Thomann LED-Commander 16/2 Bedienungsanleitung

LED-Commander 16/2

DMX-controller

user manual

Musikhaus Thomann

Thomann GmbH

Hans-Thomann-Straße 1

96138 Burgebrach

Germany

Telephone: +49 (0) 9546 9223-0

E-mail: [email protected]

Internet: www.thomann.de

06.08.2015, ID: 251852 | SW V1.0

Table of contents

1 General notes............................................................................................................................................... 4

2 Safety instructions..................................................................................................................................... 6

3 Features....................................................................................................................................................... 10

4 Installation.................................................................................................................................................. 11

5 Starting up.................................................................................................................................................. 12

6 Connections and operating elements........................................................................................... 13

7 Operation.................................................................................................................................................... 22

8 Technical specifications....................................................................................................................... 44

9 Protecting the environment.............................................................................................................. 45

Table of contents

LED-Commander 16/2

1 General notes

This user manual contains important information on safe operation of the device. Read and

follow all safety notes and all instructions. Save this manual for future reference. Make sure

that it is available to all persons using this device. If you sell the device, include the manual for

the next owner.

Our products are subject to a process of continuous development. We therefore reserve the

right to make changes without notice.

This section provides an overview of the symbols and signal words used in this user manual.

Signal word Meaning

DANGER! This combination of symbol and signal word indicates an

immediate dangerous situation that will result in death or

serious injury if it is not avoided.

NOTICE! This combination of symbol and signal word indicates a pos‐

sible dangerous situation that can result in material and

environmental damage if it is not avoided.

Symbols and signal words

General notes

DMX-controller

Warning signs Type of danger

Warning – danger zone.

General notes

LED-Commander 16/2

2 Safety instructions

This device is intended to be used to control spot lights, dimmers, light effects, moving heads

or other DMX-controlled devices. Use the device only as described in this user manual. Any

other use or use under other operating conditions is considered to be improper and may result

in personal injury or property damage. No liability will be assumed for damages resulting from

improper use.

This device may be used only by persons with sufficient physical, sensorial, and intellectual

abilities and having corresponding knowledge and experience. Other persons may use this

device only if they are supervised or instructed by a person who is responsible for their safety.

Intended use

Safety instructions

DMX-controller

DANGER!

Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and are not

within reach of babies and young children. Choking hazard!

Ensure that children do not detach any small parts (e.g. knobs or the like) from

the unit. They could swallow the pieces and choke!

Never let children unattended use electrical devices.

Safety

Safety instructions

LED-Commander 16/2

NOTICE!

External power supply

The device is powered by an external power supply. Before connecting the

external power supply, ensure that the input voltage (AC outlet) matches the

voltage rating of the device and that the AC outlet is protected by a residual cur‐

rent circuit breaker. Failure to do so could result in damage to the device and pos‐

sibly the user.

Unplug the external power supply before electrical storms occur and when the

device is unused for long periods of time to reduce the risk of electric shock or

fire.

NOTICE!

Risk of fire

Do not cover the device nor any ventilation slots. Do not place the device near

any direct heat source. Keep the device away from naked flames.

Safety instructions

DMX-controller

NOTICE!

Operating conditions

This device has been designed for indoor use only. To prevent damage, never

expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and

strong vibrations.

Safety instructions

LED-Commander 16/2

3 Features

n16 devices controllable via DMX-512

n2 × 8 memory slots each for scenes and chases

nFaders for fade and scene time and speed, dimmer etc.

nOperation modes: automatic, sound controlled and manual

nBlackout and Full-on-function

nSeparate channel assignment

nBackup and firmware update via USB

nUSB port for desk light

n19" housing, 4 RU

Features

DMX-controller
