Teufel Ultima 40 C Bedienungsanleitung

Ultima 40 C

Center speaker

Technical Description

and User Manual

2• Ultima 40 C

Contents

General Notes and Information

Notice

The information in this document

may change without prior notice and

in no way constitutes any liability

on the part of Lautsprecher Teufel

GmbH.

No part of this user manual may

be reproduced in any form or be

broadcasted in any way electroni-

cally, mechanically, by photocopy or

recording without the written permis-

sion of Lautsprecher Teufel GmbH.

Version 3.0, July 2018

General Notes and Information........ 2

For Your Safety................................... 3

Unpacking, Setup, Connection ......... 6

Care and Cleaning...........................10

Protecting the Environment ............11

Technical Data .................................11

Before operating the speaker,

please first read the safety

notes and user manual care-

fully. Only in this way, you can ensure

that all functions are used in a safe

and reliable manner. Store the user

manual in a safe place and also be

sure to pass it on to any subsequent

owner.

Original packaging

If you wish to exercise your eight-

week right of return, we ask that you

be absolutely sure to hold on to the

packaging. We can only accept the

return of the speakers WITH THE

ORIGINAL PACKAGING.

Empty boxes are not available!

3• Ultima 40 C

Contact

Please contact our customer service

with any questions, suggestions or

criticism:

Lautsprecher Teufel GmbH

BIKINI Berlin

Budapester Str. 44

10787 Berlin (Germany)

Phone 00800 - 200 300 40 (toll-free)

Fax: +49 (0)30 / 300 930 930

Service:

www.teufelaudio.com/service

Contact:

www.teufelaudio.com/contact

Complaints

In case of a complaint we will need

the following information to process

your enquiry:

1. Invoice number

Can be found on the sales slip

(enclosed with the product) or on the

order confirmation received as a PDF

document, e.g. 4322543

2. Serial number or batch number

Located on the back side of

the device, e.g. serial no.:

KB20240129A-123.

Thank you for your support!

For Your Safety

Proper use

The center speaker is designed for

the playback of audio signals that are

transmitted by an external amplifier

via a speaker cable.

Only use the speaker as described

in this user manual. Any other use

will be deemed as not in accordance

with the instructions and may lead to

damage of property or even persons.

The manufacturer accepts no liability

for damage caused by improper use.

The center speaker is intended for

private use only.

4• Ultima 40 C

An unsuitable setup location may

result in injury and damage.

–If the speaker is not securely

mounted, do not use it in vehicles,

in unstable locations, on wobbly

tripods or furniture, on under-

dimensioned brackets etc. The

speaker may fall down and cause

injury to persons or be damaged

itself.

–Place the speaker in such a way

that it cannot be knocked down

inadvertently and make sure that

the cable does not pose a tripping

hazard.

–Make sure that the wall mounting

is done in a professional manner.

–In case of a wall mounting, verify

the carrying capacity of the walls

and make sure that there are

no cables or pipes in the drilling

areas. Before you drill, use a metal

detector to check the applicable

areas. Otherwise, there is a risk of

electric shock/short circuit!

–Do not place the speaker near heat

sources (e.g. heaters, ovens, other

heat generating equipment such as

amplifiers etc.).

Children can become trapped in

the plastic wrapping when playing

and suffocate.

–Do not allow children to play with

the device or the plastic wrapping.

There is a danger of suffocation.

–Ensure that children do not remove

small parts from the device or take

them off of the device (e.g. control

Explanation of terms

You can find the following signal

terms in this user manual:

WARNING

This signal term indicates a

moderate risk, which, if not

avoided, may result in death

or severe injury.

CAUTION

This signal term indicates a

low risk, which, if not avoided,

may result in minor or

moderate injury.

NOTICE

This signal term warns you of

potential damage.

Safety notes

This chapter contains general safety

notes which you should always

observe to protect yourself and third

parties. Also observe the warning

notes in each chapter of this user

manual.

5• Ultima 40 C

knobs or plug adapters). They

could swallow the parts and choke.

Extended listening at high volumes

may lead to hearing loss.

To avoid damage to health, avoid

extended listening at high volumes.

–When the volume is set high,

always keep a certain distance and

never hold your ears directly on the

speaker.

–If an amplifier is set to full volume,

this may produce very high sound

pressure. This may have psycho-

logical consequences and also

cause physical injury. Children and

pets are particularly at risk. Set the

volume control of your amplifier to

a low setting before you turn it on.

This product contains magnetic

material.

–If necessary, consult your physician

and ask for effects on implants such

as pacemakers or defibrillators.

If the speaker is subjected to warm

temperatures after being cold (e.g.

after transport), condensation may

occur inside of it.

–In this case, wait at least 2 hours

before you connect and activate

the speaker.

