Introduction
Thank you for purchasing TOP-VIEW KVM switch. TOP-VIEW KVM switch can save your MONEY, TIME,
SPACE, EQUIPMENT and POWER.
Controlling multiple PCs from One Keyboard, Mouse and VGA Monitor. TOP-VIEW
KVM switch is loaded with features such as 19” Rack Mount Size, Daisy Chain up to eight units, On Screen
Display Manual, Password security, searching PC server name, Hot key Control, Front Panel Push Button
and Auto Scan Control. It has complete keyboard and mouse emulation for simultaneous PCs boot-up
process.
Features
z4/8/16 port KVM switch is 19” rack mount size design.
zSupport Microsoft Intellimouse, Microsoft Intellimouse Explorer, Logitech Net Mouse or the other fully
compatible MS mouse.
zProvide Console PS/2 to PC serial mouse conversion
zSupport DOS, Win3.X, Win95/98/98SE/2000/ME, WinNT, Netware, Unix, Linux
zHot Plug - Add PCs or Remove Connected PCs for Maintenance without Powering Down the KVM
switch or PCs.
zVery High Video Quality - Up To 1920X1440, Bandwidth: 200MHz
zNo Software Required - easy PC selection via On Screen Display Manual, Push Buttons, Hot Keys
zSupport eight characters password protection and search PC server name
zAuto Scan Mode for monitoring PCs and flexible Scan time from 5~99 seconds
zKeyboard status restored when switching PCs
zLED Display for easy status monitoring
zBuzzer sound for switching port confirmation.
zUsing Standard Keyboard, VGA, Mouse cable.
zBuilt-in one extra daisy chain port and no waste any PC port
zNo DIP switch setting needed and auto detect daisy chain bank
Package Contents
Model No.: KS 104
4 port KVM Switch 1 PCS
User’s manual 1 PCS
AC to DC Power Adapter 1 PCS
Rack Mount Kit 1 SET
Daisy Chain Cable 1 SET
