NOTE: This User Instruction Manual contains important information, including
safety & installation points, which will enable you to get the most out of
your appliance. Please keep it in a safe place so that it is easily available
for future reference, for you or any person not familiar with the operation of
the appliance.
V1/2021
USER MANUAL
Wine Coolers
OZ60SB OZ60DB
OZ60DX OZ60DW
OZ90DB OZ90DX
OZ90DW OZ124SB
OZ124DB
--CONTENTS--
04 Conformity
04 Energy Saving
04 Service
05 DESCRIPTION OF APPLIANCE
05 Product Features
07 Control Panel
08 Interior light
09 The Wine Cooler shelves
09 USING YOUR WINE COOLER
09 Before Switching On
10 During First Use
10 Locking/Unlocking The Control Panel
10 Setting The Temperature Range
11 Setting The Temperature
12 Power On/ O And Standby
12 The Interior Light
12 Switch OC/OF
13 Lighting On/O Buttons Backlit And Display Window
13 Power Saving Mode of Display Window
13 Overheating Warning
14 Error Code
14 Display Actual/Set Temperature
14 Loading The Wine Cooler
17 Storing Your Wines
18 Wine Storage Problems
19 INSTALLATION
19 Electrical Connection
20 Positioning
21 Built-In Installation
24 Installing The Handle
24 Reversing The Door Of Your Wine Cooler
29 CLEANING AND MAINTENANCE
29 Cleaning The Wine Cooler
30 Removing The Shelves For Cleaning
30 Carbon Filter Change
30 Moving Your Wine Cooler
30 Power Failure
31 Vacation Time
31 Disconnecting From Power
33 TROUBLESHOOTING
SAFETY INFORMATION
This appliance uses flammable refrigerants and flammable insulation
blowing gases. Before using the appliance, please properly position and
install it as described in this manual. To avoid the risk of fire, electrical
shock, or injury when using the appliance, follow these basic precautions:
● This appliance is for domestic purposes and is intended to be used
exclusively for the storage of sealed bottled wines.
● The appliance must be positioned so that the plug is accessible.
●Make sure the voltage/current marked on the rating label corresponds
with your supply voltage. Plug into a grounded 3-pin outlet, do not
remove grounding pin, do not use an adapter, and do not use an
extension cord.
● Do not connect or disconnect the electric plug with wet hands.
● To disconnect the appliance, grip the plug and pull it from the wall outlet.
Never pull out by the cord.
● It is recommended that a separate circuit, serving only your appliance
be provided.
● Unplug the appliance or disconnect power before cleaning,
maintenance or servicing. Failure to do so can result in electrical shock
or death.
● If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a
hazard.
● The fuse (or circuit breaker) size should be 10 amps or higher.
● To ensure proper ventilation for the appliance, the front of the unit must
be completely unobstructed. Locate the unit away from direct sunlight
and sources of heat (stove, heater, radiator, etc.).
● Do not attempt to repair or replace any part of the appliance unless it
is specially recommended in this manual. All other servicing should be
referred to a qualied technician.
● Ensure enough peoples to move and install the appliance to avoid any
damage to the appliance or injury to the peoples.
● It is important for the appliance to be leveled in order to work properly.
You may adjust the appliance’s feet to level it.
● Never clean the appliance parts with ammable uids which may create
a re hazard or explosion. And do not store or use gasoline or other
ammable apors and liquids in the vicinity of the appliance.
● Do not use solvent-based cleaning agents of abrasives on the interior.
These cleaners may damage or discolor the interior.
● Do not use this appliance for other than its intended purpose.
● Do not store explosive substances such as aerosol cans with a ammable
propellant in this appliance.
● The use of attachments not recommended by the manufacturer may be
hazardous.
● Please keep the products away from the re or similar glowing substance
before you dispose the appliance.
● GWP( Global Warming Potential): R600a=3
● When you dispose the appliance, take o the door and leave the shelves
in place so that children may not easily climb inside. And make sure the
coolant circuit, particularly the heat exchanger at the back/bottom of
the unit is not be damaged.
● The recycle symbol on the product or its packaging indicates that this
product is not to be handled as normal household waste and it is to be
taken to a recycling collection point for electrical and electronic goods.
● This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
● This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
● Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
● This appliance is intended to be used in household and similar
applications such as:
1.staff kitchen areas in shops, ofces and other working environments;
2. farm houses and by clients in hotels, motels and other residential type
environments;
3.bed and breakfast type environments;
4.catering and similar non-retail applications
– WARNING: Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
– WARNING: Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
– WARNING: Do not damage the refrigerant circuit.
– WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
- WARNING: When positioning the appliance, ensure the supply cord is not
trapped or damaged.
- WARNING: Do not locate multiple portable socket- outlets or portable
power suppliers at the rear of the appliance.
- WARNING: To avoid a hazard due to instability of the appliance, it must
be xed in accordance with the instructions
.
basis, as long as the equipment is of equivalent type and has the same
functions as the supplied equipment.
Conformity
By placing the marking on this product, we declare, on our
own responsibility, compliance to all of European safety ,health and
environmental requirements stated in the legislation for this product.
Energy Saving
--Always ensure good ventilation. Do not cover ventilation opening or grille.
--Always keep fan louvers clear.
--Do not place appliance in areas of direct sunlight or close to a stove,
heather or similar object.
--Open or keep the doors open as little as possible
--Remove dust present on the rear of the appliance
Service
● You should not attempt to repair the appliance
yourself, as this could cause injury or a more serious
malfunction. If you require a service call then please
contact the Customer Care Department
DESCRIPTION OF APPLIANCE
Product Features
1Control Panel 5 Glass Door
2Beech Shelves (Long) 6Handle
3Separator (Dual Zone) 7Gasket
4Beech Shelves (Short) 8Feet
Single Zone
OZ60SB OZ60DB OZ60DX OZ60DW
Dual Zone
30 Bottles 28 Bottles Single & Dual Zone
1
3
2
4
5
6
8
7
1Control Panel(Single Zone) 5 Glass Door
2Beech Shelves (Long) 6Handle
3Separator (Dual Zone) 7Gasket
4Beech Shelves (Short) 8Feet
Single Zone
OZ90SB OZ90DB OZ90DX OZ90DW
Dual Zone
47 Bottles 41 Bottles Single & Dual Zone
1
3
2
4
5
6
8
7
1
3
2
4
5
6
8
7
1Control Panel (Single Zone) 5 Glass Door
2Beech Shelves (Long) 6Handle
3Control Panel (Dual Zone) 7Gasket
4Beech Shelves (Short) 8Feet
Single Zone
OZ124SB OZ124DB
Dual Zone
81 Bottles 74 Bottles Single & Dual Zone
Control Panel
Buttons on Control Panel: Single Zone
63 7
1Power 5Temp.Plus
2Light 6Temp.Minus
3Lock 7
o
C/
o
F Switch
2+6 +Temp. Display Mode
4 Display Window
1
o
C5Warning
2
o
F6Digital
3Compressor 7Screen on
4Lock
Marks on Dispaly Window
Buttons on Control Panel: Dual Zone
1
Power
5
Temp.Plus
2
Light
6
Temp.Minus
2+6 +
Temp.
Display Mode
5+6 +o
C/
o
F Switch
3
Lock
7
Temp.Zone
Select
4Display Window
1
Digital On
Upper Zone
7
Compressor
2
Upper Zone
8
Lock
3 o
C
9
Warning
4o
F
10
Screen
5
Lower Zone
6
Digital On
Lower Zone
63 7
Marks on Dispaly Window
Interior light
