SN74LVC2G241
SCES210O –APRIL 1999–REVISED DECEMBER 2015
SN74LVC2G241 Dual Buffer and Driver With 3-State Outputs
1 Features 3 Description
This dual buffer and line driver is designed for 1.65-V
1• Available in the Texas Instruments to 5.5-V VCC operation.
NanoFree™ Package The SN74LVC2G241 device is designed specifically
• Supports 5-V VCC Operation to improve both the performance and density of 3-
• Inputs Accept Voltages to 5.5 V state memory-address drivers, clock drivers, and bus-
• Max tpd of 4.1 ns at 3.3 V oriented receivers and transmitters.
• Low Power Consumption, 10-µA Maximum ICC NanoFree package technology is a major
• ±24-mA Output Drive at 3.3 V breakthrough in IC packaging concepts, using the die
as the package.
• Typical VOLP (Output Ground Bounce)
<0.8 V at VCC = 3.3 V, TA= 25°C The SN74LVC2G241 device is organized as two 1-bit
• Typical VOHV (Output VOH Undershoot) line drivers with separate output-enable (1OE, 2OE)
>2 V at VCC = 3.3 V, TA= 25°C inputs. When 1OE is low and 2OE is high, the device
passes data from the A inputs to the Y outputs. When
• Ioff Supports Live Insertion, Partial-Power-Down 1OE is high and 2OE is low, the outputs are in the
Mode, and Back-Drive Protection high-impedance state.
• Can Be Used as a Down Translator to Translate To ensure the high-impedance state during power up
Inputs From a Max of 5.5 V Down or power down, OE should be tied to VCC through a
to the VCC Level pullup resistor, and OE should be tied to GND
• Latch-Up Performance Exceeds 100 mA Per through a pulldown resistor; the minimum value of the
JESD 78, Class II resistor is determined by the current-sinking or the
• ESD Protection Exceeds JESD 22 current-sourcing capability of the driver.
– 2000-V Human-Body Model (A114-A) This device is fully specified for partial-power-down
applications using Ioff. The Ioff circuitry disables the
– 200-V Machine Model (A115-A) outputs, preventing damaging current backflow
– 1000-V Charged-Device Model (C101) through the device when it is powered down.
2 Applications Device Information(1)
• AV Receivers PART NUMBER PACKAGE BODY SIZE (NOM)
• Blu-ray Players and Home Theaters SN74LVC2G241DCT SM8 (8) 2.95 mm × 2.80 mm
• DVD Recorders and Players SN74LVC2G241DCU VSOOP (8) 2.30 mm × 2.00 mm
SN74LVC2G241YZP DSBGA (8) 1.91 mm × 0.91 mm
• Desktop or Notebook PCs
• Digital Radio or Internet Radio Players (1) For all available packages, see the orderable addendum at
the end of the data sheet.
• Digital Video Cameras (DVC)
• Embedded PCs Logic Diagram (Positive Logic)
• GPS: Personal Navigation Devices
• Mobile Internet Devices
• Network Projector Front-Ends
• Portable Media Players
• Pro Audio Mixers
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
