Installation and Operation Manual

Thermo Scientific

General Purpose, Flammable Storage, and

Explosion Proof Freezers

General Purpose, Flammable Material Storage

and

Explosion Proof Freezers

Explosion-Proof

05EFEETSA Flammable Material Storage

05FFEETSA General Purpose

05LFEETSA

02LREETSA

Table of Contents

Safety Information ...............................................................................................................................................................3

AlertSignals .....................................................................................................................................................................3

Explosion-Proof Refrigerators and Freezers.......................................................................................................................5

Overview..........................................................................................................................................................................5

MODEL 05EFEETSA ......................................................................................................................................................6

Flammable Materials StorageRefrigerators and Freezers....................................................................................................7

Overview..........................................................................................................................................................................7

MODEL 05FFEETSA......................................................................................................................................................8

Unpacking and Installation ..............................................................................................................................................12

Shipping Carton............................................................................................................................................................12

Unpacking.....................................................................................................................................................................12

Location ........................................................................................................................................................................12

Clearance......................................................................................................................................................................12

Electrical .......................................................................................................................................................................13

Be Advised....................................................................................................................................................................13

How to Seal Killark® Box Conduit with Fiber and Sealing Compound to Help Protect Against Explosions

(Explosion-ProofUnits Only): .......................................................................................................................................14

EnvironmentalOperating Conditions ............................................................................................................................18

Start-UpProcedure .......................................................................................................................................................18

Howto Save Energy .....................................................................................................................................................19

Safety Tips....................................................................................................................................................................19

Troubleshooting.................................................................................................................................................................20

Maintenance .....................................................................................................................................................................21

Cleaning of Units...........................................................................................................................................................21

Interior/Exterior and Door Gaskets...............................................................................................................................21

Condenser ....................................................................................................................................................................21

Manual Defrost Procedure ............................................................................................................................................22

Ordering Procedures.........................................................................................................................................................24

Replacement Parts...........................................................................................................................................................23

One Year Limited Warranty...............................................................................................................................................25

Intended Use Statement ..................................................................................................................................................4

Reversing the Door Swing ..........................................................................................................................................17

Operation.........................................................................................................................................................................18

General Purpose LaboratoryRefrigerators and Freezers......................................................................................................9

Overview..........................................................................................................................................................................9

MODEL 05LFEETSA.....................................................................................................................................................10

.................................................................

Material Compatibility ...................................................................................

MODEL 02LREETSA.....................................................................................................................................................11

Safety Information

Alert Signals

Thank you for selecting Thermo Scientific products for yourequipment needs. These instructions contain

important operating and safety information. The user must carefully read andunderstand these instructions

before using theunit. Yourunit has been designed to optimize function, reliability, safety and ease of use. It is

the user’s responsibility to install the unit in conformance with local electrical codes.

DANGER RISK OF CHILD ENTRAPMENT

Before you throw away your old refrigerator or freezer:

Take off doors 



Leave the shelves in the place so that children may not easily climb inside. 

If the equipment is used in a manner not specified by the manufacturer, the

protection provided by the equipment may be impaired.

OFF

Safety Alert Important operating instructions. To reduce the risk of injury

or poor performance of the unit.Read the user manual

before putting the equipment into operation.

WARNING

Indicates an immediately hazardous situation, which

if not avoided, will result in death or serious injury.

CAUTION

Indicates an immediately hazardous situation, which if

not avoided, may result in minor to moderate injury.

(No symbol)

CAUTION

(Without Safety Alert Symbol) indicates a situation that

may result in property damage.

Shock Hazard

Use of this equipment involves power supplies which convert

line voltage to low voltage power. Do not modify or use

power supplies other than OEM equipment. Connection of

the power supply may require a properly grounded

receptacle. Potential for electrical shock or equipment

damage exists if precautions are not followed.

Frost bite/

Low

Temperature

Avoid contact with cold freezer surfaces potential

for cold burns or skin sticking to cold surfaces.

Intended Use Statement

The Refrigerators/Freezers described in this manual are for

professional use only. These products are intended for use

in research for the storage of samples or inventory in the

following temperature ranges :

General purpose Freezers: -14 °C to -25 °C

FMS and EXP Freezers:

-21 °C to -28 °C

Only Explosion Proof Units or Flammable

Material Storage Units are to be used for the

storage of flammable inventory/samples.

These are not considered medical devices and have therefore

not been registered with a medical device regulatory body (e.g.

FDA): that is, it has not been evaluated for the storage of

samples for diagnostic use or for samples to be re-introduced

to the body.

Warning

Only Explosion Proof Units or

Flammable Material Storage Units are to

be used for the storage of

flammable inventory/samples.

