1/20

For: PlayStation®3

User Manual

2/20

TECHNICAL FEATURES

1 Steering wheel base

2Steering wheel

3 D-pad

42 digital gearshift levers (Up & Down)

5 Action buttons

6 LED

7 MODE button

8 Large screw thread (for the clamping

system and the clamp screw)

9 Clamping system

10 Metal clamp screw

11 Pedal set cable and connector

12 Steering wheel cable and USB connector

13 Mains adaptor

14 Mains adaptor power cable

3/20

11 Pedal set cable and connector

15 Removable foot rest

16 Arch

17 Removable pedal set

18 Removable “Realistic Brake” MOD

(not installed by default)

19 2mm Allen key, supplied

20 2.5mm Allen key, supplied

17 Metal head

21 Plastic Head Support

22 Pedal arm

23 Removable metal stop

(not installed by default)

4/20

WARNING

Before you use this product, please read this documentation carefully and keep it safe should you need to

consult it later.

* Store the product in a dry location and do not expose it to dust or sunlight.

Warning – Electric shock

* Respect the connection direction.

* Do not twist or pull the connectors and cables.

* Do not spill any liquid on the product or its connectors.

* Do not short-circuit the product.

* Never dismantle the product (except to adjust the pedal set if necessary); do not throw it onto a fire and

do not expose it to high temperatures.

* Do not use any adaptors other than the mains adaptor provided with the “T500 RS”.

* Do not use the mains adaptor if its connectors or cables are damaged, split or broken.

* Make sure that the mains adaptor’s power cable is perfectly inserted into the wall socket.

* If the steering wheel is operating unusually (if it is emitting any abnormal sounds, heat or odours), stop

using it immediately, disconnect the power cable from the socket and disconnect the other cables.

* If you are not going to be using the steering wheel for an extended period, disconnect the mains adaptor

from the wall socket.

Make sure that you do not block any of the air vents on the steering wheel base. For optimum ventilation,

respect the points below:

Air vents

* Position the base at least 10 cm away from any wall surfaces.

* Do not place the base in any tight spaces.

* Do not cover the base.

* Do not let any dust build up on the air vents.

5/20

Playing with a force-feedback steering wheel may cause muscle or joint pain. To avoid any problems:

Warning – Injuries due to force feedback and repeated movements

* Avoid lengthy gaming periods.

* Take 10 to 15 minute breaks after each hour of play.

* If you feel any fatigue or pain in your hands, wrists, arms, feet or legs, stop playing and rest for a few

hours before you start playing again.

* If the symptoms or pain indicated above persist when you start playing again, stop playing and

consult your doctor.

* Keep out of children’s reach.

* During games, always leave both hands correctly positioned on the steering wheel without letting it go

completely.

* During game calibration, never place your hand or arm inside the steering wheel.

* Check the steering wheel base is carefully clamped as per manual’s instructions.

* After each use, put the warning notice back in its original place on the wheel’s shaft, to warn any

potential new users.

To be handled only by users

16 years of age or older

HEAVY PRODUCT

Be careful not to drop the product on yourself

or on anyone else!

ALWAYS

NEVER

6/20

Warning – Pedal set pinch hazard when playing

* Keep the pedal set out of children’s reach.

* Do not remove the protections placed on the pedal arms.

* During games, never place your fingers near the sides

* During games, never place your fingers near the of the pedals.

rear base

* During games, never place your fingers near the of the pedals.

front base

of the pedals.

NEVER

Warning – Pedal set pinch hazard when not playing

* Store the pedal set in a safe place, and keep it out of children’s reach.

* Do not remove the protections placed on the pedal arms.

7/20

INSTALLING THE WHEEL

Fixing the wheel to a Table or Desk

1. Place the wheel on a table or another flat surface.

2. Place the clamp screw (10) in the table clamp (9) then screw the clamping unit (anti-clockwise)

into the large screw thread (8) located under the wheel until it is perfectly stable.

ALWAYS NEVER

CAUTION: Never screw the clamp screw into the clamping system on itsown!

(this may damage the steering wheel).

8/20

ASSEMBLY /

DISASSEMBLY

To tighten:

Screw

anti-

clockwise

To loosen:

Unscrew

clockwise

Attaching the steering wheel and pedal set to a cockpit

1. Place the steering wheel on the Cockpit’s tablet.

2. Tighten 2 “M6” screws (not supplied) into the Cockpit table and into the 2 small screw threads

under the wheel.

Important note for the Wheel

3. If necessary, screw in the standard clamping system (into the large screw thread).

: These screws must not be longer than 12mm to avoid damaging

the components inside the base.

4. In the same way, attach the Pedal set using the small screw threads underneath it.

Note for the Pedal set

Do not hesitate to test the different possible settings for more comfort.

: In certain cockpits the “Floor position” (F1 type) will be more user-friendly.

On others the “Suspended position (GT/Rally type)" will be more comfortable.

9/20

INSTALLATION ON PLAYSTATION®3

1. Connect the pedal set to the steering wheel by plugging in its connector (11) at the back of the

wheel.

2. Connect the mains adaptor to the wheel (13) by plugging in its connector to the back of the wheel.

3. Connect the mains adaptor to its power cable (14).

Note: To be sure that the 2 elements are perfectly connected, push the power cable’s connector into

the mains adaptor socket firmly.

4. Connect the mains cable (14) to a socket.

5. Connect the wheel’s USB connector (12) to the console’s No. 1 port.

You are now ready to play!

AUTOMATIC CALIBRATION FOR THE WHEEL AND PEDALS

The wheel calibrates itself automatically once the mains adaptor and the USB connector are connected.

This operation will cause the steering wheel to move quickly 1080° to the left and right before coming

to its final position in the center.

When calibrating the steering wheel

CAUTION:

never touch the wheel

(this may mislead the calibration or cause injury).

The pedals are also calibrated automatically once they have been pressed a few times.

TROUBLESHOOTING & TIPS

- My wheel and my pedals don’t work correctly or appear to be improperly calibrated:

Switch off your console, completely disconnect your wheel including all cables (with the mains

adaptor and the pedal set) and restart your game.

- There are various tips and help features (not included in this manual) available on the

website http://ts.thrustmaster.com in the Technical Support category.
