SLAU719–April 2019

TAS5806MDEVM User's Guide

User's Guide

SLAU719–April 2019

TAS5806MDEVM User's Guide

This user’s guide describes the operation of the TAS5806MD Evaluation Module (EVM). The EVM is

connected to the PurePath™ Console Motherboard (PPCMB). The main contents of this document are:

• Hardware descriptions and implementation

Required equipment and accessories:

• TAS5806MDEVM

• PurePath Console Motherboard

• A USB micro type-B cable

• Power supply unit (PSU)

• Speakers and cables

• Desktop or laptop running Microsoft®Windows®7, Windows 8, or Windows 8.1

• Audio source: This can be a DVD player with appropriate SPDIF cable or Playback Media from

Windows 7, Windows 8 or Windows 8.1.

Contents

1 Hardware Overview.......................................................................................................... 2

1.1 Features.............................................................................................................. 2

1.2 Functions............................................................................................................. 3

1.3 Detailed Operations ................................................................................................ 3

2 Hardware Setup.............................................................................................................. 5

2.1 I2C Device Addresses .............................................................................................. 5

3 Troubleshooting.............................................................................................................. 5

3.1 Power Cycle......................................................................................................... 5

4 Board Layouts, Bill of Materials, and Schematic ........................................................................ 6

4.1 Schematics .......................................................................................................... 6

4.2 Board Layouts....................................................................................................... 9

4.3 Bill of Materials .................................................................................................... 11

Trademarks

PurePath is a trademark of Texas Instruments.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

All other trademarks are the property of their respective owners.

Hardware Overview

www.ti.com

2SLAU719–April 2019

Submit Documentation Feedback

TAS5806MDEVM User's Guide

1 Hardware Overview

The TAS5806MDEVM showcases the latest TI digital input Class-D closed-loop amplifier. The

TAS5806MD is a digital input Class-D audio amplifier with enhanced processing and an integrated

headphone driver. The EVM is used in conjunction with the PurePath Console Motherboard (PPCMB).

The PVDD supply is provided via the TAS5806MDEVM (Figure 1) and is regulated to 5 VDC and 3.3 VDC

on the PPCMB. The PPCMB provides the I2S, I2C, and 3.3 VDC to the TAS5806MDEVM.

Figure 1. TAS5806MDEVM

1.1 Features

The EVM has the following features:

• 96-kHz input sample rate support

• 2.0, mono and 2.1 capable

• Operates in BTL or PBTL

• PurePath Console Motherboard provides flexible input signal routing (USB, SPDIF, and analog)

• Demonstration, evaluation and development environment via the PurePath Console 3 software (GUI)

www.ti.com

Hardware Overview

SLAU719–April 2019

TAS5806MDEVM User's Guide

1.2 Functions

The TAS5806MDEVM is controlled by the PPCMB. The digital audio data input to the TAS5806MDEVM is

sent from PPCMB and is selectable from USB audio, optical SPDIF, coaxial SPDIF, PSIA (external I2S)

and analog ADC sources.

1.3 Detailed Operations

Upon power-on, the PPCMB uses USB audio input (default). The I2S signals LRCLK, SCLK, SDIN and

MCLK come from the TAS1020B.

foobar2000 or similar non-processing media source can be used to stream audio. The TAS1020B

enumerates as the following device on a Microsoft Windows operating system (OS): USB audio (USB-

AudioEVM), i, and USB Composite Device, see Figure 2.

Figure 2. Device Manager

Hardware Overview

www.ti.com

4SLAU719–April 2019

Submit Documentation Feedback

TAS5806MDEVM User's Guide

USB audio output quality can be configured as shown in Figure 3. Users must select "2 channel, 16 bit,

48000 Hz (DVD Quality)".

Figure 3. Default Format

www.ti.com

Hardware Setup

SLAU719–April 2019

TAS5806MDEVM User's Guide

2 Hardware Setup

Use the following steps when setting up the hardware:

Step 1. Connect the PPCMB to the TAS5806MDEVM.

Step 2. Connect speakers to the TAS5806MDEVM.

Step 3. Connect a PSU to the TAS5806MDEVM and turn on the power. 5-V and 3.3-V LEDs (Yellow)

are illuminated. The USB Lock LED (Blue) is also illuminated.

Step 4. Plug in a USB cable from the PC to the PPCMB.

Step 5. If an optical SPDIF source is used, the blue SPDIF clock-locked LED is illuminated.

2.1 I2C Device Addresses

The default I2C addresses on the EVM are set to 0x58 for the top device (U1) and 0x5A for the bottom

one (U2).

3 Troubleshooting

3.1 Power Cycle

To perform a power cycle, disconnect both the USB cable and the power supply from the board.