Improper handling of the speaker

may result in damage or fire.

–Do not place open fire sources

such as burning candles or similar

on the speaker.

–Ensure sufficient ventilation.

–Do not expose the speaker to

direct sunlight.

–Only use the speaker in indoor areas.

–Do not use the speaker in wet

rooms and protect it against drip-

ping or spraying water. Make sure

that no vases or other liquid-filled

objects are located on or near the

device in order to prevent liquid

from penetrating the housing.

The isolation pads can produce

discolouration on sensitive

surfaces.

–On parquet, varnished wood and

similar surfaces, you should stick

felt gliders to the rubber feet of the

speaker or put blankets or small

carpets under it. This will prevent

discolouration of the floor over the

long term.

If the amplifier is underdimen-

sioned, it may end up in clipping

operation at high volumes, which

could destroy the high-range

speakers.

–Only connect your speakers to

amplifiers, which suit the output of

your speakers.

An overdimensioned amplifier can

destroy the bass speaker due to

excessive volume.

–If the music playback sounds

distorted, reduce the volume.

6• Ultima 40 C

Unpacking

• Carefully open the boxes, take out

the EPE foam parts and carefully

lift the speaker out of the box

without touching the diaphragms.

Due to differing customer

requirements, the Ultima 40

series is shipped without any speaker

cables. You can find suitable cables

in our webshop (www.teufelaudio.com)

n the “Accessories” area.

NOTICE

–Check that all items have been

delivered and that nothing is

damaged. If you find any damage,

do not operate the device; instead

contact our customer service

department.

Setup

Our website contains compre-

hensive notes for correct setup.

Location tips

– Select a stable, level base.

– Make sure that the environment is

clean and free from dust.

– Select a location away from heat

sources and direct sunlight.

– Lay the connector cord so that it

does not pose a tripping hazard.

– Do not place any heavy objects on

the cord or the speaker.

Unpacking, Setup, Connection

– Place the center speaker in a

central position under or above the

video screen or screen.

– It should be set up about 20 centi-

metres behind the front speakers.

– If you can only place the center

speaker in line with the front

speakers, you should activate

the delay for the center channel

(“Center Delay”) – providing that

your AV receiver has this option.

Many modern AV receivers and

amplifiers do not offer this kind

of function, but automatically set

this delay to a correct value when

looking up the distances from the

listening position to the speakers

of the Dolby Surround system in

the installation menu.

If you would like to set the speaker

up, attach the 4 enclosed rubber feet

to the corners of the speaker base.

As a result, interference due to vibra-

tions is avoided.

7• Ultima 40 C

• Hang the center speaker on the

wall using the keyhole openings

and the previously mounted

screws.

• These openings are also suitable

for mounting the speaker to a wall

bracket.

Alternatively, you can use the

threaded hole on the bottom of

the speaker. When delivered, the

threaded hole contains a screw

that must be removed before

installation.

You will find suitable speaker

stands and wall brackets in our

webshop (www.teufelaudio.com) in

the “Accessories” area.

NOTICE

The isolation pads can produce

discolouration on sensitive

surfaces.

–On parquet, varnished wood and

similar surfaces, you should stick

felt gliders to the rubber feet of the

speaker or put blankets or small

carpets under it. This will prevent

discolouration of the floor over the

long term.

Wall mounting

CAUTION

Improper mounting may cause

damage.

–Make sure that wall

mounting is done in a profes-

sional manner.

–Before drilling the holes, use

a metal detector to ensure

that there are no electrical

cables or pipes in the wall

within the drilling area.

–Use only suitable screws

and dowels for fixing. Verify

the carrying capacity of the

walls.

8• Ultima 40 C

NOTICE

Make sure the polarity is

correct!

–Connect each of the like

coloured terminals of your

speaker and your amplifier

with one another; other-

wise the sound quality will

suffer. To facilitate this, the

individual single wires of the

speaker cables are marked

with different colours or

shapes.

3. Split the single wire down by

approx. 30 mm on both ends and

remove approx. 10 mm of insula-

tion each.

4. Twist the stripped wire ends so

that no strands are protruding. Tin

coating is not necessary.

5. Turn the connector terminal coun-

terclockwise until loose. Run the

stripped cable end into the now

visible hole. Close the terminal by

turning it counter-clockwise. The

cable has now been clamped in

place.

Connecting

CAUTION

Risk of tripping!

–Lay the cables so that

they do not pose a tripping

hazard.

1. Switch your AV receiver or multi-

channel active subwoofer off.

2. Lay a speaker cable from your AV

receiver or multi-channel active

subwoofer to the speaker. Use a

high-quality double wire speaker

cable with marked strands for this.

The cross-section should amount

to at least 1.5 .

