CC3100 SimpleLink™ Wi-Fi®and IoT Solution
Getting Started Guide
User's Guide
Literature Number: SWRU375D
June 2014–Revised May 2018
2SWRU375D–June 2014–Revised May 2018
Submit Documentation Feedback
Copyright © 2014–2018, Texas Instruments Incorporated
Table of Contents
Contents
1 Trademarks......................................................................................................................... 4
2 Introduction......................................................................................................................... 4
2.1 Prerequisites.............................................................................................................. 4
3 Getting Started .................................................................................................................... 4
3.1 Download and Install Software......................................................................................... 4
3.2 Update Service Pack .................................................................................................... 4
4 Getting Started with SimpleLink Studio .................................................................................. 5
4.1 Configure Boards......................................................................................................... 5
4.2 Run the Software......................................................................................................... 8
5 Getting Started with the MSP430F5529.................................................................................. 13
5.1 Configure Boards ....................................................................................................... 13
5.2 Run the Software ....................................................................................................... 15
6 Summary........................................................................................................................... 20
7 Acronyms Used.................................................................................................................. 20
Revision History.......................................................................................................................... 21
www.ti.com
3
SWRU375D–June 2014–Revised May 2018
Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated
List of Figures
List of Figures
1 CC3100BOOST.............................................................................................................. 5
2 CC31XXEMUBOOST ....................................................................................................... 6
3 Connect the CC3100BOOST to the CC31XXEMUBOOST ............................................................ 7
4 Device Manager.............................................................................................................. 8
5 MinGW Installation Screen ................................................................................................. 9
6 Import Existing Code....................................................................................................... 10
7 Paths and Symbols ........................................................................................................ 11
8 Eclipse Output Console ................................................................................................... 11
9 CC3100BOOST ............................................................................................................ 13
10 Jumpers on the MSP430F5529 Launchpad ............................................................................ 14
11 Connect the CC3100BOOST to the MSP430F5529 Launchpad .................................................... 15
12 Select CCS Projects to Import............................................................................................ 16
13 Define SSID_Name ........................................................................................................ 17
14 Launch Tera Term ......................................................................................................... 17
15 Tera Term VT............................................................................................................... 18
16 Macro Definition of SSID_Name ......................................................................................... 18
17 Launch Tera Term ......................................................................................................... 19
18 Tera Term VT............................................................................................................... 19
4SWRU375D–June 2014–Revised May 2018
Submit Documentation Feedback
Copyright © 2014–2018, Texas Instruments Incorporated
CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide
User's Guide
SWRU375D–June 2014–Revised May 2018
CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting
Started Guide
ABSTRACT
This guide is intended to assist users in the initial setup and demonstration of the Getting Started with
WLAN Station application. The guide explains how to install an Integrated Development Environment
(IDE), and then compile, download, and debug Getting Started with WLAN Station.
1 Trademarks
SimpleLink is a trademark of Texas Instruments.
Microsoft, Windows are registered trademarks of Microsoft.
Wi-Fi is a registered trademark of Wi-Fi Alliance.
2 Introduction
2.1 Prerequisites
The user should have the following items:
• One CC3100BOOST
• One CC31XXEMUBOOST or MSP430F5529 Launchpad
• An 802.11b/g/n Wireless Access Point (AP)
• A computer running Microsoft®Windows®7 or XP operating systems.
3 Getting Started
3.1 Download and Install Software
Download and install the following software:
• CC3100 SDK package http://www.ti.com/tool/cc3100sdk
– This guide assumes the use of the default installation folder C:\TI\CC3100SDK_<x.x.x>\. .
3.2 Update Service Pack
If the board is not already flashed with the service pack for SDK_<x.x.x>, the latest service pack for
SDK_<x.x.x> must be flashed on the CC3100. The latest service pack can be downloaded from
http://www.ti.com/tool/cc3100sdk. Refer to the UNIFLASH Quick Start guide for details on flashing the
service pack to the CC3100
(http://processors.wiki.ti.com/index.php/CC31xx_%26_CC32xx_UniFlash#Service_Pack_Programming).