GND

OUTA1+

OUTA1-

OUTB1+

OUTB1-

GND GND GND

OUT_A1+

OUT_B1-

OUT_A1-

OUT_B1+

GND GND GND

BST_A1+

GND

4.7uF

C10

0.1uF

C20

GND GND

1uF

C21

1uF

C16GND

BST_A1-

BST_B1+

BST_B1-

SDOUT1

TO CONTROLLER

SDOUT1

OUT1A

OUT1B

PVDD1 PVDD1

4.70k

PDN1

SCLK

SCL

SDA

SCL

LRCLK

SCLK

SDIN1

ADR/FAULT1

PDN1

LRCLK

SDA

SDIN1

ADR/FAULT1

TP1

ADR/FAULT1

TP2

PDN1

FROM

0.1uF

C11

GND GND

1uF

C14

GND

1uF

C23

1uF

C22

1 2

DVDD1

PVDD1

PVDD1VIN

3.3V DVDD1 DVDD1

DVDD1

ADR/FAULT

AVDD

DGND 12

DVDD

PAD 39

OUT_A- 2

BST_A+ 4

OUT_A+ 5

BST_A- 1

OUT_B+ 34

OUT_B- 37

BST_B+ 35

BST_B- 38

PGND 3

PGND 36

AGND 31

DGND 8

PVDD

VR_DIG

SDIN

15 SCLK

14 LRCLK

SDA

SCL

PDN

SDOUT 26

NC 24

HP_GND 16

HPVDD

HPR_IN

18 HPL_IN

HPR_OUT 20

HPL_OUT 21

HPVSS 22

CPN 23

CPP 25

TAS5806MDDCPR

CONTROLLER

0.1uF

1000pF

C13

R13

GND

1000pF

C24

1000pF

C25

1000pF

C28

1000pF

C19

R14

GND

1000pF

C26

R15

GND

1000pF

C27

R16

GND

TO CONTROLLER

I2C Address = 0x58

35V

22uF

35V

22uF

35V

22uF

35V

22uF

0.22uF

C12

0.22uF

C17

0.22uF

C15

0.22uF

C18

Board Layouts, Bill of Materials, and Schematic

www.ti.com

6SLAU719–April 2019

Submit Documentation Feedback

TAS5806MDEVM User's Guide

4 Board Layouts, Bill of Materials, and Schematic

This section includes the EVM schematics, board layouts and bill of materials.

4.1 Schematics

Figure 4 to Figure 4 illustrate the schematics for this EVM.

Figure 4. TAS5806MDEVM Schematic (1 of 3)

GND

4.7uH

0.68uF

C29

0.68uF

C38

4.7uH

0.68uF

C52

0.68uF

C41

OUTA2+

OUTA2-

OUTB2+

OUTB2-

GND GND GND

OUT_A2+

OUT_B2-

OUT_A2-

OUT_B2+

GND GND GND

BST_A2+

GND

4.7uF

C39

0.1uF

C40

GND GND

1uF

C46

1uF

C51GND

BST_A2-

BST_B2+

BST_B2-

SDOUT2

TO CONTROLLER

SDOUT2

OUT2A

J12

OUT2B

PVDD2 PVDD2

15.0k

R21

SDA

SCL

LRCLK

SCLK

SDIN2

ADR/FAULT2

PDN2

TP10

ADR/FAULT2

TP11

PDN2

FROM

HPRIN

HPLIN

0.1uF

C50

GND GND

1uF

C49

GND

1uF

C54

1uF

C53

GND

HPL_OUT

HPR_OUT

1 2

J11

DVDD2

PVDD2

PVDD2VIN

3.3V DVDD2 DVDD2

DVDD2

ADR/FAULT

AVDD

DGND 12

DVDD

PAD 39

OUT_A- 2

BST_A+ 4

OUT_A+ 5

BST_A- 1

OUT_B+ 34

OUT_B- 37

BST_B+ 35

BST_B- 38

PGND 3

PGND 36

AGND 31

DGND 8

PVDD

VR_DIG

SDIN

15 SCLK

14 LRCLK

SDA

SCL

PDN

SDOUT 26

NC 24

HP_GND 16

HPVDD

HPR_IN

18 HPL_IN

HPR_OUT 20

HPL_OUT 21

HPVSS 22

CPN 23

CPP 25

TAS5806MDDCPR

CONTROLLER

0.1uF

C32

0.1uF

C33

I2C Address = 0x5A

1000pF

C36

R17

1000pF

C44

R19

GND

1000pF

C37

R18

GND

1000pF

C45

R20

GND1uF

C56

1uF

C57

PDN2

SCLK

SCL

LRCLK

SDA

SDIN2

ADR/FAULT2

HPL_IN

HPR_IN

390uF

C59

GND

390uF

C55

GND

HP OUT

35V

22uF

C30

35V

22uF

C31

35V

22uF

C34

35V

22uF

C35

0.22uF

C42

0.22uF

C47

0.22uF

C43

0.22uF

C48

www.ti.com

Board Layouts, Bill of Materials, and Schematic

SLAU719–April 2019

TAS5806MDEVM User's Guide

Figure 5. TAS5806MDEVM Schematic (2 of 3)