NOTE: Do not store corrosive materials in these units.

Any damage which occurs due to storage of corrosives

will not be covered under warranty claims.

General purpose Refrigerators: 1 °C to 8 °C

Explosion-Proof Refrigerators and

Freezers

Overview

Conventional refrigerators and freezers are not suitable for storing

flammable materials. Such units have components in their

electrical and refrigeration systems that can trigger explosions of

flammable air-vapor mixtures inside the unit and/or in the

immediate surrounding area.

The Authority Having Jurisdiction (AHJ) determines ifwork areas

are designated as a hazardous location with respect tothe

presence of flammable gases or vapors. Such locations are

defined in(National Fire Protection Agency) NFPA 70 Articles 500-

501 and OSHA 29 CFR1910.307. Some of these classified areas

are expected to experience concentrations of flammable gases

and/or vapors at or above their lower flammability limits for

extended periods of time.

The construction of our explosion-proof units has beenevaluated

by Canadian standards Association (CSA) and are suitable for use

in classified areas requiring Class I,Groups C and D* protected

equipment. The electrical components such as thermostats, wiring,

splices, relays and compressor motors on explosion-proof units are

safely housed within explosion-proof enclosures and conduit.

Compressor surface temperatures have been evaluated and

determined to remain below the flash point of materials found in

Class I,Groups C and D.

All models have heavy-gauge, rigid, steel construction with a

durable enamel finish. Interiors have epoxy enamel or ABS plastic

construction. Each unit is insulated throughout for energy-efficient

operation.

These units areideal for storing cyclopropane, ethyl ether,

ethylene, acetone, alcohol, benzene, butane, gasoline,hexane,

lacquer solvent vapors, naphtha, natural gas or propane along

with many other potentially hazardous materials.

*The notation Class I, Groups C and D is an accepted abbreviation

for Class I,Div 1, Groups C and D; Class I Zone 1 Group IIB.

EXPLOSION-PROOF UNITS

MODEL 05EFEETSA

21.5” Wide,

Under-counter freezer

Features:

•Adjustable thermostat

•Magnetic gasket

•Hermetically-sealed

compressor

•Manual defrost

•White color

Model Refrigerator Chamber Dimensions

H x Wx D inches (cm) Freezer Chamber Dimensions

H x Wx D inches (cm) Total Vol.

Cu. Ft. Exterior Dimensions

H x Wx D inches (cm)

05EFEETSA N/A 26" x 18" x 20.25"

(66 x 45.7 x 51.4 cm) 4.4 33.3" x 23.7" x30.1"

(84.5 x 60.1 x 76.4 cm)

Model Electrical Characteristics

Volts/Hz, Watts, Amps Refrig. Temp.Range

°C (°F) Net Wt.

Lbs. (kg) Ship Wt.

Lbs. (kg)

05EFEETSA 120/60, 110, 0.96 N/A

Freezer Temp.

Range

°C (°F)

-21 to -28

(-5.8 to -18.4) 77 (35) 95 (43)

NOTE: Amps listed are at normal run mode, starting amps may be higher.

Flammable Materials

Storage Refrigerators and

Freezers

Overview

Conventional refrigerators and freezers are not suitable for

storing flammable materials. Such units have components in

their electrical and refrigeration systems that can trigger

explosions of flammable air-vapor mixtures inside the unit.

Flammable Materials Storage (FMS) refrigerators/freezers are

designed for use in locations, which are not classified by the

Authority Having Jurisdiction (AHJ) as hazardous. Under normal

operating conditions the build up or presence of flammable

vapors will not occur in the environment external to the unit.

(Commonly known as “Ordinary Locations”)

FMS units are NOT designed foruse inClass I,Groups

Cand D environments, which require anExplosion-

Proof Refrigerator/Freezer.

FMS units are designed and evaluated by Canadian standards

Association (CSA) to meet the requirements of the National Fire

Protection Association Standards Nos. 45, 70 and 99. These

units have no internal electrical components that could trigger an

explosion or fire of hazardous materials inside the unit.

These units areideal for storing cyclopropane, ethyl ether,

ethylene, acetone, alcohol, benzene, butane, gasoline, hexane,

lacquer solvent vapors, naphtha, natural gas or propane along

with many other potentially hazardous materials.

All models have heavy-gauge, rigid, steel construction with a

durable enamel finish. Interiors have epoxy enamel or ABS

plastic construction. Each unit is insulated throughout for

energy-efficient operation.

