Preface

Read This First

About This Manual

This user’s guide provides the information needed to set up and operate the

AFE8201EVM evaluation module. For a more detailed description of the

AFE8201, please refer to the product data sheet available from the Texas In-

struments web site at http://www.ti.com. Additional support documents are

listed in the sections of this guide entitled Related Documentation from Texas

Instruments.

How to Use This Manual

Throughout this document, the acronym EVM and the phrase evaluation

module are synonymous with the AFE8201EVM.

Information About Cautions

This book contains cautions.

This is an example of a caution statement.

A caution statement describes a situation that could potentially

damage your software or equipment.

The information in a caution or a warning is provided for your protection.

Please read each caution carefully.

Contents

Related Documentation From Texas Instruments

The following documents provide information regarding Texas Instrument inte-

grated circuits used in the assembly of the AFE8201EVM. These documents

are available from the TI web site. The last character of the literature number

corresponds to the document revision, which is current at the time of the writing

of this user’s guide. Newer revisions may be available from the TI web site at

http://www.ti.com or by calling the Texas Instruments Literature Response

Center at (800) 477−8924 or the Product Information Center at (972)

644−5580. When ordering, identify the document(s) by both title and literature

number.

Data Sheets: Literature Number:

AFE8201 SBWS016

If You Need Assistance

If you have questions regarding either the use of this evaluation module or the

information contained in the accompanying documentation, please contact

the Texas Instruments Product Information Center at (972) 644−5580 or visit

the TI Semiconductor Online Technical Support pages at http://www.ti.com.

FCC Warning

This equipment is intended for use in a laboratory test environment only. It may

generate, use, or radiate radio frequency energy and has not been tested for

compliance with the limits of computing devices pursuant to sub−part J of part

15 of the FCC regulations, which are designed to provide reasonable protec-

tion against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

Trademarks

All trademarks are the property of their respective owners.

AFE8201EVM

The AFE8201EVM is designed to assist with evaluating the performance of

the AFE8201 analog-to-digital converter (ADC) with digital downconverter.

Topic Page

1 Overview 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Purpose 2

EVM Basic Functions 2

Power Requirements 2

Operational Procedure 3

2 Circuit Description 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Analog Inputs 4

Clock Inputs 4

Serial Interface 4

Outputs 4

3 Software Description 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Xilinx FPGA Software 5

Visual Basic Software 5

4 Physical Description 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Schematic, PCB Layout, and Bill of Materials 6

Overview

1 Overview

This user’s guide gives a general overview of the AFE8201 evaluation module

(EVM), and provides a general description of the feature and functions to be

considered while using this module.

1.1 Purpose

The AFE8201EVM is a platform for evaluating the AFE8201 ADC with digital

downconverter under various signal, reference, and supply conditions. This

document should be used in combination with the EVM schematic diagrams

(see Figure 1, Figure 2, and Figure 3) and the supplied USB interface drive

software.

1.2 EVM Basic Functions

Analog input to the AFE is provided via external SMA connectors. The single-

ended input is converted into a differential signal at the input of the device. The

input path is transformer-coupled.

The EVM provides one external SMA connector for converting the single-

ended input to a differential AFE clock signal at the input of the device.

Digital outputs from the EVM are via two 40-pin connectors and two DSK

peripheral 80-pin connectors.

The AFE internal registers can be programmed using the onboard USB inter-

face module through a PC.

Power connections to the EVM are made through either a 5V DC supply, or

3.3V and 1.8V supplies.

1.3 Power Requirements

The EVM can be powered in one of two ways:

1) The EVM can be powered directly with a +5V supply if using the AC/DC

(+90V to +265V AC input/+5V DC output adaptor) module; or

2) The EVM can be powered by lab power from +5V analog, 3.3V analog,

3.3V digital, and 1.8V digital supplies.

Voltage Limits

Exceeding the maximum input voltages can damage EVM

components. Undervoltage may cause improper operation of some

or all of the EVM components.

Operational Procedure

AFE8201EVM

1.4 Operational Procedure

The AFE8201EVM provides a flexible means of evaluating the AFE8201 in a

number of modes of operation. The following basic setup procedure can be

used as a board confidence check.

1) Verify all jumper settings against the jumper lists in Table 1, Table 2, and

Table 3.