GND GND

SDA-PPCMB_OUT

SCL-PPCMB_OUT

(PPCMB-GPIO8)

VSS

4SDA 5

SCL 6

WP 7

VCC 8

EEPROM_8P

(PPCMB-GPIO3)

GND

3.3V

10.0k

3.3V

10.0k

DNP

3.3V

GND

(PPCMB-GPIO7)

TO DUTs

TO DUT

SCLK

LRCLK

FROM DUT

(PPCMB-GPIO9)

ADR/FAULT1 (PPCMB-GPIO0)

(PPCMB-GPIO1)

GND

0R7

TO DUT

3.3V

2.20k

3.3V

2.20k

SDA-PPCMB_OUT

SCL-PPCMB_OUT

3.3V

Green

D1 3.3V

332

GND

SCLK

LRCLK

SDOUT

3.3V

SDIN1

LRCLK

SCLK

SDOUT

SCL

SDA

GND

SCL

SDA

TP5 SDA

ADR/FAULT1

GND 101

GND 102

GND 103

GND 104

J1A

GND 105

GND 106

GND 107

GND 108

100

J1B

HPRIN

HPLIN

VIN

PVDD RANGE

4.5-26.4VDC

GND

VIN

J10

GND

VIN

PDN1

PDN2

SDOUT2

GND GND

49.9

R11

GND 4

A/B 6

VCC

74LVC2G157DCT

SDOUT1

10.0k

R12

GND

SDOUT2SDOUT

FROM DUT

HPRIN

HPLIN

SDOUT1

SDOUT-SEL

GND

ADR/FAULT2 ADR/FAULT2

TP4 SCL

3.3V

10.0k

R10

10.0k

R22

3.3V 3.3V

10.0k

R23

PDN2

PDN1

GND

10.0k

R24

GND

GND GND

49.9

R25

GND 4

A/B 6

VCC

74LVC2G157DCT

SDIN1

SDIN-SEL

SDIN2

10.0k

R26

TO DUTS

GND

3.3V

SDIN-SEL

3.3V

3.3VSDOUT1

0.1uF

16V

0.1uF

16V

0.1uF

C58

SDOUT-SEL

Board Layouts, Bill of Materials, and Schematic

www.ti.com

8SLAU719–April 2019

Submit Documentation Feedback

TAS5806MDEVM User's Guide

Figure 6. TAS5806MDEVM Schematic (3 of 3)

www.ti.com

Board Layouts, Bill of Materials, and Schematic

SLAU719–April 2019

TAS5806MDEVM User's Guide

4.2 Board Layouts

Figure 7 and Figure 8 illustrate the board layouts for the EVM.

Figure 7. TAS5806MDEVM Top Composite Assembly

Board Layouts, Bill of Materials, and Schematic

www.ti.com

10 SLAU719–April 2019

Submit Documentation Feedback

TAS5806MDEVM User's Guide

Figure 8. TAS5806MDEVM Bottom Composite Assembly

Inhaltsverzeichnis

Andere Texas Instruments Hauptplatine Handbücher

Texas Instruments

Texas Instruments TPA032D01 Bedienungsanleitung

Texas Instruments

Texas Instruments TMS320C6670 Bedienungsanleitung

Texas Instruments

Texas Instruments DAC5686 EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPS2640EVM Bedienungsanleitung

Texas Instruments

Texas Instruments Chipset TRF2436EVM Bedienungsanleitung

Texas Instruments

Texas Instruments BUF20800 Bedienungsanleitung

Texas Instruments

Texas Instruments LMK04826 Bedienungsanleitung

Texas Instruments

Texas Instruments PCM6 0Q1EVM-PDK Series Bedienungsanleitung

Texas Instruments

Texas Instruments TMP451EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPA032D02 Bedienungsanleitung

Texas Instruments

Texas Instruments TAS6424-Q1 Bedienungsanleitung

Texas Instruments

Texas Instruments RF430F5978EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPS65313-Q1 Bedienungsanleitung

Texas Instruments

Texas Instruments LMH1297EVM Bedienungsanleitung

Texas Instruments

Texas Instruments bq27441 EVM Bedienungsanleitung

Texas Instruments

Texas Instruments MSP-US-TRF6901 Bedienungsanleitung

Texas Instruments

Texas Instruments LMR36506MSCEVM Bedienungsanleitung

Texas Instruments

Texas Instruments ADC1 D (RF )RB Series Bedienungsanleitung

Texas Instruments

Texas Instruments AM574 Series Bedienungsanleitung

Texas Instruments

Texas Instruments UCC14131EVM-070 Bedienungsanleitung

Texas Instruments

Texas Instruments TPS65910 EVM Bedienungsanleitung

Texas Instruments

Texas Instruments LMK5C33216EVM Bedienungsanleitung

Texas Instruments

Texas Instruments bq27750EVM Bedienungsanleitung

Texas Instruments

Texas Instruments TPS7A91EVM-831 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
