Tissot PRX Digital Bedienungsanleitung
QUARTZ DIGITAL
User’s Manual V1.0
Contents
2 / 19 24.07.2023
CONTENTS
HOME ..................................................................................................................................... 3
DATE ....................................................................................................................................... 5
T1 ............................................................................................................................................ 7
T2 ............................................................................................................................................ 9
LAP.......................................................................................................................................... 10
SPLIT....................................................................................................................................... 12
TIMER ..................................................................................................................................... 14
AL............................................................................................................................................ 16
OTHER .................................................................................................................................... 18
Light ............................................................................................................................................................................... 18
Sound ............................................................................................................................................................................ 18
Standby......................................................................................................................................................................... 18
Battery........................................................................................................................................................................... 18
HOME
24.07.2023 3 / 19
HOME
Welcome to your QUARTZ DIGITAL watch manual
Forward
Backward
Functions
Single press
+
-
0.5"
3"
LAP SPLIT
Setting
Validating
Light
Reset
Splits
Push-button press time
START/STOP
Pressed for more than 3 seconds
Pressed for more than 0.5 second
Sound
Battery
START/STOP
Standby
Functions
Select a pictogram to access the corresponding function
HOME
4 / 19 24.07.2023
General setting procedure
All settings are made using the same process.
1Select the function
2Enter setting mode
The whole screen flashes once
3"
3Adjust the value
+
-
4Confirm and exit setting mode
DATE
24.07.2023 5 / 19
DATE
Setting
1Select DATE
2Enter setting mode
The whole screen flashes once, then the year is
displayed and flashes
3"
3Adjust the value
+
-
4Confirm the selection and move on to the next
setting
The month flashes
5Adjust the value
+
-
6Confirm the selection and move on to the next
setting
The day flashes
7Adjust the value
+
-
8Confirm and exit setting mode
DATE
6 / 19 24.07.2023
Display the date temporarily
1In time display mode, you can temporarily
display the date
2Press once
The screen displays the date
3After 5 seconds, it reverts to time display mode
T1
24.07.2023 7 / 19
T1
Setting the time, setting the primary time
The time can be displayed in 12- or 24-hour mode
Setting
1Select T1
2Enter setting mode
The whole screen flashes once, then the hour flashes
3"
3Adjust the value
+
-
4Confirm and move on to the next setting
The minutes flash
5Adjust the value
+
-
6Confirm and move on to the next setting
The seconds flash
7Adjust the value
+
-
T1
8 / 19 24.07.2023
8Confirm and move on to the next setting
9Select 12- or 24-hour display mode
10 Confirm and exit setting mode
T2
24.07.2023 9 / 19
T2
Secondary time setting (second time zone)
Setting
1Select T2
2Enter setting mode
The whole screen flashes once, then the hour
flashes
3"
3Adjust the value
+
-
4Confirm and move on to the next setting
The minutes flash
5Adjust the value
Move forward or backward +/-15 minutes
+
-
6Confirm and exit setting mode
The seconds cannot be set and are always identical
to T1
LAP
10 / 19 24.07.2023
LAP
Timing in LAP mode (lap time)
Information
The LAP function is a chronometer designed to measure the lap time in a running
race or motor race.
For example: measuring the lap time taken for a long-distance runner.
Measurement range
Maximum measurement time
Measurement resolution (less than 1 hour)
Measurement resolution (more than 1 hour)
100 days
1/100''
1''
Minutes-seconds-hundredths display Hours-minutes-seconds display
Use
1Select the LAP chrono
To be able to select the LAP function, the SPLIT
chrono needs to be reset and vice versa
2Start timekeeping
3Each time the runner completes a lap, press to
record the lap time
The recorded time flashes on the display for
3seconds, then the current timing is displayed again
4On the runner's last lap, stop timekeeping
The last lap time is recorded
