*60*31 mm.
6.3 Electrical and operating specifications
Acceptable voltage range is (6 ÷ 32)V DC. 9 V is a nominal value. The PC the
„ModemCOM/G10“ modem is connected to must have a RS232 (COM) interface.
Note: The device must be powered with AC/DC adapter provided by manufacturer.
Electrical parameters of the device are shown in the Table 1.
Table 1. Electrical parameters of the device
Parameter Min Typical Max
Power Supply +6V 0.58A +9V 0.39A +32V 0.1A
Average Power consumption - 480 mW -
Maximum Power consumption 1 - 3500 mW -
ModemCOM-TM2 User’ Manual v2.1.1.19
7
Operating conditions and other parameters are shown in Table 2.
Table 2. Operating conditions
Parameter Min Typical Max Meas. Units
Weight (modem only) - 85 ± 10 - g
Recommended operating
temperature
+15 - +35 ºC
Marginal operating temperature -20 - +55 ºC
Storage temperature -40 - +85 ºC
Notice: if the settings outreach the characteristics given above the device can be damaged!
6.4 Indication
On the „ModemCOM/G10“ modem were integrated 3 indicators: „POWER“ and 2
„STATUS“ indicators. They are located on the side of device.
A LED indicator “Power“ is located on the side of ModemCOM/G10.
“Power“ LED‘s Status Modem status
„Power“ LED is on Modem power supply is on
„Power“ LED is off Modem power supply is off
ModemCOM-TM2 User’ Manual v2.1.1.19
8
A LED indicators “Status“ are located on the side of ModemCOM/G10.
“Status“ LEDs LED Status Modem Description
STATUS 1 (Green) ON Modem ready
STATUS 1 (Green) Slow blink Initialization
STATUS 1 (Green) Double blink Limited service PIN/PUK required
STATUS 2 (Orange) Continuously blinking Network absent
STATUS 2 (Orange) Slow blink GPRS fail
STATUS 2 (Orange) Double blink No SIM
Picture 2. Side view of „ModemCOM/G10“
Connectors:
•DB9 female for connection to the device;
•3,5 mm/1,35 mm power supply connector;
•SIM card slot.
ModemCOM-TM2 User’ Manual v2.1.1.19
9
6.5 Pins of DB9 (COM) connector
Picture 6.5.1. Pins of COM port
ModemCOM-TM2 User’ Manual v2.1.1.19
10
7. MODEM SETUP
7.1 Connecting to the computer
1) Turn OFF your computer
2) Insert the SIM card into modem. Follow the instructions on the device sticker. Make
sure, the SIM card is pushed inside till it fixes.
3) Plug DB9 connector of the serial (RS232) cable into the modem.
4) Plug another end of the serial cable to one of the COM ports of PC.
5) Plug in the AC/DC adapter to power supply socket of “ModemCOM/G10”.
6) Plug in the AC/DC adapter to power supply network.
7) Turn ON your computer
7.2 Installation of “Modem Control Tool”
Step 1 - Open the “ModemCOM/G10”
Pack, take only the CD and insert it into
the PC CD Drive.
Step 2 – Wait till the system displays the
screen “Select Setup Language”.
Step 3 - Select English and Click “OK”
button.
Step 4 -Click “Install” button