Table 1. Pin Jumper List Table

Jumper Function Installed Default

JP1 GSET of Test DAC Yes 3.3V Analog

JP2 AC/DC or Lab 5V DC

Voltage Supply Switch Yes Lab 5V DC

JP3 Digital Input Voltage:

Lab 5V DC/3.3V Yes Lab 5V DC

JP4 3.3V Digital Supply Operation:

Lab 3.3V/Regulator 3.3V Yes Lab 3.3V

JP5 1.8V Digital Supply Operation:

Lab 1.8V/Regulator 1.8V Yes Lab 1.8V

JP6 3.3V Analog Supply Operation:

Lab 3.3V/Regulator 3.3V Yes Lab 3.3V

Table 2. Jumper and Push Button Switch List Table

Jumper Function Default

S1 FGPA Reset Open

S3 Program Reset Open

JP7 Aux DAC Output Open

Table 3. Relay List Table

Jumper Function

K1A DSK Connector Option to SCK

K2A DSK Connector Option to MOSI

K3A DSK Connector Option: MISO or DOUT1

2) Connect supplies to the EVM in the following manner:

-+5V AC/DC Supply to JP2

-+5V Lab Supply to P6

-+3.3V Analog Supply to P8

-+3.3V/1.8V Lab Supply to P7

Circuit Description

2 Circuit Description

The schematic diagrams for the EVM are located at the end of this document

(see Figure 1, Figure 2, and Figure 3).

2.1 Analog Inputs

The EVM can be configured to provide the AFE with transformer-coupled in-

puts from a single-ended source. The inputs are provided via SMA connectors

(J6) for a transformer-coupled input.

2.2 Clock Inputs

The initial configuration of the EVM provides a transformer-coupled clock input

(J8) to the AFE differential clock.

2.3 Serial Interface

The EVM has a USB interface input through FPGA to control a serial bus to

operate of the registers of the AFE.

2.4 Outputs

The data outputs from the AFE have two possible connection options: two

40-pin connectors (P3 and P4), or two DSK 80-pin connectors (P1 and P5).

-40-pin connector output pins:

JI Output: on connector P3 (Digital Interface 1), from pin 4 (LSB) to pin

34 (MSB), even pins only (odd pins are ground).

JQ output: on connector P4 (Digital Interface 2), from pin 2 (LSB) to pin

32 (MSB), even pins only (odd pins are ground).

JStrobe: On connector P3, pin 2 (sample I and Q data on falling edge of

strobe)

-80-pin connector output pins:

JSee schematic diagrams shown in Figure 1, Figure 2, and Figure 3.

Inhaltsverzeichnis

Andere Texas Instruments Hauptplatine Handbücher

Texas Instruments

Texas Instruments SWIFT TPS561201EVM-896 1-A Bedienungsanleitung

Texas Instruments

Texas Instruments ADS528 Series Bedienungsanleitung

Texas Instruments

Texas Instruments TPS53127EVM-614 Bedienungsanleitung

Texas Instruments

Texas Instruments DLPLCRC964 Bedienungsanleitung

Texas Instruments

Texas Instruments TPS8269 EVM-207 Series Bedienungsanleitung

Texas Instruments

Texas Instruments INA226 Bedienungsanleitung

Texas Instruments

Texas Instruments ADC3 J EVM Series Bedienungsanleitung

Texas Instruments

Texas Instruments TAS3108EVM2 Bedienungsanleitung

Texas Instruments

Texas Instruments SLUU083A Bedienungsanleitung

Texas Instruments

Texas Instruments TPS7A53EVM-080 Bedienungsanleitung

Texas Instruments

Texas Instruments TPS65251 Bedienungsanleitung

Texas Instruments

Texas Instruments TPS54373EVM-237 Bedienungsanleitung

Texas Instruments

Texas Instruments DEM-OPA-MSOP-1B Bedienungsanleitung

Texas Instruments

Texas Instruments TUSB1044 Bedienungsanleitung

Texas Instruments

Texas Instruments TMUX-24PW-EVM Bedienungsanleitung

Texas Instruments

Texas Instruments ADC1 D (RF )RB Series Bedienungsanleitung

Texas Instruments

Texas Instruments AN-1601 LM34917A Bedienungsanleitung

Texas Instruments

Texas Instruments DIYAMP-SOT23-EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPA3220 Bedienungsanleitung

Texas Instruments

Texas Instruments PGA411-Q1 EVM Bedienungsanleitung

Texas Instruments

Texas Instruments LM25085A Bedienungsanleitung

Texas Instruments

Texas Instruments Tiva C Series Bedienungsanleitung

Texas Instruments

Texas Instruments LMX2430 Bedienungsanleitung

Texas Instruments

Texas Instruments Hercules TMS570LS04x/03x Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
