Titan Attachments STANDARD Series Bedienungsanleitung
STANDARD SERIES ROTARY CUTTERS
STSRC48, STSRC60
191585, 191586
Operator’s Manual
Read the Operator’s Manual entirely.
When you see thissymbol, the
subsequent instructions and warnings are
serious follow without exception. Your life
and the lives of others depend on it!
2
IMPORTANT SAFETY INFORMATION
THESE ARE STANDARD PRACTICES THAT MAY NOT APPLY TO THE PRODUCTS
DESCRIBED IN THIS MANUAL.
SAFETY AT ALL TIMES
Thoroughly read and understand the instructions given in this manual before operation. Refer
to the “Safety Label” section, read all instructions noted on them. Do not allow anyone to
operate this equipment who has not thoroughly read and comprehended this manual. Do not
allow anyone who has not adequately trained in the safe operation of the equipment.
•The operator should be familiar with all functions of the unit.
•Operate implement from the driver’s seat only.
•Make sure all guards and shields are in place and secured before operating the tool.
•Do not leave a tractor or implement unattended with the engine running.
•Dismounting from a moving tractor could cause severe injury or death.
•Do not allow anyone to stand between tractor and implement while backing up to
implement.
•Keep hands, feet, and clothing away from power-driven parts.
•Wear snug-fitting clothing to avoid entanglement with moving parts.
•Watch out for wires, trees, etc., when raising implements. Make sure all persons are
clear of the working area.
•Turning the tractor too tight may cause implement to ride upon wheels. This activity
could result in injury or equipment damage.
•Do not carry passengers on the tool at any time.
LOOK FOR THE SAFETY ALERT SYMBOL
The SAFETY ALERT SYMBOL indicates a potential hazard to personal safety, and individuals
must take safety precautions. When you see this symbol, be alert and carefully read the
message that follows it. In addition to the design and configuration of equipment, hazard
control and accident prevention depend on the awareness, concern, prudence, and proper
training of personnel involved in the operation, transport, maintenance, and storage.
3
BE AWARE OF SAFETY ALERT WORDS
DANGER: Indicates imminently hazardous practices. A situation that, if not avoided, will result in
death or severe injury. The signal word is limited to the most extreme situation, typically for
machine components that, for functional purposes, cannot be guarded.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death or
severe injury, and includes hazards that are exposed when guards remove. Use warnings to alert
against unsafe practices.
CAUTION: Indicates a potentially hazardous situation that may result in minor or moderate injury
if not avoided. It may also be used to alert against unsafe practices.
FOR YOUR PROTECTION
Thoroughly read and understand the “Safety Label” section, read all instructions noted on them.
SHUTDOWN AND STORAGE
•Lower machine to the ground, put the tractor in park, turn off the engine, and remove the
key.
•Detach and store implements in an area where children typically do not play
USE SAFETY LIGHTS AND DEVICES
•Slow-moving tractors, self-propelled equipment, and towed implements can create a hazard
when driven on public roads. They are challenging to see, especially at night.
•Flashing warning lights and we recommend turn signals whenever driving on the public
road.
TRANSPORT MACHINERY SAFELY
•Comply with state and local laws
•The maximum transport speed for implement is 20 mph, DO NOT EXCEED. Never travel at a
rate that does not allow adequate control of steering and stopping. Some rough terrain
requires a slower speed.
•Sudden braking can cause a towed load to swerve and upset. Reduce speed if the towed
load is not equipped with brakes.
Use the following maximum speed –tow load weight ratios as a guideline:
•20 mph when weight is less than or equal to the weight of the tractor.
•10 mph when weight is double the weight of the tractor.
IMPORTANT: Do not tow a load that is more than double the weight of the tractor.
KEEP RIDERS OFF MACHINERY
•Riders obstruct the operator’s view; they could be struck by foreign objects or thrown from
the machine.
•Never allow children to operate equipment.
•Practice Safe Maintenance
•Understand procedure before doing work. Use proper tools and equipment; refer to
4
Operator’s Manual for additional information.
•Work in a clean, dry area
•Lower the implement to the ground, put the tractor in park, turn off the engine, and remove
the key before maintenance.
•Allow implement to cool completely.
•Do not grease or oil implement while it is in operation.
•Inspect all parts. Make sure details are in good condition and installed correctly.
•Remove the buildup of grease, oil, or debris.
•Remove all tools and unused parts from implementation before operation.
PREPARE FOR EMERGENCIES
•Be prepared if a fire starts.
•Keep a first aid kit and fire extinguisher handy
•Keep emergency numbers for doctor, ambulance, hospital, and fire department near the
phone.
WEAR PROTECTIVE EQUIPMENT
•Wear protective clothing and equipment appropriate for the job. Avoid loose-fitting clothing.
•Prolonged exposure to loud noise can cause hearing impairment or hearing loss. Wear
suitable hearing protection such as earmuffs or earplugs.
•Operating equipment safety requires the full attention of the operator. Avoid wearing radio
headphones while operating machinery.
