tianhoo EOS play Bedienungsanleitung
EOS play
Bluetooth-Speaker
USER MANUAL
tianhootech.com
01.
IMPORTANT SAFETY INSTRUCTIONS
• Read these instructions – All the safety and operating instructions should be read
before this product is operated.
• Keep these instructions – The safety and operating instructions should be retained
for future reference.
• Heed all warnings – All warnings on the appliance and in the operating instructions
should be adhered to.
• Follow all instructions – All operating and use instructions should be followed.
WARNING!
• WARNING –To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture. The apparatus shall not be exposed to
dripping or splashing.• WARNING –do not cover.
• WARNING –only use attachments/accessories specified by the
manufacturer (such as the exclusive supply adapter, battery etc). the plug
is the main disconnect device and should be used as such. The
disconnect device should remain readily accessible.
• WARNING – do not listen too close to the active loudspeaker.
• WARNING – do not listen for an extended period of time at a high sound
pressure level.
• WARNING – do not attempt to remove the active loudspeaker chassis,
there are no user serviceable parts.
• DANGER – of dropping the product.
MOISTURE AND HUMIDITY
• The active loudspeaker should be located in a place free from moisture
and water.
• Do not use this apparatus near water
• Do not expose it to rain or dripping water. Do not splash water on it.
02.
INSTALLATION
• Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
CONNECTION
• Connect the active loudspeaker according to the instructions in the manual.
• Connect the active loudspeaker only to the correct mains voltage as shown
on the equipment.
• Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit the
apparatus.
• Use only power cables of the type specified in the operating instructions or
as marked on the active loudspeaker.
• Unplug this apparatus during lightning storms or when unused for long
periods of time.
• Do not install in an area that impedes access to the power plug.
Disconnecting the power plug is the only way to completely remove power
to the product and the plug must be readily accessible at all times.
CLEANING
• Clean only with dry cloth.
MAINTENANCE
• Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• CAUTION: These servicing instructions are for use by qualified service
personnel only. To reduce the risk of electric shock, do not perform any
servicing unless you are qualified to do so.
03.
COMPLIANCE MARKS
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This device and its antenna(s) must not be co-located or operating in conjunction with
any other antenna or transmitter.NOTE:
This equipment has been tested and found to comply with the limits for a Class B
digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference
in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to
try to correct the interference by one or more of the followingmeasures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, The 20cm is the
minimum
distance that has to be maintained between your body and the device.
FCC ID :2AXAX-ESOPLAY
1. EOS play CONFERENCE SPEAKER
2. POWER ADAPTER
3. MICRO USB CABLE
4. USER MANUAL AND WARRANTY CARD
04.
BOX CONTENS
1.
2.
3. 4.
05.
GENERAL DESCRIPTION
1.UPPER COVER
3.USBC
4.LIGHTNING
5.KEY PAD
6.INDICATORS LIGHT
7.MICROPHONE
8.LOUDSPEAKER
2.MICRO USB
9.MICRO USB PORT
1. Short Press : Play / Aanswer.
2. Short Press : Volume Down.
Hold Down 3 Seconts : Previous Song.
3 Short Press : Microphone off.
4. Short Press : Volume Up.
Hold Down 3 Seconts : Next Song.
5. Short Press : Hang Up.
Hold Down 3 Seconts : Disconnect and re-pair
06.
KEYPAD OVERVIEW
1 2 3 4 5
07.
IMPORTANT:
Before proceeding to point 1 below, check the included power
cord and plug and your EOSplay Bluetooth speaker are compatible
with your mains electricity supply and associated wall socket.
1. Insert the micro usb cable into the micro usb port on the back of
the speaker.
2. Insert the micro usb cable into the usb port on the POWER
ADAPTER
3. Connect the POWER ADAPTER to the wall socket.
PLUGGING IN THE EOS play
1 2
3
08.
BLUE LIGHT ON : Bluetooth connection ; Microphone on.
BLUE - GREEN FLASHING : Bluetooth is connecting.GREEN LIGHT FLASHING : Incoming call.GREEN LIGHT ON : Calling.RED LIGHT ON : Microphone off.RED LIGHT FLASHING : Pairing.
Follow these steps to pair the EOSplay wirelessly to your
bluetooth device.
1. Ensure that the EOSplay is powered on.
2. The RED indicator starts to flash.
3. Enable bluetooth functionality on your device. (smartphone,
tablet, computer).
4. On your device, select the EOS play from the bluetooth list and
accept pairing.
5. The bluetooth indicator on the speaker turns to a steady blue
and the units are now connected.
INDICATORS LIGHT
CONNECTING VIA BLUETOOTH PAIRING
09.
If a bluetooth connected device is moved outside the range
of the stanmore bluetooth (approximately 10 metres without
obstacles), it is disconnected. The device is automatically
connected again when it is moved back within range.
Every time the speaker starts up, it will tries to connect to the
last connected bluetooth device.
BLUETOOTH AUTO CONNECTION
Note: Only the original 5V 2A power adapter can be used.
Do not use non-original power adapters.
1. Open the upper cover and take out the magnetic plug. Choose
the magnetic plug that matches your smartphone.
2. Insert the magnetic plug into the port of your smartphone.
3. Put the remaining magnetic plug back into the slot and close the
top cover.
4. Put your smartphone into the magnetic port.
CHARGE YOUR SMARTPHONE.