Use the connection terminal with

the two clamps on the back of the

speaker to connect the speaker

cables.

The terminals are each marked red

(+) and black (-).

9• Ultima 40 C

6. Connect the speaker cable to your

AV receiver or multi-channel active

subwoofer. You should be able to

find corresponding notes in the

user manual of your device.

Removing the protective

grid

You can remove the protective grid

by carefully reaching behind it and

slowly pulling it off to the front.

By removing the protective grid,

especially high frequencies will sound

clearer.

When putting the protective grid on,

please make sure that the installa-

tion pins slide directly into the corre-

sponding jacks on the speaker.

Crossover frequency

We recommend a crossover

frequency of 80–100 Hz. Where

possible, set your AV receiver or

DecoderStation as close as possible

to this value.

Operation in full-range mode is also

possible (all speakers set to “Large”).

However, the maximum volume is

slightly lower in this case.

10 • Ultima 40 C

Care and Cleaning

The veneered surfaces of our

speakers have a protective surface

coat so they no wood polish is neces-

sary.

NOTICE

External influences may

damage or destroy the device.

–If possible, only use plain

water without any additives.

In case of stubborn marks,

a mild soap solution may be

used.

–Do not use caustic cleaning

products, white spirit,

thinners, petrol or similar

under any circumstances.

Such cleaning agents may

damage the delicate surface

of the housing.

• Ideally, you should remove dust or

small amounts of dirt with a dry,

smooth leather cloth.

• Rub off stubborn dirt with a damp

cloth. Make sure that no liquid

penetrates the speakers.

• Then immediately wipe the

surfaces dry with a soft cloth

without applying pressure.

Inhaltsverzeichnis

Andere Teufel Sprecher Handbücher

Teufel

Teufel L 430 Stücklistenhandbuch

Teufel

Teufel ULTIMA 40 ACTIVE NG Stücklistenhandbuch

Teufel

Teufel Motiv Go Stücklistenhandbuch

Teufel

Teufel One M Bedienungsanleitung

Teufel

Teufel MOTIV HOME Stücklistenhandbuch

Teufel

Teufel ULTIMA 25 AKTIV Stücklistenhandbuch

Teufel

Teufel THEATER 500S Stücklistenhandbuch

Teufel

Teufel cinebar 21 Handbuch

Teufel

Teufel Cinebar Duett Stücklistenhandbuch

Teufel

Teufel iTeufel Air Blue Handbuch

Teufel

Teufel L 220 FR Bedienungsanleitung

Teufel

Teufel CS 25 Mk3 Handbuch

Teufel

Teufel cinebar 21 mk2 Handbuch

Teufel

Teufel LT 6 THX Select Bedienungsanleitung

Teufel

Teufel T 530 C Stücklistenhandbuch

Teufel

Teufel Definion 5S Handbuch

Teufel

Teufel Definion 3S Handbuch

Teufel

Teufel T 500 Mk 2 Bedienungsanleitung

Teufel

Teufel Motiv B Handbuch

Teufel

Teufel Cinebar 52 THX Handbuch

Teufel

Teufel H 600 CF Bedienungsanleitung

Teufel

Teufel ROCKSTER Gebrauchs- und Pflegehandbuch

Teufel

Teufel ROCKSTER CROSS Bedienungsanleitung

Teufel

Teufel CL 302 C Handbuch

Beliebte Sprecher Handbücher anderer Marken

argon audio

argon audio IE20 Bedienungsanleitung

Denon

Denon SC-N7 Bedienungsanleitung

Gemline

Gemline Ace 3952 Bedienungsanleitung

Focal

Focal ON WALL 300 Bedienungsanleitung

HEADRUSH

HEADRUSH Maximus HRSP 5024 Bedienungsanleitung

SoundLogic

SoundLogic BCCS-6/6395 Bedienungsanleitung

Peavey

Peavey DTH 218 Bedienungsanleitung

Avantree

Avantree Pluto Air Bedienungsanleitung

Morel

Morel Integra Series INTEGRA OVATION 4 Bedienungsanleitung

Oppo

Oppo SONICA Bedienungsanleitung

Bose

Bose SoundLink Wireless Music System Bedienungsanleitung

Rocksteady

Rocksteady Stadium Bedienungsanleitung

Bowers & Wilkins

Bowers & Wilkins 4 Bedienungsanleitung

Sonance

Sonance SONOS OUTDOOR Series Bedienungsanleitung

Electro-Voice

Electro-Voice EVID FM4.2 Bedienungsanleitung

Pioneer

Pioneer XW-HTD630 Bedienungsanleitung

Onn

Onn BWA16AA002 Bedienungsanleitung

HP GL313AA - USB Speakers PC Multimedia Bedienungsanleitung
