Motion- and
masking-triggered
alarm or tamper
triggering
Lights up red for about one
second
During the alarm, it slowly
lights up green and slowly goes
out
Replacement of the detector battery is
described in the Battery Replacement
paragraph
Functionality Testing
The Ajax security system allows conducting tests for checking the functionality of connected
devices.
The tests do not start straight away but within a period of 36 seconds when using the standard
settings. The test time start depends on the settings of the detector scanning period (the
paragraph on “Jeweller” settings in hub settings).
Signal Strength Test
Detection Zone Test
Attenuation test
According to the requirements of EN50131, the level of the radio signal sent by wireless devices
is reduced during the test mode.
Choosing an installation place
Before installing the device, conduct a signal strength test.
The MotionProtect Outdoor must be located at a height of 0.8 –1.3 m. The detector body is
located in a way that the upper lens axis is parallel to ground level and the supposed path of
intruder entry passes perpendicular to the lens axis.
The MotionProtect Outdoor sends an alarm to the hub only if identical motion signals are
detected with two PIR sensors. In this case, the difference in motion capture time shall not
exceed 1.5 seconds in this case.
It is recommended to check the functioning of the detector at the proposed installation site!
When choosing a location for MotionProtect Outdoor, consider the limited range of the radio
signal.
If the signal level is one division, we cannot guarantee stable operation of the security system.
Take possible measures to improve the quality of the signal! As a minimum, move the device -
even 20 cm shift can significantly improve the quality of reception.
If, after moving, the device still has a low or unstable signal strength, use a radio signal range
extender ReX.
Take care when installing the attachment panel. Excessive force during its fixation can lead to
deformation, and, consequently, to the inability to install the detector or to its unreliable fixation.
Secure the attachment panel only with the bundled mounting tools! Using other fasteners, e.g.
large diameter self-tappers, may damage the attachment panel. It is not recommended to use
