User Guide
SMART INFRARED CONTROLLER
YOUR AIR CONDITIONER WILL NEVER BE SMARTER
2
www.i-timetec.com
Smart Infrared Controller
PRODUCT BRIEF
The TimeTec Smart Infrared Controller can control home appliances
such as air conditioner or TV by infrared remote control. So user can
control appliances by using i-TimeTec APP.
3
www.i-timetec.com
Smart Infrared Controller
FEATURES
1Infrared remote control
2Learn and store infrared control commands
3LED indicator
4i-TimeTec App control
TECHNICAL SPECIFICATION
Working voltage: AC 180V-250V 50Hz
Standby current: <=15mA
Working current:
Working temperature: -10 - 55°C
Working humidity: <=90%RH
Communication distance: <=50M (open environment)
Dimension: ø81mm x 73mm
Installation: plug in
Learn infrared commands: 38
Appliances to control: 4
4
www.i-timetec.com
Smart Infrared Controller
How to add the device to your smart home system?
Log in to your i-TimeTec App account
In the main menu, select Add Device, then scan the QR code of the de-
vice.
Add the device to the TimeTec Smart Gateway or TimeTec Smart Camera
Gateway.
Plug in the device to electricity, power it up so it will connect to the Tim-
eTec Smart Gateway by wireless.
After it connects to the Gateway, the green LED is on. If the orange LED is
on, it does not connect to the Gateway.
Learn the infrared commands you want to use, then you can control the
appliances in your i-TimeTec smartphone APP.
HOW TO USE
black color zone, infrared receiver
5
www.i-timetec.com
Smart Infrared Controller
In i-TimeTec APP, click the TimeTec Camera Gateway, choose Setting, --Device--
Infrared controller, then Add, choose the appliance, get into the LEARN interface,
choose the function key you want to learn
Remote control facing the infrared receiver zone, press the button on the remote
control.
Orange LED flash once to confirm receiving the command
Press finish to end the learning of that command
After learning, user can use i-TimeTec APP to control.
Remark:
1 While learning, the distance between this device and remote control shall be less than 5 meters.
2. The control key on App shall be same function as the one on remote control.
3. Press the reset button for 10 seconds, while LED flashing in red and green slowly, release it, then
orange LED on. Then device quits from the network.
4. Press the reset button for 25 seconds, while LED flashing in red and green quickly, release it, then
orange LED on. Then device will erase all learned commands and quits the network.
6
www.i-timetec.com
Smart Infrared Controller
i-TimeTec Smartphone App control fail:
Check whether the device is already added and connected to the Tim-
eTec Smart Gateway
Can control ON/OFF, but appliance has no response
Check whether the infrared commands are already learned.
The device shall be installed in a dry place without chem-
ical corrosion.
Please contact service agent if the unit does not work
properly.
TROUBLESHOOTING
© 2020 Timetec Cloud Sdn Bhd. All rights reserved • 012020