Details on setting up the hardware for flashing can be found in Section 4.1 .
www.ti.com
Getting Started with SimpleLink Studio
5
SWRU375D–June 2014–Revised May 2018
Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated
CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide
4 Getting Started with SimpleLink Studio
4.1 Configure Boards
1. The jumpers on the CC3100BOOST should be connected as shown in Figure 1.
Figure 1. CC3100BOOST
Getting Started with SimpleLink Studio
www.ti.com
6SWRU375D–June 2014–Revised May 2018
Submit Documentation Feedback
Copyright © 2014–2018, Texas Instruments Incorporated
CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide
2. The jumpers on the CC31XXEMUBOOST should be connected as shown in Figure 2.
Figure 2. CC31XXEMUBOOST
www.ti.com
Getting Started with SimpleLink Studio
7
SWRU375D–June 2014–Revised May 2018
Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated
CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide
3. Connect the CC3100BOOST to the CC31XXEMUBOOST as shown in Figure 3.
Figure 3. Connect the CC3100BOOST to the CC31XXEMUBOOST
4. Connect the J6 port CC31XXEMUBOOST to the PC using the provided micro-USB cable.
5. The CC3100BOOST is now visible in the Device Manager as shown in Figure 4. The user may see
two COM ports instead of four.
Getting Started with SimpleLink Studio
www.ti.com
8SWRU375D–June 2014–Revised May 2018
Submit Documentation Feedback
Copyright © 2014–2018, Texas Instruments Incorporated
CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide
Figure 4. Device Manager
4.2 Run the Software
The Getting Started with WLAN Station example uses SimpleLink Studio. This example performs the
following functions:
1. Program restores WLAN configuration to factory default
2. Prompts the user for the SSID of an AP
3. Prompts the user for the security type
4. Prompts the user for the password to the AP
5. Attempts to acquire an IP address through DHCP
6. Attempts to reach the internet
NOTE: For full compatibility ensure Visual Studio 2010 is used. Newer versions of Visual Studio will
not work with the device. Visual Studio 2012 works with the "getting started" example, but
gives the error code -2003 for the weather example, and error code -2005 for the email app.
Option 1. Microsoft Visual Studio:
1. Download and install Microsoft Visual Studio Express 2010 from http://www.visualstudio.com/en-
us/downloads/download-visual-studio-vs#DownloadFamilies_4.
2. Open Microsoft Visual Studio Express, and select File>Open>Project/Solution.
3. Navigate to C:\TI\CC3100SDK_<x.x.x>\cc3100-
sdk\platform\simplelinkstudio\example_project_vs\getting_started_with_station , and open
getting_started.sln.
4. Select Build>Build Solution from the menu.
5. When building is complete, select Debug>Start Debugging from the menu.
www.ti.com
Getting Started with SimpleLink Studio
9
SWRU375D–June 2014–Revised May 2018
Submit Documentation Feedback Copyright © 2014–2018, Texas Instruments Incorporated
CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide
Option 2. Eclipse:
1. Download and install the latest version of Java: https://www.java.com/en/download/. Install the correct
version for the system (64-bit or 32-bit).
2. Download and extract Eclipse from http://www.eclipse.org/downloads/. Choose the Eclipse IDE for
C/C++ Developers package. Install the correct version for the system (64-bit or 32-bit).
3. Download and install MinGW from
http://sourceforge.net/projects/mingw/files/latest/download?source=files. During installation, ensure the
following configurations are selected:
a. Set the installation location as C:\MinGW.
b. In the MinGW Installation Screen, select packages for mingw32-base and mingw32-gcc-g++ as
shown in Figure 5.
Figure 5. MinGW Installation Screen
c. After selecting the packages, choose Installation>Apply Changes from the menu, then press Apply.
d. Select Installation>Quit from the menu to quit the installer.
4. After a successful MinGW installation, add the path (c:\MinGW\bin\) to the Windows environment
variable path by going into Control Panel>System>Advanced System Settings>Environment Variables.
Under System Variables, select PATH and press Edit. Append “;C:\MinGW\bin\” to the end of the line
and press Ok.
5. Open Eclipse by running eclipse.exe from the extracted Eclipse folder.
6. In the "Select a workspace," choose your desired workspace directory (for example:
C:\Users\myself\Desktop\eclipse_workspace). This directory should be different from the user's other
versions of Eclipse.
7. From the menu, select File>New>Makefile Project with Existing Code.
8. Enter ‘Getting_started’ as the project name.
9. For Existing Code Location, enter C:\TI\CC3100SDK_<x.x.x.>\cc3100-
sdk\platform\simplelinkstudio\example_project_eclipse\getting_started_with_station .