FLAMMABLE MATERIALS STORAGE UNITS

MODEL 05FFEETSA

23.7”Wide

Under Counter freezer

Features:

•4.4 Cuft Under counter

•Mechanical Thermostat

•3 Wired Shelves and

3 Door Shelves

•Manual defrost

Model Refrigerator Chamber Dimensions

H x WxD inches (cm) Freezer Chamber Dimensions

H x Wx D inches (cm) Total Vol.

Cu. Ft. Exterior Dimensions

H x W x D inches (cm)

NOTE: Amps listed are at normal run mode, starting amps may be higher.

Model Electrical Characteristics

Volts/Hz, Watts, Amps Refrig. Temp.Range

°C (°F) Net Wt.

Lbs. (kg) Ship Wt. Lbs.

(kg)

05FFEETSA 120/60, 110, 0.96

Freezer Temp. Range

°C (°F)

-21 to -28

(-5.8 to -18.4)

05FFEETSA N/A 26" x 18" x 20.25"

(66 x 45.7 x 51.4 cm) 4.4 33.3" x 23.7" x 27.8"

(84.5 x 60.1 x 70.6 cm)

N/A 77 (35) 95 (43)

Andere Handbücher für 05EFEETSA

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Thermo Scientific Gefrierschrank Handbücher

Thermo Scientific

Thermo Scientific Revco RDE Series Betriebsanleitung

Thermo Scientific

Thermo Scientific TSX Series Betriebsanleitung

Thermo Scientific

Thermo Scientific TSG Series Betriebsanleitung

Thermo Scientific

Thermo Scientific HERAfreeze HFU Series Betriebsanleitung

Thermo Scientific

Thermo Scientific Fisher brand Isotemp FBV20FPSA Bedienungsanleitung

Thermo Scientific

Thermo Scientific PLUS Series Bedienungsanleitung

Thermo Scientific

Thermo Scientific Ultima II Bedienungsanleitung

Thermo Scientific

Thermo Scientific Thermo Scientific TDE Series Bedienungsanleitung

Thermo Scientific

Thermo Scientific ES Series Bedienungsanleitung

Thermo Scientific

Thermo Scientific TSX Series Betriebsanleitung

Thermo Scientific

Thermo Scientific Jewett CTF306 Bedienungsanleitung

Thermo Scientific

Thermo Scientific Isotemp -86 C Freezers Bedienungsanleitung

Thermo Scientific

Thermo Scientific ULT-10140-9-D Betriebsanleitung

Thermo Scientific

Thermo Scientific TSX Series Betriebsanleitung

Thermo Scientific

Thermo Scientific 325099H11 Betriebsanleitung

Thermo Scientific

Thermo Scientific 902 Betriebsanleitung

Thermo Scientific

Thermo Scientific Isotemp IUE 86L Series Bedienungsanleitung

Thermo Scientific

Thermo Scientific Revco ExF-86C Bedienungsanleitung

Thermo Scientific

Thermo Scientific Forma 900 Series Betriebsanleitung

Thermo Scientific

Thermo Scientific 8600 Series Betriebsanleitung

Thermo Scientific

Thermo Scientific XBF40-MD Series Einrichtungshandbuch

Thermo Scientific

Thermo Scientific 722 Betriebsanleitung

Thermo Scientific

Thermo Scientific 7451 Betriebsanleitung

Thermo Scientific

Thermo Scientific DLT Montageanleitung

Beliebte Gefrierschrank Handbücher anderer Marken

Siemens

Siemens GU..D SERIES Bedienungsanleitung

Omcan

Omcan FR-CN-0155 Bedienungsanleitung

Beko

Beko FNE290E24W Bedienungsanleitung

Electrolux

Electrolux ARCTIS G 8 60 50-6I Bedienungsanleitung

Electrolux

Electrolux EUF2042AOX Bedienungsanleitung

Dometic

Dometic CoolFreeze CFX95DZ Bedienungsanleitung

Electrolux

Electrolux EUF7000W1 Bedienungsanleitung

Polar Electro

Polar Electro CT330 Bedienungsanleitung

MPM

MPM MPM-145-SK Series Bedienungsanleitung

SAF

SAF PRESTOTIG 200AC/DC Kurzanleitung

Zanussi

Zanussi ZFT11407WA Bedienungsanleitung

AEG

AEG A63190GT Bedienungsanleitung

AEG

AEG A81000TNW0 Bedienungsanleitung

Matsui

Matsui MUC50S15E Bedienungsanleitung

NEFF

NEFF G4344X8 Bedienungsanleitung

Frigidaire

Frigidaire FV 1246 H Bedienungsanleitung

Frigidaire

Frigidaire FFC13K1AW Bedienungsanleitung

Electrolux

Electrolux EU 2400C Bedienungsanleitung