AVOID HIGH-PRESSURE FLUIDS HAZARD
•Escaping fluid under pressure can penetrate the skin causing severe injury.
•Avoid the hazard by relieving pressure before disconnecting hydraulic lines or performing
work on the system.
•Ensure all hydraulic fluid connections are tight and all hydraulic hoses and lines are in good
condition before applying pressure to the system.
•Use a piece of paper or cardboard, NOT BODY PARTS, to check for suspected leaks.
•Wear protective gloves and safety glasses or goggles when working with hydraulic systems.
•If an accident occurs, see a doctor immediately. Remember, any fluid injected into the skin
must be treated within a few hours, or gangrene may result
TIRE SAFETY
•Tire changing can be dangerous, and trained personnel should be the only ones using
correct tools and equipment.
•When inflating tires, use a clip-on chuck and extension hose long enough to allow you to
stand to one side and NOT in front of or over the tire assembly. Use a safety cage if
available.
•When removing and installing wheels, use wheel handling equipment adequate for the
weight involved.
5
Warning
Danger: Keep hands and feet away
SAFETY LABELS
Your rotary cutter comes equipped with all safety labels in place. They were designed tohelp
you safely operate your implement. Read and follow the directions.
6
This shows the grease position.
Caution: 540 RPM PTO speed
Caution: Fill gearbox
with SAE 90gear lube
SSAFETY LABELS
7
INTRODUCTION
APPLICATION
TITAN Standard Series Rotary Cutters (STSRC) are ideal for clearing grass, weeds, and light
brush.These cutters offer fast, clean, dependable mowing, and have been extensively
tested to ensure safety. High blade tip speeds assure a clean cut in a variety of field
conditions. This Rotary cutter is adapted for standard Category 1 –three-point hitch or
Quick-Hitchsystem mounting. It’s recommended to equip a slip clutch PTO shaft.
SECTION 1: ASSEMBLY AND SET-UP
TRACTOR REQUIREMENTS
Tractor horsepower should be within the range noted below. Tractors outside the
horsepower range must not be used. Must be using a minimum of 40 hp when operatingat
maximum capability. The lower 3-Point arms must be stabilized to prevent side to side
movement. Most tractors have sway blocks or adjustable chains for this purpose.
WARNING
To avoid serious injury or death:
Lightweight tractors with rear attached implements may need weights added to the front to
maintain steering control.
Consult your tractor Operator’s Manual to determine proper weight requirements and maximum
weight limitations.
8
PACKING DESCRIPTION
1. REMOVE AND CHECK
Remove the packing and check goods to if there are any defects or part omission.
Figure 1-1: Your New Standard Rotary Cutter as it is shipped to You
Figure 1-2: The STSRC cutter and Accessory in Package
9
2. PACKING LIST
The detailed packing list of the mower and accessory as the following table 1-1.
ITEM
DESCRIPTION
QTY
PACKAGE FORM
(1)
MAIN BODY
1
NONW
(2)
FRONT AND REAR BRACES
1
BUBBLE FILM
(3)
DRIVELINE SHAFT WITH CLUTCH
1
BUBBLE FILM
(4)
WHEEL TIRE ASSEMBLY AND FITTINGS
1
BUBBLE FILM
(5)
PIVOTING UPPER HITCH-BLACK AND FITTINGS
1
BUBBLE FILM
(6)
TAILWHEEL ADJUTING BRACKET AND FITTING
1
BUBBLE FILM
(7)
R&L SKUD WELDMENT AND FITTING
1
BUBBLE FILM
(8)
IRON CRATE
1
NONE
(9)
REMOVABLE ANGLE STEEL
2
CRATE ATTACHMENT
(10)
LOCK NUT M10
12
CRATE ATTACHMENT
(11)
BOLT M10*20
8
CRATE ATTACHMENT
(12)
REMOVABE ANGLE STEEL SUPPORT
2
CRATE ATTACHMENT
(13)
BOLT M10*25
4
CRATE ATTACHMENT
(14)
PLAIN WASHER 10
4
CRATE ATTACHMENT
Table 1-1: Packing List of The Standard Rotary Cutter and Accessory
The detailed description of front and rear braces
Figure 1-3: Front and Rear Braces
ITEM
DESCRIPTION
QTY
(1)
REAR BRACE
2
(2)
FRONT BRACE
2
Table 1-2: Front and Rear Braces
10
The detailed description of wheel tire assembly and fittings
Figure 1-4: Wheel Tire Assembly and Fittings
ITEM
DESCRIPTION
QTY
(1)
RUBBER TIRE ASSEMBLY
1
(2)
SPACER H=6
2
(3)
CAP SHAFT MOUNT
1
(4)
SAFETY LOCK PIN 8*45
1
Table 1-3: Wheel Tire Assembly and Fittings List
The detailed description of pivoting upper hitch-black and fittings
Figure 1-5: Pivoting Upper Hitch-Black and Fittings