10. For Toolchain for indexer settings, choose “MinGW GCC” as shown in Figure 6.
Getting Started with SimpleLink Studio
www.ti.com
10 SWRU375D–June 2014–Revised May 2018
Submit Documentation Feedback
Copyright © 2014–2018, Texas Instruments Incorporated
CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide
Figure 6. Import Existing Code
11. Press Finish.
12. Select Window>Show View>Project Explorer from the menu.
13. Select the Getting_started project in the Project Explorer, and select File>Properties from the menu.
14. In the Project Explorer window, right click on <Project_Folder_Name>, then select Property.
15. Expand the C/C++ Build menu, and select Tool Chain Editor. Under Current Builder, Select "Gnu
Make Builder", then click Apply.
16. Click the C/C++ Build menu and do the following:
a. Uncheck 'Use the default build command.'
b. Type mingw32-make -f Makefile in the Build command.
c. Uncheck 'Generate Makefiles automatically.'
d. Set the Build Directory as: ${workspace_loc:/Getting_started}
17. Select Environment in the C/C++ Build menu. Ensure the value of MSYS_HOME is empty, then click
Apply.
18. Click the C/C++ General menu, and select Paths and Symbols. Under the Includes tab, in the
Andere Handbücher für CC3100 SimpleLink
2
Inhaltsverzeichnis
Andere Texas Instruments Mikrocontroller Handbücher
Texas Instruments
Texas Instruments TMS570LC4357 Produkthandbuch
Texas Instruments
Texas Instruments BQ769142 Bedienungsanleitung
Texas Instruments
Texas Instruments Errata MSP430F6746 Bedienungsanleitung
Texas Instruments
Texas Instruments TMS570LS0 32 Series Bedienungsanleitung
Texas Instruments
Texas Instruments Piccolo F280049 Bedienungsanleitung
Texas Instruments
Texas Instruments LaunchPad MSP430FR4133 Bedienungsanleitung
Texas Instruments
Texas Instruments TMS570 Bedienungsanleitung
Texas Instruments
Texas Instruments MSPM0G310 Series Bedienungsanleitung
Texas Instruments
Texas Instruments DV2031S2 Bedienungsanleitung
Texas Instruments
Texas Instruments MSP430F6766 Bedienungsanleitung
Texas Instruments
Texas Instruments TI-InnovatorHub Bedienungsanleitung
Texas Instruments
Texas Instruments AM5728 Bedienungsanleitung
Texas Instruments
Texas Instruments LaunchPad LP-EM-CC2340R5 Bedienungsanleitung
Texas Instruments
Texas Instruments CC2543EM Bedienungsanleitung
Texas Instruments
Texas Instruments CC3220 Bedienungsanleitung
Texas Instruments
Texas Instruments MSP430F67461 Bedienungsanleitung
Texas Instruments
Texas Instruments CC-6LOWPAN-DK-868 Bedienungsanleitung
Texas Instruments
Texas Instruments 430BOOST-TMP006 BoosterPack Bedienungsanleitung
Texas Instruments
Texas Instruments MSP430F6735 Bedienungsanleitung
Texas Instruments
Texas Instruments MSP430C311S Bedienungsanleitung
Beliebte Mikrocontroller Handbücher anderer Marken
AMS
AMS AS7261 Demo Kit Bedienungsanleitung
Novatek
Novatek NT6861 Bedienungsanleitung
Espressif Systems
Espressif Systems ESP8266 SDK Einrichtungshandbuch
Nuvoton
Nuvoton ISD61S00 ChipCorder Leitfaden
STMicrolectronics
STMicrolectronics ST7 Assembler Linker Bedienungsanleitung
Lantronix
Lantronix Intrinsyc Open-Q 865XR SOM Bedienungsanleitung
NEC
NEC 78GK0S/K 1+ Series Montage- und Bedienungsanleitung
Mikroe
Mikroe SEMITECH N-PLC Click Montage- und Bedienungsanleitung
Intel
Intel Agilex Bedienungsanleitung
Cypress
Cypress CY4607 HX2VL Bedienungsanleitung
DIGITAL-LOGIC
DIGITAL-LOGIC MICROSPACE Bedienungsanleitung
CYPRES
CYPRES CY14NVSRAMKIT-001 Bedienungsanleitung
Espressif Systems
Espressif Systems ESP8266EX Betriebsanleitung
Abov
Abov AC33M8128L Bedienungsanleitung
Laird
Laird BL654PA Bedienungsanleitung
Silicon Laboratories
Silicon Laboratories C8051F800 Bedienungsanleitung
Energy micro
Energy micro EFM32 Giant Gecko Starter Kit Bedienungsanleitung
Mikroe
Mikroe click Proximity 2 Bedienungsanleitung
